Side 1/50
M N - 2 9 4 2 3 0 2 / 1 2
p r in t ed i n u .s . a .
Holding Cabinet
Deluxe or Simple Control
Models:
500-S
750-S
1000-S
1200-S
1000-UP
1200-UP
•INSTALLATION
•OPERATION
•MAINTENANCE
1200-UP
1200-s
W164 N9221 Water Street P.O. Box 450 Menomonee Falls, Wisconsin 53052-0450 USA
PHONE: 262.251.3800 800.558.8744
USA/CANADA
FAX: 262.251.7067 800.329.8744
U.S.A. ONLY
www.alto-shaam.com
1000-
1000-s
750-s
500-s
Delivery .........................................1
Unpacking .......................................1
Safety Procedures and Precautions ...................2
Installation
Installation Requirements .........................3
Clearance Requirements .........................3
Dimension Drawings, weights & capacities .........4-6
1200-S, 1200-UP pan/product capacities .............7
Universal Pan Slides/Side Racks and Shelves ........7
Options and Accessories .........................8
Leveling ......................................9
Restraint Requirements - Mobile Equipment ..........9
Drip Tray Installation ...........................10
Electrical Specifications ......................11-12
User Safety Information .........................13
Before Initial Use ..............................13
Heating Characteristics .........................13
Operating Instructions
Simple Control Operation ........................14
Deluxe Control Identification .....................15
Deluxe Control Set-Up ..........................15
Deluxe Control Operation ........................15
Heat Recovery ................................16
Dough Proofing Instructions ......................16
Deluxe Control Timer Programming ................17
General Holding Guidelines ......................18
Care and Cleaning
Cleaning and Preventative Maintenance ............19
Protecting Stainless Steel Surfaces ................19
Cleaning Agents ...............................19
Cleaning Materials .............................19
Clean Daily ...................................20
Sanitation
Sanitation/Food Safety ..........................21
Internal Food Product Temperatures ...............21
Service
Thermostat Accuracy ...........................22
Trouble Shooting ..............................23
Exterior Service Views and Parts -
simple control
single
compartment. .......................24-25
double compartment. ......................26-27
Exterior Service Views and Parts -
deluxe control
single
compartment. .......................28-29
double compartment. ......................30-31
Cable Heating Kits ............................32
Wire Diagrams
Always refer to the wire diagram(s) included with the unit
for most current version.
Warranty
Transportation Damage and Claims ........ Back Cover
Limited Warranty ...................... Back Cover
holding c a b i n e t s i n s t a l l a t i o n /o p e r a t i o n /s e r v i c e manual - pg. 1
DelIVery
This Alto-Shaam appliance has been
thoroughly tested and inspected to ensure only
the highest quality unit is provided. Upon
receipt, check for any possible shipping damage
and report it at once to the delivering carrier.
See Transportation Damage and Claims section
located in this manual.
This appliance, complete with unattached
items and accessories, may have been delivered
in one or more packages. Check to ensure that all
standard items and options have been received
with each model as ordered.
Save all the information and instructions
packed with the appliance. Complete and return
the warranty card to the factory as soon as
possible to ensure prompt service in the event of a
warranty parts and labor claim.
This manual must be read and understood
by all people using or installing the equipment
model. Contact the Alto-Shaam Tech Team Service
Department if you have any questions concerning
installation, operation, or maintenance.
note: All claims for warranty must include the
full model number and serial number of
the unit.
UnPaCKIng
1. Carefully remove the
appliance from the
carton or crate.
note: Do not discard the
carton and other
packaging material
until you have
inspected the unit
for hidden damage
and tested it for
proper operation.
2. Read all instructions in this manual carefully
before initiating the installation of this appliance.
DO NOT DISCARD THIS MANUAL.
This manual is considered to be part of the
appliance and is to be provided to the owner
or manager of the business or to the person
responsible for training operators. Additional
manuals are available from the Alto-Shaam
Tech Team Service Department.
3. Remove all protective plastic film, packaging
materials, and accessories from the appliance
before connecting electrical power. Store any
accessories in a convenient place for future use.
®
®
