AG Preamp Pedal
Revered for its tight, fast response and wide tonal flexibility, the AG preamp takes the beloved AG sound
and places it in a compact pedal. The AG preamp features a 4-band EQ and foot-switchable broadband
“deep” and “bright “controls for added depth and presence. Its 18-volt operation provides plenty of
headroom ensuring your sound stays clean and transparent. It also features a built-in headphone out and
aux in, for silent practicing, as well as a DI with pre/post and ground lift controls. The AG preamp is a
must-have for any bassist looking for a clean and transparent preamp with all the controls needed for
sculpting their sound.
Features:
• Analog preamp circuit inspired from the AG 700 amplifier
• 4-band EQ with treble, bass, low midrange, and high midrange controls
• Foot-switchable, broadband “Bright” and “Deep” EQ controls
• DI out with pre/post and ground lift controls
• 1/8” aux-in and 1/8” headphone out for silent practice
• Three-year limited warranty
Owner’s Manual
Manual Version 1.1
Functions
A. Top Panel:
Gain - Controls input sensitivity level
Treble - +/- 14 dB @ 4 kHz
Bass - +/- 17 dB @ 40 Hz
High Mid - +/- 14dB @ 800 Hz
Low Mid - +/- 15 dB @ 300 Hz
Volume - Controls output level
Engage - Toggles between on/bypass (blue LED indicates on)
Bright/Deep - Toggles through broadband “Deep”, “Bright”, or “Deep + Bright” (blue LED indicates on) The
frequencies for the boosts are:
Deep: +6 dB <250 Hz, shelving Bright: +6 dB >3 kHz, shelving
Headphone Mix - Controls mix of bass signal and aux-in in headphones
Aguilar Musical Instruments
316 South Service Road
Melville, NY 11747
