Bluetooth Car FM Transmitter and
Charger FMT-63BT
EN - ENGLISH
USER MANUAL
Thank you for purchasing our Bluetooth car charger!
In order to have a best performance experience,
please read the manual carefully before use!
I. Product introduction
This product is a car-specific car Bluetooth
player, built-in advanced Bluetooth and
WMA.MP3, FLAC. decoder chip, can play music
files inside U disk, wirelessly transmitted to car
audio, no need to modify your car can easily
make your music enjoy while driving. More
important is the purity and clarity of the special
sound of DSP technology. We hope to bring you
unlimited enjoyment of the music.
II. Schematic Appearance
Description:
1. USB1: QC3.0 fast charge output
2. PD fast charge
3. LED display
4. On / off key; press and hold for two seconds
to turn off / press any key to turn on
5. Short press: Previous/Long press to enter
mode switching (BT/USB/TF)
6. MIC
7. Play / pause / answer / call back / long press
to wake-up SIRI / Left and right rotation to adjust
the volume / addition and subtraction of left and
right rotation frequency in FM mode
8. Colorful light frame
9. U disk playback / 5V1A output
10. Short press the colorful light button to switch
/long press the colorful light button to turn on
breathing mode
11. Short press: next song / long press to enter
FM mode
12. TF card slot
13. Positive and negative Cigarette
III. Features
1. Bluetooth V5.0
2. Dual display digital tube display
3. Support QC3.0 quick charge
4. Support PD quick charge
5. Support voice assistant function
6. Support one-key soft shutdown; support any key to
boot
7. Support colorful light
8. Battery voltage detection
9. Automatic power off memory function
10. Support U disk music player
11. Support TF card music player
12. Support WMA, MP3, WAV, FLAC music format
files
13. Supports A2DP, AVRCP, HFP, HSP
14. Bluetooth hands-free calling
15. Bluetooth frequency: 2.4 – 2.483 GHz
16. Bluetooth channel emission power: 2dbm
VI. Operation instructions
4.1.1. The device will auto power on after plugging it
into the car cigar lighter socket, the LED will flash and
display HI->BT->FM Frequency.
4.1.2 Tune up the FM frequency same with the car
radio, then the voice will come out from the original
car speaker
4.1.3 Adjust the FM frequency:
Long press to enter state，the LED display
flashes, turn left/right to adjust the transmission
frequency from 87.5 ~ 108MHZ, and exit the
frequency point selection without operation for three
seconds.
4.2 Bluetooth Pairing
When pairing the product with the mobile phone at
the first time, it may need pin code to finish the
paring, for more details, please refer to the relevant
manual
1. Please turn on Bluetooth on your mobile phone and
search for the device “FMT-63BT” from phone menu
list. 2.Choose the device “FMT-63BT”
3. Choose “FMT-63BT” in menu of phone and select
the connection as “hands-free device” in the
authorized device.
Additional devices connection
After FMT-63BT powered on, it will start to
automatically reconnect to the paired device which
was latest paired.
Note: Not all phones can support the auto re-
connection, some phones may need to be granted
permission each time. You can set it to “Automatically
connect.” For more information, please refer to the
phone's user manual.
4.3 Use Bluetooth hands-free calling
(When your Bluetooth is running in background or
music playing status）
4.3.1 Dial number
After Bluetooth pairing finished, dial the No. directly in
your phone, Voice will auto come out from the car
audio system.
4.3.2 Answering the call
On the status of Bluetooth, to answer the incoming
call, press “ ”to answer, press again“ ”to
hang up.
4.3.3 Rejecting the call
Long press“ ”to reject the incoming call
4.3.4 Redialing the call
When Bluetooth is running in background,
press“ ” twice to redial the last phone call
4.4 Play music stored in your phone
This product supports A2DP function, which can play
the music stored in the mobile phone and transmit to
the car audio via FM.
4.5 Mode switch (BT/TF/U-Disk)
Long press“ ”to enter mode switch：BT---USB---
TF
After Bluetooth is paired successfully, select the
song to play or insert the TF/U disk to
automatically read and play the music.
4.6 Siri/google voice assistant function
After Bluetooth successfully paired, press and
hold 3 seconds“ ” button to activate the
Siri/Google voice assistant (the supported
mobile phone brands are: iPhone, Samsung,
native Android system mobile phone). Note:
Some phones do not have this feature.
4.7 Rainbow LED function
Short press to change the RGB light to Light
blue, blue, purple, red, yellow, green breathing
mode, shut-off, cycle switching mode, the device
has light color memory function after shut off
V. Tech Specs:
Rated working
voltage
12V-24V
Limit working
voltage
10~26V
PD output
20W
USB output
5W+18W
Working temp
0~50�
Music format
support
MP3 / WMA / WAV/ FLAC
SNR
>60dB
Battery voltage
error
±0.5V
USB1
U-disk /5V/1A
USB2
QC3.0(3.6V-12V)
Bluetooth Ver.
Version 5.0
Bluetooth audio
processing
DSP and A2DP(Advance
Audio Distribution Profile)
Bluetooth
transmission
distance
<10M
MIC effective
distance
0.5~2M
FM Freq.
87.5~108Mhz
VI. Warm tips:
1. Do not turn the radio volume too high (usually 18 or
below) to avoid the increase of the sound back noise.
2. Although the transmission power of this product is
relatively strong, better to skip the frequency with
strong signal in local to get a better sound quality
3.Do not use this product in a dusty and humid
environment with extremely high and low
temperatures.
4. Do not drop the product to avoid the surface
damage or breakdown.
5. Do not dismantle compulsory the product, if you
have any questions, please contact your dealer.
6. Due to continuous improvement and enhancement
of technology, changes in product performance and
functionality are subject to change without notice.
VII.Troubleshooting:
Power is
not
respondin
g or not
displayed
. Check if the machine is in good
contact with the cigarette port, and
the cigarette holder is not
seriously rusted.
· Unplug and re-try again
·Check if the cigarette holder is
powered normally
Can't play
. Check if the USB device is
connected to the player or not, or
you can try another USB device.
· Please make sure if no there is
copy of the file in the USB device
that can be supported by the
product.
· Please make sure the volume is
not set to 0
There is
noise but
no sound
. Whether the product player is in
a pause state
. Is the volume adjusted to 0 or
small?
The audio
of car can't
receive
sound
. Make sure that the product FM
launch has been turned on.
· Is the transmission frequency of
the product the same as that you
car?
The Tran
smiting
effect is
not good,
there is
some
noise
. Make sure that there is no strong
signal station at the frequency of
the current transmission. When
using it, adjust to the frequency of
no radio station to get better
sound effect.
VIII. Packaging
1. Manual 2. Main device
Disposal of waste electrical and electronic
equipment
This symbole on the product or
packaging means that the product
should not be treated as household
waste. Do not throw garbage at the
end of its life, but take it to a collection
center for recycling. In this way you will help to protect
the environment and be able to prevent any negative
consequences that it would have on the environment
and human health.
To find your nearest collection center:
- Contact local authorities;
- Access the web site: www.mmediu.ro
;
- Request additional information from the store
where you purchased the product.
Importator:
SC Intervision Trading-RO SRL
Pitesti, Bd. I.C. Bratianu, nr. 48-52, corp A, et. 5,
Cam 504-505, Jud. Arges, Romania,
cod postal: 110121
www.akai.com.ro
