Side 1/40
User Guide
English ( 2 – 7 )
Guía del usuario
Español ( 8 – 13 )
Guide d'utilisation
Français ( 14 – 19 )
Guida per l'uso
Italiano ( 20 – 25 )
Benutzerhandbuch
Deutsch ( 26 – 31 )
Gebruikershandleiding
Nederlands ( 32 – 37 )
Appendix
English ( 38 )
2
User Guide (English)
Introduction
Box Contents
Trouper
Power Cable
User Guide
Safety & Warranty Manual
Support
For the latest information about this product (system requirements, compatibility information,
etc.) and product registration, visit altoprofessional.com.
For additional product support, visit altoprofessional.com/support.
Setup
Connection Diagrams
Items not listed under the Box Contents are sold separately.
Example 1: One Trouper loudspeaker system with Bluetooth
®
audio device:
Smartphone,
tablet, etc.
Press and release the Trouper loudspeaker's
Pair button. Its LED will flash, and you will
hear a tone sequence from the loudspeaker.
From your Bluetooth device's settings page,
enable Bluetooth and select Alto Pro
Wireless as the device. When paired
successfully, you will hear a final
"confirmation tone" from the loudspeaker and
the Pair LED will light continuously. (The first
time you do this, the process may take up to
60 seconds.)
Note: When using two Trouper loudspeaker
systems, you will need to link them wirelessly.
The stereo signal will be split between them.
Please see Bluetooth > Linking to learn
more.
Power
3
Example 2: One Trouper loudspeaker system with vocal microphone and guitar with
active pickup:
Example 3: Two Trouper loudspeaker systems with remote mixer, DJ controller, etc.:
Connect a dynamic microphone to the Ch. 1
Input using an XLR or 1/4" (6.35 mm) TRS
cable. Connect a guitar with an active pickup
to the Ch. 2 Input using a 1/4" (6.35 mm) TS
cable.
Note: When using the Trouper loudspeaker
system with a guitar, we recommend using
one with active pickups rather than passive
pickups. If you use a guitar with passive
pickups, connect it to an external preamp or
direct input (DI) box, and connect the line-
level output to the loudspeaker.
We recommend using dynamic microphones
with the Trouper loudspeaker rather than
condenser microphones. If you use a
microphone that requires +48V of phantom
power, you must connect it to an external
phantom power supply. Trouper does not
supply any phantom power.
Microphone
Acoustic guitar
with active pickup
Power
Power
DJ controller,
mixer, etc.
Connect the left and right output of your DJ
mixer, controller, etc. to Ch. 1 Input of each
loudspeaker system using XLR or 1/4" (6.35
mm) TRS cables.
Tip: To send the same mix to both Trouper
loudspeakers, connect both channels of your
DJ mixer, controller, etc. to the Ch. 1 and Ch.
2 Inputs of one loudspeaker, and then connect
that loudspeaker's Link Output to the Ch. 1
Input of the other loudspeaker. Both Trouper
loudspeaker systems will then play identical
summed mono mixes.
