Side 1/2

PHONE (800) 267-5486 FAX: (800) 267-5489 WEB: WWW.AMPLI.COM EMAIL: INFO@AMPLI.COM

PARTS DESCRIPTION

1 Wireless Antenna - adjustable

2 On/Off Switch & Power indicator light

3 Wireless Mic Volume & Indicator Light

4 Wired Microphone Jack with Volume

Control

5 Audio input jack w/ volume control

6 Treble/Base Control

7 Jack Out for Recording

8 Reverb/Echo control

9 Speaker 6.5-in

10 Wireless Handheld Mic or Lapel Mic

with Transmitter

11 Power Cord & Audio Input Cable

12 Handle

OPERATING INSTRUCTIONS

1. Readytospeakoutofthebox!

a. ACpower–Beforeuse,pleasemakesurethevoltageof

powersupplyisthesameasthatindicatedontheunit.

 Ifdifferent,itwillcausedamagetotheunit.

b. DCpower–suppliedfromtheDCinputjack.Thevoltage

shouldbe12V-15V

c. Battery–IncludedSLA(sealedleadacid)rechargeablebat-

tery.

2. Beforeswitchingtheuniton,adjustthemastervolume,treble,

bassandecho(reverb)controlstominimum,thenturnuniton.

Adjustlevelsaccordingly.

3. Iffeedbackoccursturndownthetrebletonecontrol.Iffeedback

stillexists,turnmastervolumedown.

4. Ifvolumeisgettinglower,receivingdistanceisshortenedor

soundisnotnormal,changethebatteries.

5. Thewirelessmicrophoneandwiredmicrophonecanbeused

together.

6. CDINcanconnectwiththeportableRadio,CDplayer,VCR

playerorMP3Playerandothersoundsources.

7. RECOUTcanconnectwitharecordertohaveon-siterecording

ofyourpresentationORwiththeoutputjackofalargeramplifier

toenlargethecoverage.Youcanalsoplugintoahousesystem.

Wireless Portable Public Address

RECHARGEABLE MITY-VOX

SW212

FRONT VIEW

REC OUT

PHONE (800) 267-5486 FAX: (800) 267-5489 WEB: WWW.AMPLI.COM EMAIL: INFO@AMPLI.COM

PARTS DESCRIPTION

14 Carrying Case

15 Rechargeable Battery

16 Compartment for AC cord

17 AC Input

18 Fuse

19 Camera Tripod Mount

20 Optional Alkaline Battery Compartment

21 DC Input Jack

22 Charge LED Indicator

23 Power Supply Label

Wireless Portable Public Address

RECHARGEABLE MITY-VOX

SW212

REAR VIEW

8. Whennotusingthesystem,remembertoturnofftheON/OFFswitchof

themicrophoneandturnofftheswitchontheamplifierinordertoavoid

wastingpower.

9. Donotusedifferentbrandsofbatteriestogetherormixoldandnewbat-

teriestogether.Alwayschangeall8batteriesatthesametime.

10.Removetheoptional8-Dcellbatterieswhentheamplifierwillnotbeused

forlongperiodsoftime,sincetheycanleakanddamagetheunit.Ourwar-

rantydoesnotcoverdamagecausedbyleakingbatteries.

11.Don’topenthechassis.

12.Don’tgetunitwet.

13.Don’tuseanyvolatilechemicalsonunit.

If you have any questions please call 1-800-267-5486 Monday to

Friday 8 am to 6 pm CST.

Specs:

OperatingRange:64to128ft(20-

40m)

ReceivingMode:VHF

S/NRadio:60dB

DynamicRange:80dB

Power:30Watts

Impedance:600Ohm

AmplifierBattery:BuiltinSLA

rechargeableoroptional8D-cells

TransmitterBattery:9V

FrequencyRange:100-15,000Hz

VHFFMBand

1Unbalanced6.3mmjackinputfor

microphone

1unbalanced6.3mmjackforCD

1unbalanced6.3mmjackoutfor

REC

Dimensions:11.25-in.Hx9-in.Wx

6.5-in.D

Weight:7.5lbs.withoutbatteries

Updated9/10/2010
