SQFlash

CompactFlash Card

Specifications subject to change without notice, contact your sales representatives for the most update information.

REV 1.7 Page 1 of 49 Feb. 3, 2014

SQFlash

Technical Manual

(SQF-P10SX-XG-P8X)

SQFlash

CompactFlash Card

Specifications subject to change without notice, contact your sales representatives for the most update information.

REV 1.7 Page 2 of 49 Feb. 3, 2014

CONTENTS

1. Overview ............................................................................................ 4

2. Controller Features ........................................................................... 5

3. System Features................................................................................ 6

4. Specification Table ............................................................................ 7

5. General Description .......................................................................... 9

6. Pin Assignment and Description ................................................... 10

6.1

Compact Flash Interface Pin Assignments .................................................................... 10

6.2

Signal Descriptions ....................................................................................................... 12

7. Identify Drive Information ............................................................... 18

8. CIS information................................................................................ 19

9. Power Management ........................................................................ 24

9.1

Power Saving Flow ....................................................................................................... 25

10. ATA Command Set ........................................................................ 26

11. System Power Consumption ....................................................... 30

12. Electrical Specifications .............................................................. 30

13. DC Characters ............................................................................... 31

14. AC Characters ............................................................................... 31

14.1

PCMCIA Interface ......................................................................................................... 31

14.2

IDE Interface Timing (PIO Mode) .................................................................................. 40

14.3

Multi Word DMA ............................................................................................................ 43

14.4

Ultra DMA ...................................................................................................................... 45

15. Package Specifications ................................................................ 48

SQFlash

CompactFlash Card

Specifications subject to change without notice, contact your sales representatives for the most update information.

REV 1.7 Page 3 of 49 Feb. 3, 2014

Revision History

Rev.

Date

History

1.0

2011/11/10

1. 1

draft

1.1

2012/05/14

1. Add complete capacity information

1.2

2012/07/23

1. Correct transfer mode

1.3

2012/10/20

1. Add 512MB

1.4

2012/12/16

1. Detail endurance information

1.5

2013/09/26

1. Add endurance information

1.6

2014/01/03

1. Add performance and TBW information

1.7

2014/02/03

1. Add user capacity information (LBA)

2. Add power consumption by capacities

Advantech reserves the right to make changes without further notice to any products or data herein to improve reliability, function, or

design. Information furnished by Advantech is believed to be accurate and reliable. However, Advantech does not assure any liability

arising out of the application or use of this information, nor the application or use of any product or circuit described herein, neither

does it convey any license under its patent rights nor the rights of others.

Produkspesifikasjoner

Merke:	Advantech
Kategori:	Ikke kategorisert
Modell:	SQF-P10 P8
Bredde:	42.8 mm
Dybde:	36.4 mm
Høyde:	3.3 mm
Varighet:	5000000 sykluser per logiske sektor
Antall per pakke:	1 stykker
Kapasitet:	32 GB
Minnespenning:	3.3 V
Vibrasjonsmotstand:	20 G
Produktfarge:	Black, Blue, White
Internminnetype:	SLC
Driftstemperatur (T-T):	-40 - 85 °C
Beskyttelsesfunksjoner:	Sjokkresistent
Støt under drift:	1500 G
Type flashkort:	CompactFlash
Lesehastighet, medier:	83 MB/s
Skrivehastighet/brennehastighet:	87 MB/s
Flash-minneklasse:	Klasse 1
