SQFlash

M.2 2280 640

Specifications subject to change without notice, contact your sales representatives for the most update information.

REV 1.5 Page 1 of 25 Mar. 29, 2019

M.2 2280 640

Datasheet

(SQF-SM8x-xxx-SBx)

SQFlash

M.2 2280 640

Specifications subject to change without notice, contact your sales representatives for the most update information.

REV 1.5 Page 2 of 25 Mar. 29, 2019

CONTENTS

1. Overview ............................................................................................ 4

2. Features ............................................................................................. 5

3. Specification Table ............................................................................ 6

4. General Description .......................................................................... 8

5. Pin Assignment and Description ................................................... 11

5.1

M.2 2280 Interface Pin Assignments ............................................................................. 11

6. Identify Device Data ........................................................................ 14

7. ATA Command Set .......................................................................... 17

8. System Power Consumption ......................................................... 23

8.1

Supply Voltage .............................................................................................................. 23

8.2

Power Consumption ...................................................................................................... 23

9. Physical Dimension ........................................................................ 24

Appendix: Part Number Table ........................................................... 25

SQFlash

M.2 2280 640

Specifications subject to change without notice, contact your sales representatives for the most update information.

REV 1.5 Page 3 of 25 Mar. 29, 2019

Revision History

Rev.

Date

History

0.1

2016/3/22

1. Preliminary

0.2

2016/7/22

1. Update performance and TBW

0.3

2016/9/9

1. Update GPIO information

0.4

2016/10/13

1. Update 1TB information

0.5

2017/5/15

1. Update performance, power consumption & TBW

0.6

2017/5/17

1. Update power consumption & TBW

0.7

2017/10/31

1. Update performance

0.8

2018/3/3

1. Add 3D NAND (BiCS3) information

0.9

2018/4/24

1. Add 512GB performance information

1.0

2018/6/19

1. Update 3D NAND information

1.1

2018/8/31

1. Update TBW information

1.2

2018/11/21

1. Update Power consumption information

1.3

2018/12/28

1. Update OP temp description

2. Update write protect pin information

1.4

2019/1/9

1. Revise PN list

1.5

2019/3/29

1. Correct dimension information

Advantech reserves the right to make changes without further notice to any products or data herein to improve reliability, function, or

design. Information furnished by Advantech is believed to be accurate and reliable. However, Advantech does not assure any liability

arising out of the application or use of this information, nor the application or use of any product or circuit described herein, neither

does it convey any license under its patent rights nor the rights of others.

Produkspesifikasjoner

Merke:	Advantech
Kategori:	minnekort (SSD)
Modell:	SQF-SM8U4-128G-SBC
Bredde:	22 mm
Dybde:	80 mm
Høyde:	3.8 mm
Bruksanvisning:	Ja
Sertifisering:	CE
SSD-kapasitet:	128 GB
SSD-formfaktor:	M.2
Dataoverføringshastighet:	6 Gbit/s
Driftstemperatur (T-T):	0 - 70 °C
Bærekraftsertifikater:	RoHS
Beskyttelsesfunksjoner:	Shock resistant, Vibration proof
Videoopptaksgrensesnitt:	Serial ATA III
Støt under drift:	1500 G
Lesehastighet, medier:	561.36 MB/s
Skrivehastighet/brennehastighet:	497.16 MB/s
Tilfeldig lese (4KB):	87943 IOPS
Tilfeldig skrive (4kB):	86088 IOPS
Vibrering ved drift:	20 G
