Quick Reference

MGE™ Galaxy™

3500 Series

10-40 kVA 380/400/415 V 3:3

15-40 kVA 380/400/415 V 3:1

Contents

MGE Galaxy 3500 10-40 kVA 380/400/415 V Quick Reference

Product Overview............................................................ 1

UPS for up to 2 battery modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

UPS for up to 4 battery modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Availability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Serviceability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Manageability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Total Cost of Ownership . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Default Settings............................................................... 3

AC Input ........................................................................... 4

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

380 V, 400 V, and 415 V . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

380 V, 400 V, and 415 V 3:1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Input Power Factor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

AC Output ........................................................................ 6

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

380 V, 400 V, and 415 V . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

380 V, 400 V, and 415 V 3:1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Efficiency ......................................................................... 7

Efficiency Curves . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Derating due to Load Power Factor . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Environmental ............................................................... 10

Heat Dissipation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

380 V, 400 V, and 415 V . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

380 V, 400 V, and 415 V 3:1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Produkspesifikasjoner

Merke:	Apc
Kategori:	uforstyrret strømtilførsel (UPS)
Modell:	MGE Galaxy 3500 10kVA 400V with 4 Battery Modules
Vekt:	627000 g
Støynivå:	43.3 dB
LED-indikatorer:	Ja
Pakkevekt:	657000 g
Sertifisering:	CE, EN 50091-2, EN/IEC 62040-3, EN/IEC 62040-1-1, IEC 61000-3-2, IEC 61000-3-3, ISO 14001, ISO 9001, VFI-SS-111
Utgangseffekt:	8000 W
Dimensjoner (B x D x H):	523 x 838 x 1491 mm
Batteriteknologi:	Forseglet blysyre (VRLA)
Batteritype:	VRLA
Batteriladetid:	5 timer
Produktfarge:	Sort
Driftstemperatur (T-T):	0 - 40 °C
Oppbevaringstemperaturomåde (Celsius):	-15 - 45 °C
Lagringsrelativ fuktighet:	0 - 95
Inngangsfrekvens:	40/70 Hz
Driftshøyde:	0 - 999.9 m
Relativ luftfuktighet under drift (H-H):	0 - 95
Innput-forbindelsestype:	5-wire (3PH + N + G)
Pakningsstørrelse (BxDxH):	650 x 1062 x 1643 mm
Strøm (maks.):	14 A
Høyde når uvirksom:	0 - 15000 m
Output strømkapasitet (VA):	10 kVA
Nødstrøm av (EPO):	Ja
Output-forbindelser:	1 x 4-wire (3PH + G) \t\n1 x 5-wire (3PH + N + G) \t\n1 x Screw Terminals
Utdata spenningsnotis:	+/- 5%
