PPC-112W/115W Startup Manual 1
Before installation, ensure that the following items are
included with the shipment:
1. 1 x Panel PC
2. 1 x Startup manual
3. 1 x Adapter
If any of the above items are missing or damaged, contact
your distributor or sales representative immediately.
PPC-112W/115W 11.6”/15.6” All-in-One Panel PC
with Rockchip 3399 Processor and Android 10 OS
Startup Manual
Front View
Rear View
VESA mount screws: 4 x M4 screws
Screw depth: 8 mm/0.31 in (max.)
A. DC-In
B. 1 x RS-232
C. 1 x USB 2.0
D. 1 x USB 3.0
E. 1 x LAN
F. 1 x Micro USB OTG
G. 1 x Reset button
H. 1 x Micro SD slot (with lock catch)
Packing List
For more information about this product, visit the
Advantech website at
http://www.advantech.com/products/fanless-panel-
pcs/sub_1-2jkjm3
For technical support and customer service, visit the
Advantech support website at
http://support.advantech.com/support/new_default.
aspx
This manual is for the PPC-112W/PPC-115W series,
Rev. A0.
Part No. 2044112W00
Printed in China
Edition 1
December 2021
Appearance
I/O Layout
2 PPC-112W/115W Startup Manual
Specications
PPC-112W-PK91A PPC-115W-PK91A PPC-115W-PK91B
CPU Rockchip RK3399 Big.Little architecture: Dual Cortex-A72 + Quad Cortex-A53 (64 bit)
GPU Mali-T860
Memory On-board 2 GB LPDDR4-1333
Network (LAN) 1 x 10/100/1000 Mbps
I/O
1 x USB 2.0, 1 x USB 3.0, 2 x USB 2.0 via pin header
1 x Micro USB OTG
1 x RS-232, 1 x RS-232 via pin header
1 x DC-In
5 x GPIO via pin header (3.3V TTL level)
Expansion 1 x M.2 2230 E-key slot
Watchdog Timer Timeout duration: 21s (max.)/10s (default)
Storage 16 GB eMMC NAND Flash; 1 x micro SD slot
Input Voltage 12V
DC
, 3A
Operating System Android 10 (default), Linux
Weight 1.78 kg/3.92 lb 2.6 kg/5.7 lb
Dimensions
291.7 x 186.6 x 49.2 mm/
11.5 x 7.3 x 1.9 in
402 x 260 x 53.2 mm/15.8 x 10.2 x 2.1 in
Mount Options VESA 100
Size 11.6” 15.6” 15.6”
Resolution 1366 x 768 1366 x 768 1920 x 1080
Viewing Angle
45 (left), 45 (right),
20 (up),40 (down)
45 (left), 45 (right),
15 (up), 35 (down)
85 (left), 85 (right),
85 (up), 85 (down)
Brightness 250 220 250
Contrast Ratio 500 400 800
Backlight Lifetime 15,000 hrs (min.)
Type Projected-capacitive multi touch
Light Transmission >88%
Interface USB
Operating Temperature 0 ~ 50 °C/32 ~ 122 °F
Storage Temperature -20 ~ 60 °C/-4 ~ 140 °F
Humidity 10 ~ 95% @ 40 °C/104 °F (non-condensing)
Shock 10 G peak acceleration (11 ms duration), in accordance with IEC 60068-2-27
Vibration Random vibration test 5 ~ 500 Hz, 0.5 Grms, in accordance with IEC 60068-2-64
EMC CE, FCC Class B, BSMI
Safety CB, UL, CCC, BSMI
Ingress Protection IP65-rated front panel
