PCE-3032/PCE-4132 Startup Manual 1
Before you begin installing your card, please ensure the
following items have been shipped:
1. 1 x PCE-3032/PCE-4132 PICMG 1.3 System Host
Board
2. 1 x PCE-3032/PCE-4132 Startup Manual
3. 1 x Serial ATA HDD data cable
4. 1 x 2-port COM cable kit
5. 1 x 4-port USB 2.0 cable kit
6. 1 x Warranty card
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
PCE-3032/PCE-4132 LGA1200 Intel
®
Xeon
®
, Core™
i9/i7/i5/i3/Celeron
®
/Pentium
®
PICMG 1.3 Half-size
System Host Board with DDR4/Dual GbE LAN
Startup Manual
General
• CPU:LGA1200-socket Core™ i9/i7/i5/i3, Pentium
®
and
Xeon
®
W series processors
Note:Only PCE-4132 supports Intel
®
Xeon
®
processors.
• L2Cache: Please refer to CPU specication for detailed
information.
• BIOS: AMI SPI BIOS 256Mb (PCE-4132)/128Mb (PCE-
3032)
• SystemChipset:Intel
®
W480E (PCE-4132)/Intel®
H420E (PCE-3032)
• Systemmemory:
- PCE-4132: Up to 64 GB in 2 x 260-pin SODIMM sock-
ets. Supports dual-channel DDR4 2666/2933 SDRAM
with or without ECC function.
- PCE-3032: Up to 64 GB in 2 x 260-pin SODIMM sock-
ets. Supports dual-channel DDR4 2666/2933 SDRAM
without ECC function.
• SATAharddiskdriveinterface:PCE-3032 supports 3
x SATA 3.0 ports without RAID function, and PCE-4132
supports 4 x SATA 3.0 ports with SW RAID 0,1,5,10.
• Serialports:2 x RS-232 serial ports
• Watchdogtimer:Programmable 1~255 sec
• USB:4 x USB 3.0 and 6 x USB 2.0
• GPIO:1 x programmable 8-bit GPIO pin-header
Display
• Chipset:Intel
®
HD Graphics embedded in the processor.
EthernetInterface
• Chipset supports:
-
LAN 1: Intel
®
I210AT (PCE-3032) and I210AT (PCE-
4132).
-
LAN 2: Intel
®
I210AT (PCE-3032) and I210AT (PCE-
4132).
• Connection: 2 on-board RJ-45 connectors with LED
indicators.
MechanicalandEnvironmental
• Dimensions: (L x W): 172.6 x 126.3 mm/6.7 x 4.97 in
• Power supply voltage: +3.3 V, +5 V, +12 V, 5 VSB
• Power requirements:
CPU:Intel®i7-10700ECPU@2.90GHz,DDR:4GBSO-
DDR4-2666*2
Voltage +V12 +V5_SB +V3.3 +V5
Current 4.36A 0.17A 1.8A 2.13A
• Operating temperature: 0 ~ 60 °C / 32 ~ 140 °F (depend-
ing on CPU)
• Weight: 0.33 kg / 72 lb (weight of board)
SpecicationsPackingList
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
For technical support and service, please visit our
support website at:
https://www.advantech.com/support
This manual is for the PCE-3032/PCE-4132 Series Rev. A2.
PCE-3032: PCE-4132:
Part No. 2041303201
Printed in China
2nd Edition
October 2022
