DT3239D TOUCH DISPLAY
USER MANUAL
Catalog
Chapter 1 Product Introduction
1.1 Product introduction ....................................................................... 1
1.2 Precautions ..................................................................................... 1
1.3 About DT3239D ............................................................................... 1
Chapter 2 Touch Display Installation
2.1 Touch display installation instructions ............................................ 2
2.2 Product picture ................................................................................. 3
2.3 Bracket mounting ............................................................................. 4
2.4 Rear VESA wall mount installation .................................................... 4
2.5 Interface connection ......................................................................... 5
2.6 Touch technology ............................................................................. 5
Chapter 3 Operating Instructions
3.1 Adjust the touch display .................................................................. 6
3.1.1OSD Controller ......................................................................... 6
3.1.2 Power management system .................................................... 7
Chapter 4 Common Faults And Solutions
Common faults and solutions ............................................................... 7
Appendix A
Optimal resolution ............................................................................... 9
Appendix B
Use the touch display safely .................................................................. 9
Touch display maintenance ................................................................... 10
Product drawing ................................................................................... 12
1
Chapter 1 Product Introduction
1.1 Product introduction
DT3239D is an embedded product. The original intent of this product
was to create a product that is truly suitable for high performance, high
reliability and ease of use in a variety of complex environments.
1.2 Precautions
Use the touchmonitor properly and regularly inspect and maintain
your touchmonitor to maximize the performance and longevity of product.
See Appendix B for more information on the correct use of touch displays.
1.3 About DT3239D
DT3239D series products use WLED backlight LCD screen, 1920X1080
HD resolution, low power consumptionembedded structure, compact
shape, ultra-thin design, multiple sets of fixed holes, to meet a variety of
integration solutions. DT3239D series products have passed FCC, CE, RoHS
certification, and have a large number of market applications in industrial
control, self-service terminals, self-service vending machines, and game
console solutions.
Self-developed wide temperature and wide pressure industrial
control drive board;
Provide a variety of installation options;
High-quality LCD panel with wide viewing angle and good display
effect;
Easy-to-remove structure on the back for easy maintenance;
Compact, ultra-thin, easy to integrate from the side, top and bottom
Multi-point capacitive touch technology, surface AF treatment,
providing the best touch experience
VGA/HDMI dual display
2
M4*8 screw*16
Bracket*4left and
right
Bracket*4up and
down
Power cable *1
USB cable *1
OSD Controller *1
HDMI cable*1
Touch display *1
Chapter 2 Touch Display Installation
2.1 Touch display installation instructions
Each DT3239D should contain the following items:
