Akai ABTS-M10 Bruksanvisning

Akai hub & dokkstasjon ABTS-M10

Les nedenfor 📖 manual på norsk for Akai ABTS-M10 (36 sider) i kategorien hub & dokkstasjon. Denne guiden var nyttig for 2 personer og ble vurdert med 4.7 stjerner i gjennomsnitt av 1.5 brukere

Last ned PDF

Side 1/36

ABTS- M10

CLOCK RADIO SPEAKER WITH BLUETOOTH

Instruction Manual

EN - ENGLISH

Please read this manual carefully before operating the unit.

This prevents malfunctions and lets you experience all features of your

device.

KEY DEFINITION

： Power on-off. Long press and hold for 2 seconds to turn off the

speaker and display goes out when the power hard key switch is ON, but the Time

and Alarm clock are still working. Long press

and hold for 5 seconds to reset

the speaker.

：Short press to play or pause music when play music on Bluetooth/AUX

mode; Short press to answer or Long press to reject it when have a coming call.

Promptly press twice to recall the last phone number. Short press to switch the

saved stations on FM mode.

: Short press to select Mode (Long press into the automatic searching

under FM mode and long press to set time Under Time mode).

：Short press to enter the previous music, Long press to decrease the

volume.

On the Time mode, short Press to select 12-hour format /24-hour format.

On FM mode, short Press to backward 0.1MHZ.

：Short Press to enter the next music, Long Press to increase the volume.

On the Time mode, Short Press to select 12-hour format /24-hour format.

On FM mode, short Press to forward 0.1MHZ.

6. ：Short Press to turn on/off and light on/off the Alarm clock 1; Long Press to

set Alarm clock 1.

：Short Press to turn on/off and light on/off the Alarm clock 2; Long Press to

set Alarm clock 2.

：Short Press to sleep for 10 minutes again.

：Short press to switch sleep countdown time (switch SOFF, S15, S30

and S60 to sleep in 15, 30 and 60 minutes)

：Short press to switch screen to three brightness (bright, medium,

low), Long press to switch mood light to three brightness (bright, low, off).

10. Power On/Off: It automatically enter Time mode after the back power switch

is on. The clock and Alarm are still working but the display and mood light are off

after the back power switch is off.

Characteristics:

Power Consumption: 12W

Bluetooth version:4.2

Bluetooth channel emission power:1.5 dbm

Input/Output

1. DC 5V Power supply

2. Built in Lithium battery 3.7V 2200mAh

3. Power output: 6W*2

Charging

use

Lithium Battery charging:

The

light

is bright in red

after the USB cable

inserted

for charging,

and the red light turns green after

the

Lithium Battery is

charged to

full.

Time

Mode:

Short press

to select 12 /24-hour format,

long press

to set Time,

then

short press

to set hour; short press

and

to set

minute,

then short press

complete time setting.

Alarm Mode

Short Press

to turn on/off

Alarm clock 1. Long press to set Alarm Time,

then

short press

to set hour; short press

and

to set

minute,

Short press

to complete

Alarm setting. To skip manual adjustment, keep

it idle for 3

seconds to resume to clock display.

Alarm

ring play for 2 minutes, the

alarm icon

and real-time flash

when alarm work, then sleep 10 minutes,

sustainable 6

cycles. Short press

to sleep more

10 minutes,

and short

press

to end snooze and turn off the alarm

when

short press again.

Short Press

turn on/off Alarm clock 2. Long press

to set Alarm Time, then

short press

to set hour; short press

and

to set

minute, Short press

to complete

Alarm setting; To skip manual adjustment, keep

it idle for 3

seconds to resume to clock display.

Alarm ring play for 2 minutes, the

alarm icon

and real-time flash when alarm work, then sleep 10 minutes,

sustainable 6

cycles.

Short press

to sleep more 10 minutes,

and short

press

to end snooze and turn off the alarm when short press

again.

Kindly please note: the alarm can be set at any mode.

BT frequency: 2.4 – 2.483 GHz

Produkspesifikasjoner

Merke:	Akai
Kategori:	hub & dokkstasjon
Modell:	ABTS-M10
Produkttype:	Stereo bærbar høyttaler
Vekt:	870 g
Bredde:	207 mm
Dybde:	70 mm
Høyde:	102 mm
Batterikapasitet:	2200 mAh
Bluetooth:	Ja
Bluetooth-versjon:	4.2
Tilkoblingsteknologi:	Ledning & Trådløs
Pakkevekt:	930 g
Antall høyttalere:	1
FM-radio:	Ja
Anbefalt bruk:	Universell
Impedans:	80 Ω
Batteriteknologi:	Lithium-Ion (Li-Ion)
Batteritype:	Innebygd batteri
Produktfarge:	Black, Grey
Pakkedybde:	86 mm
Pakkehøyde:	129 mm
Pakkebredde:	225 mm
Batterispenning:	3.7 V
Innebygd kortleser:	Ja
AUX-inngang:	Ja
RMS-rangert strøm/utgangseffekt:	12 W
DC inngående spenning:	5 V
Frekvensrekkevidde:	65 - 18500 Hz
