Side 1/97



i

IP-200PHD-24 / IP-200PHD-24B

2.0 Mega Pixel Passive PoE

IPCamera

User’s Manual

 iAirLive IP-200PHD-24/IP-200PHD-24B 

User’s Manual

No part of this publication may be reproduced in any form or by any means, whether

electronic, mechanical, photocopying, or recording without the written consent of

OvisLink Corp.

OvisLink Corp. has made the best effort to ensure the accuracy of the information in

this user’s guide. However, we are not liable for the inaccuracies or errors in this

guide. Please use with caution. All information is subject to change without notice

All Trademarks are properties of their respective holders.



AirLive IP-200PHD-24/IP-200PHD-24B

User’s Manual

FCC Statement

Federal Communication Commission Interference Statement This equipment has

been tested and found to comply with the limits for a Class B digital device, pursuant

to Part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against harmful

interference in a residential installation. This equipment generates, uses and can

radiate radio frequency energy and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio communications. However,

there is no guarantee that interference will not occur in a particular installation. If this

equipment does cause harmful interference to radio or television reception, which can

be determined by turning the equipment off and on, the user is encouraged to try to

correct the interference by one of the following measures:

z Reorient or relocate the receiving antenna.

z Increase the separation between the equipment and receiver.

z Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

z Consult the dealer or an experienced radio/TV technician for help.

FCC Caution

Any changes or modifications not expressly approved by the party responsible for

compliance could void the user's authority to operate this equipment.

This device complies with Part 15 of the FCC Rules. Operation is subject to the

following two conditions: (1) This device may not cause harmful interference, and (2)

this device must accept any interference received, including interference that may

cause undesired operation. For product available in the USA/Canada market, only

channel 1~11 can be operated. Selection of other channels is not possible.

This device and its antenna(s) must not be co-located or operation in conjunction with

any other antenna or transmitter.

IMPORTANT NOTE

FCC Radiation Exposure Statement:

This equipment complies with FCC radiation exposure limits set forth for an

uncontrolled environment. This equipment should be installed and operated with

minimum distance 20cm between the radiator & your body.

Produkspesifikasjoner

Merke:	Airlive
Kategori:	Sikkerhetskamera
Modell:	IP-200PHD-24
Bredde:	52 mm
Dybde:	35 mm
Høyde:	75 mm
LED-indikatorer:	Ja
Bruksanvisning:	Ja
Wi-Fi:	Nei
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Maksimal oppløsning:	1600 x 1200 piksler
Strømkildetype:	PoE
Digital zoom:	10 x
Optisk zoom:	- x
Kablingsteknologi:	10/100Base-T(X)
Støttede nettverksprotokoller:	TCP/IP, UDP, ICMP, DHCP, NTP, DNS, DDNS, SMTP, FTP, HTTP, HTTPs, Samba, PPPoE, UPnP, Bonjour, RTP, RTSP, RTCP
PTZ-kontroll:	Ja
Dimensjoner (B x D x H):	52 x 35 x 75 mm
Linsesynsvinkel, horisontal:	58 °
Linsesynsvinkel, vertikal:	45 °
Bildefrekvens:	15 fps
Sensortype:	CMOS
Produktfarge:	Hvit
Minnekortenhet:	MicroSD (TransFlash)
Støttede grafikkoppløsninger:	1280 x 720 (HD 720), 1600 x 1200 (UXGA)
Strømforbruk (vanlig bruk):	3 W
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
Driftstemperatur (T-T):	0 - 40 °C
Oppbevaringstemperaturomåde (Celsius):	-15 - 60 °C
Lagringsrelativ fuktighet:	0 - 90
Innebygd kortleser:	Ja
CCD-sensorstørrelse:	1/3 "
IP-adressefiltrering:	Ja
Modell/Type:	IP-sikkerhetskamera
F-nummer (relativ apertur):	1.8
DC-inngangskontakt:	Ja
Lydsystem:	2-veis
Støttede Windows operativsystemer:	Ja
Sikkerhetsalgoritmer:	HTTPS
Minimumsbelysning:	1 lx
Ethernet/bredbåndsforbindelse:	Ja
Relativ luftfuktighet under drift (H-H):	20 - 80
Støttede plasseringer/plasseringer som kan benyttes:	Innendørs
Totale megapiksler:	2 MP
Videoformat som støttes:	H.264, MPEG, MPEG4
Strøm over Ethernet (PoE):	Ja
Strøm-LED:	Ja
Komposittvideo ut:	1
Passordbeskyttelsestype:	Ja
