W164 N9221 Water Street P.O. Box 450 Menomonee Falls, Wisconsin 53052-0450 USA
PHONE: 262.251.3800 800.558.8744
USA/CANADA
FAX: 262.251.7067 800.329.8744
U.S.A. ONLY
www.alto-shaam.com
M N - 2 8 9 5 3 0 9 / 1 1
p r i n t e d i n u . s . a .
Hot Holding
Rotisserie Companion
Models:
AR-7H MANUAL CONTROL
AR-7H ELECTRONIC CONTROL
•INSTALLATION
•OPERATION
•MAINTENANCE
SHOWN WITH PASS-THROUGH OPTION
i
Delivery ......................................................................1
Unpacking ..................................................................1
Safety Procedures and Precautions ............................2
Installation
Installation Requirements ......................................3
Clearance Requirements .......................................3
Leveling .................................................................3
Dimension Drawings ..............................................4
Product/Pan Capacity ............................................4
Electrical Connection .............................................5
Stacking Combinations & Instructions ................ 6-7
Options & Accessories ...........................................8
Operating Instructions
Start-Up Procedures ..............................................9
Manual Control Identification & Operation ..............9
Electronic Control Identification & Operation ........10
General Holding Guidelines .................................11
Sanitation ............................................................12
Care and Cleaning
Cleaning and Preventative Maintenance ..............13
Protecting Stainless Steel Surfaces .....................13
Cleaning Agents ..................................................13
Cleaning Materials ...............................................13
Equipment Care ...................................................14
Clean Daily ..........................................................14
Service
Troubleshooting Guide - Electronic Control ..........15
Troubleshooting Guide - Manual Control ..............16
Cable Replacement Kit ........................................16
Full Assembly ......................................................17
Interior Service View ............................................18
Door Assembly ....................................................18
Double Pane Curved Glass Door .........................19
Single Pane Flat Glass Door ................................20
Stainless Steel Back Panel ..................................21
Electrical - Manual Control ...................................22
Electrical - Electronic Control ...............................23
Wire Diagrams
Always refer to the wire diagram(s) included with the
unit for most current version.
Warranty
Transportation Damage and Claims .......Back Cover
Limited Warranty....................................Back Cover
dElIVEry
This Alto-Shaam appliance has been
thoroughly tested and inspected to ensure only
the highest quality unit is provided. Upon
receipt, check for any possible shipping damage
and report it at once to the delivering carrier.
See Transportation Damage and Claims section
located in this manual.
This appliance, complete with unattached
items and accessories, may have been delivered
in one or more packages. Check to ensure that all
standard items and options have been received
with each model as ordered.
Save all the information and instructions
packed with the appliance. Complete and return
the warranty card to the factory as soon as
possible to ensure prompt service in the event of a
warranty parts and labor claim.
This manual must be read and understood
by all people using or installing the equipment
model. Contact the Alto-Shaam Tech Team Service
Department if you have any questions concerning
installation, operation, or maintenance.
notE: All claims for warranty must include the
full model number and serial number of
the unit.
unpackInG
1. Carefully remove the
appliance from the
carton or crate.
notE: Do not discard the
carton and other
packaging material
until you have
inspected the unit
for hidden damage
and tested it for
proper operation.
2. Read all instructions in this manual carefully
before initiating the installation of this appliance.
DO NOT DISCARD THIS MANUAL.
This manual is considered to be part of the
appliance and is to be provided to the owner
or manager of the business or to the person
responsible for training operators. Additional
manuals are available from the Alto-Shaam
Tech Team Service Department.
3. Remove all protective plastic film, packaging
materials, and accessories from the appliance
before connecting electrical power. Store any
accessories in a convenient place for future use.
®
®
AR-7H Hot Holding Rotisserie Companion Operation & Care Manual 1
