Side 1/43

User Manual

IDK-1110R-series

TFT-LCD 10.4” SVGA (LED

Backlight)

IDK-1110R User Manual ii

The documentation and the software included with this product are copyrighted 2008

by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right

to make improvements in the products described in this manual at any time without

notice. No part of this manual may be reproduced, copied, translated or transmitted

in any form or by any means without the prior written permission of Advantech Co.,

Ltd. Information provided in this manual is intended to be accurate and reliable. How-

ever, Advantech Co., Ltd. assumes no responsibility for its use, nor for any infringe-

ments of the rights of third parties, which may result from its use.

Acknowledgements

AMI is a trademark of American Megatrends Inc.

IBM and PC are trademarks of International Business Machines Corporation.

Intel® Core 2 Quad, Pentium Dual Core and Celeron are trademarks of Intel Corpo-

ration.

WinBond is a trademark of Winbond Corporation.

All other product names or trademarks are properties of their respective owners.

Part No. 2006111000 Edition 1

Printed in China Jun 2012

iii IDK-1110R User Manual

A Message to the Customer

Advantech Customer Services

Each and every Advantech product is built to the most exacting specifications to

ensure reliable performance in the harsh and demanding conditions typical of indus-

trial environments. Whether your new Advantech equipment is destined for the labo-

ratory or the factory floor, you can be assured that your product will provide the

reliability and ease of operation for which the name Advantech has come to be

known.

Your satisfaction is our primary concern. Here is a guide to Advantech’s customer

services. To ensure you get the full benefit of our services, please follow the instruc-

tions below carefully.

Technical Support

We want you to get the maximum performance from your products. So if you run into

technical difficulties, we are here to help. For the most frequently asked questions,

you can easily find answers in your product documentation. These answers are nor-

mally a lot more detailed than the ones we can give over the phone.

So please consult this manual first. If you still cannot find the answer, gather all the

information or questions that apply to your problem, and with the product close at

hand, call your dealer. Our dealers are well trained and ready to give you the support

you need to get the most from your Advantech products. In fact, most problems

reported are minor and are able to be easily solved over the phone.

In addition, free technical support is available from Advantech engineers every busi-

ness day. We are always ready to give advice on application requirements or specific

information on the installation and operation of any of our products.

Produkspesifikasjoner

Merke:	Advantech
Kategori:	Ikke kategorisert
Modell:	IDK-1110R-23SVA1E
Type baklys:	LED
Berøringsskjerm:	Ja
Synsvinkel, horisontal:	160 °
Skjermform:	Flat
Innebygde høyttalere:	Nei
HDMI:	Nei
Skjermteknologi:	LCD
Innebygd kamera:	Nei
Energiforbruk (HDR) per 1000 timer:	- kWh
Energieffektivitetsklasse (SDR):	Ikke tilgjengelig
Energiforbruk (SDR) per 1000 timer:	- kWh
AMD FreeSync:	Nei
NVIDIA G-SYNC:	Nei
Innebygd USB-hub:	Nei
Berøringsskjermteknologi:	Resistive
USB Touch-port:	Ja
Kontrastforhold:	500:1
Skjermoppløsning:	800 x 600 piksler
Strømforbruk (standby):	- W
Antall USB Touch-porter:	1
Høydejustering:	Nei
Produktfarge:	Hvit
HD-type:	SVGA
Bredde (uten stativ):	243 mm
Høyde (uten stativ):	184 mm
Vekt (uten stativ):	380 g
Skjermdiagonal:	10.4 "
Naturlig sideforhold:	4:3
Strømforbruk (vanlig bruk):	3.5 W
Driftstemperatur (T-T):	-10 - 60 °C
Oppbevaringstemperaturomåde (Celsius):	-20 - 70 °C
VESA-montering:	Nei
Dybde (uten stativ):	8.3 mm
Synsvinkel, vertikal:	130 °
Overflatehardhet:	3H
Oppdateringsresponstid:	35 ms
Markedsplassering:	Industriell
Skjermlysstyrke (typisk):	230 cd/m²
Display antall farger:	16.2 million farger
Kabellåsport:	Nei
Anti-blendende skjerm:	Ja
