Side 1/93

H-9200AP

802.11a/b/g Dual Radio

ireless

Base Station

Use

’s Manual

AirLive WH-9200AP User’s Manual

No part of this publication may be reproduced in any form or by any means, whether

electronic, mechanical, photocopying, or recording without the written consent of OvisLink

Corp.

OvisLink Corp. has made the best effort to ensure the accuracy of the information in this

user’s guide. However, we are not liable for the inaccuracies or errors in this guide.

Please use with caution. All information is subject to change without notice

All Trademarks are properties of their respective holders.

Table of Contents

AirLive WH-9200AP User’s Manual

Regulatory Information

Federal Communication Commission Interference Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation. This

equipment generates, uses and can radiate radio frequency energy and, if not installed and

used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the user

is encouraged to try to correct the interference by one of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

- Consult the dealer or an experienced radio/TV technician for help.

FCC Caution: To assure continued compliance, (example - use only shielded interface

cables when connecting to computer or peripheral devices) any changes or modifications

not expressly approved by the party responsible for compliance could void the user’s

authority to operate this equipment. This device complies with Part 15 of the FCC Rules.

Operation is subject to the following two conditions: (1) This device may not cause harmful

interference, and (2) this device must accept any interference received, including

interference that may cause undesired operation.

For product available in the USA/Canada market, only channel 1~11 can be operated.

Selection of other channels is not possible.

IMPORTANT NOTE

FCC Radiation Exposure Statement:

This equipment complies with FCC radiation exposure limits set forth for an uncontrolled

environment. This equipment should be installed and operated with minimum distance

20cm between the radiator & your body.

This transmitter must not be co-located or operating in conjunction with any other antenna

or transmitter.

FCC NOTICE: To comply with FCC part 15 rules in the United States, the system must be

professionally installed to ensure compliance with the Part 15 certification. It is the

responsibility of the operator and professional installer to ensure that only certified systems

are deployed in the United States. The use of the system in any other combination (such as

co-located antennas transmitting the same information) is expressly forbidden.

Produkspesifikasjoner

Merke:	Airlive
Kategori:	Tilgangspunkt
Modell:	AirMax DUO
Vekt:	1105 g
Sertifisering:	RoHS, FCC, CE, IP-67
Internminne:	32 MB
Kablingsteknologi:	10/100Base-T(X)
Nettverksstandard:	IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11h, IEEE 802.3af
Støttede nettverksprotokoller:	HTTPS, WEB, Telnet, SNMP, PPPoE
Frekvensområde:	2400 - 6100 MHz
MAC-adressefiltrering:	Ja
Flash-minne:	8 MB
Universal Plug and Play (UPnP):	Ja
Maksimal dataoverføringshastighet:	108 Mbit/s
Antall kanaler:	140 kanaler
Dimensjoner (B x D x H):	122 x 225 x 225 mm
WAN-port:	Ethernet (RJ-45)
AC-inngangsspenning:	48 V
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	2
DC-inngangskontakt:	Ja
Modulator:	CCK, OFDM
Ethernet LAN dataoverføringshastigheter:	10, 100 Mbit/s
Sikkerhetsalgoritmer:	152-bit WEP, 802.1x RADIUS, SSH, SSH-2, SSID, WDS, WPA, WPA-PSK, WPA2, WPA2-PSK
Nettverksgrensesnitt:	Raskt Ethernet
Intern:	Nei
AC-adapter bunt:	Ja
Webbasert administrasjon:	Ja
Strøm over Ethernet (PoE):	Ja
Innput-strøm:	0.4 A
Utgangsstrømbeskrivelse:	17 - 23 dBm
Støttede dataoverføringsrater:	1, 2, 5.5, 11, 6, 9, 12, 18, 24, 36, 48, 54, 108Mbps
Antennetilkoblingstype:	N-type
VLAN støtte:	Ja
Antall forbindelser:	2
