Side 1/8
1
EN
DAILY REFERENCE
GUIDE
THANK YOU FOR BUYING A ARISTON PRODUCT.
In order to receive a more complete assistance, please
register your appliance on: www.aristonbrand.com
You can download the Safety Instructions and the Use
and Care Guide, by visiting our website
www.aristonbrand.com and following the Instructions
on the back of this booklet.
Before using the appliance carefully read Health and Safety guide.
PRODUCT DESCRIPTION
APPLIANCE
1. Upper rack
2. Foldable flaps
3. Upper rack height adjuster
4. Upper spray arm
5. Lower rack
6. Cutlery basket
7. Lower spray arm
8. Filter Assembly
9. Salt reservoir
10. Detergent and Rinse Aid dispensers
11. Rating plate
12. Control panel
0000 000 00000
Service:
1
2
3
4
5
6
10
12
7
11
9
8
CONTROL PANEL
1. On-Off/Reset button with indicator light
2.
Program selection button with indicator light
3.
Zone Wash button with indicator light / Key lock
4.
Eco program indicator light
5. Key lock indicator light
6. Display
7. Program number and remaining time indicator
8.
Tablet (Tab) indicator light
9. Closed water tap indicator light
10. Rinse Aid refill indicator light
11. Salt refill indicator light
12. Turbo button with indicator light / Tablet (Tab)
13. Delay Start button with indicator light
14. Start/Pause button with indicator light / Drain out
3
1
2
8
13
1454 6 7 10 11 129
2
FIRST TIME USE
SALT, RINSE AID AND DETERGENT
ADVICE REGARDING THE FIRST TIME USE
After installation, remove the stoppers from the racks and the retaining
elastic elements from the upper rack.
FILLING THE SALT RESERVOIR
The use of salt prevents the formation of LIMESCALE on the dishes and
on the machine’s functional components.
• It is important that the salt reservoir be never empty.
• It is important to set the water hardness.
The salt reservoir is located in the lower part of the dishwasher (see
PROGRAMS DESCRIPTION) and should be filled when the SALT REFILL
indicator light
in the control panel is lit.
1.Remove the lower rack and unscrew the
reservoir cap (anticlockwise).
2.Only the first time you do this: fill the salt
reservoir with water.
3.Position the funnel
(see figure)
and fill the salt
reservoir right up to its edge (approximately 1 kg);
it is not unusual for a little water to leak out.
4.Remove the funnel and wipe any salt residue
away from the opening.
Make sure the cap is screwed on tightly, so that no detergent can get
into the container during the wash program (this could damage the
water softener beyond repair).
Whenever you need to add salt, we recommend carrying out the
procedure before the washing cycle is started.
SETTING THE WATER HARDNESS
To allow the water softener to work in a perfect way, it is essential that
the water hardness setting is based on the actual water hardness in your
house. This information can be obtained from your local water supplier.
The factory setting is for average (3) water hardness.
• Switch on the appliance by pressing the ON/OFF button.
• Switch off the appliance by pressing the ON/OFF button.
• Hold down button START/PAUSE for 5 seconds, until you hear a
beep.
• Switch on the appliance by pressing the ON/OFF button.
• The current selection level number and the salt indicator light both flash.
• Press button P to select the desired hardness level (see WATER
HARDNESS TABLE).
• Switch off the appliance by pressing the ON/OFF button.
Setting is complete!
As soon as this procedure is complete, run a program without loading.
Only use salt that has been specifically designed for dishwashers.
After the salt has been poured into the machine, the SALT REFILL
indicator light switches off.
If the salt container is not filled, the water softener and the heating
element may be damaged as a result.
FILLING THE RINSE AID DISPENSER
Rinse aid makes dish DRYING easier. The rinse aid dispenser A should
be filled when the RINSE AID REFILL indicator light
in the control
panel is lit.
1. Open the dispenser
B
by pressing and pulling up the tab on the lid.
2. Carefully introduce the rinse aid as far as the maximum (110 ml)
reference notch of the filling space - avoid spilling it. If this happens,
clean the spill immediately with a dry cloth.
3. Press the lid down until you hear a click to close it.
NEVER pour the rinse aid directly into the tub.
ADJUSTING THE DOSAGE OF RINSE AID
If you are not completely satisfied with the drying results, you can ad-
just the quantity of rinse aid used.
• Switch the dishwasher on using the ON/OFF button.
• Switch it off using the ON/OFF button.
• Press button
START/PAUSE
three times - a beep will be heard.
• Switch it on using the ON/OFF button.
• The current selection level number and rinse aid indicator light flash.
• Press button P to select the level of rinse aid quantity to be
supplied.
• Switch it off using the ON/OFF button
Setting is complete!
If the rinse aid level is set to 1 (ECO), no rinse aid will be supplied. The
LOW RINSE AID indicator light will not be lit if you run out of rinse aid.
A maximum of 4 levels can be set according to the dishwasher model.
The factory setting is for a medium level.
• If you see bluish streaks on the dishes, set a low number (2-3).
• If there are drops of water or limescale marks on the dishes, set a
high number (4-5).
FILLING THE DETERGENT DISPENSER
To open the detergent dispenser
use the opening device A. Introduce
the detergent into the dry dispenser
B only. Place the amount of
detergent for pre-washing directly
inside the tub.
1.When measuring out the detergent
refer to the mentioned earlier
information to add the proper
quantity. Inside the dispenser
B
there
are indications to help the detergent
dosing.
2. Remove detergent residues from the edges of the dispenser and
close the cover until it clicks.
3. Close the lid of the detergent dispenser by pulling it up until the
closing device is secured in place.
The detergent dispenser automatically opens up at the right time
according to the program.
If all-in-one detergents are used, we recommend using the
TABLET
button, because it adjusts the program so that the best washing and
drying results are always achieved.
Water Hardness Table
Level
°dH
German degrees
°fH
French degrees
1 Soft 0 - 6 0 - 10
2 Medium 7 - 11 11 - 20
3 Average 12 - 17 21 - 30
4 Hard 17 - 34 31 - 60
5 Very hard 35 - 50 61 - 90
M
A
X
A
B
35
25
A
B
3
EN
PROGRAMS TABLE
The Eco 50° wash cycle adheres to the regulation standard . Although it has a longer duration than other wash cycles it uses less energy and AS/NZS 2007
is less harmful to the environment.
*) Not all options can be used simultaneously.
**) The duration of the program shown on the display or in the booklet is an estimate calculated on standard conditions. The actual time may vary
depending on many factors such as temperature and pressure of the incoming water, room temperature, amount of detergent, quantity and type of load,
load balancing, additional selected options and sensor calibration. The sensor calibration can increase program duration up to 20 min.
Standby consumption: Left-on mode consumption: 5 W - Off mode consumption: 0.5 W
WARNING: Some dishwasher detergents are strongly alkaline. They can be extremely dangerous if swallowed. Avoid contact with the
skin and eyes and keep children away from the dishwasher when the door is open. Check that the detergent receptacle is empty after
completion of the wash cycle.
Program
Drying
phase
Available options
*)
Detergent
dispenser
Duration of
wash program
(h:min)
**)
Water
consumption
(litres/cycle)
Energy
consumption
(kWh/cycle)
Tub B
1. Eco 50° 3:10 9.7 0.67
2. Auto Intensive 65° - 2:00 - 3:10 14 - 17 1.50 - 1.85
3. Auto Everyday 55° 1:30 - 2:30 14.5 - 16 1.15 - 1.30
4. Auto Fast 50° - - 0:55 - 1:20 13 - 14.5 1.15 - 1.25
5. Express 30’ 50° - - 0:30 9 0.55
6. Good Night 50° - 3:30 15 1.15
7. Sanitizing 65° - 1:40 10 1.20
8. Soak - - - - 0:12 4.5 0.01
9. Self-Clean 65° - 0:50 8 0.85
PROGRAMS DESCRIPTION
Instructions on wash cycle selection.
ECO
Normally soiled crockery. Standard program, the most efficient in terms
of its combined energy and water consumption.
AUTO INTENSIVE
Automatic program for heavily soiled dishes and pans (not to be used
for delicate items).
AUTO EVERYDAY
Automatic program for normally soiled pans and dishes.
AUTO FAST
Automatic program for limited quantity of normally soiled crockery
(ideal for 4 place settings).
EXPRESS 30’
Program to be used for lightly-soiled dishes with no dried food
residues. (Ideal for 2 place settings).
GOOD NIGHT
Suitable for night-time operation of the appliance. Optimum
performance ensured.
SANITIZING
Normally or heavily soiled crockery, with additional antibacterial wash.
SOAK
Crockery to be washed later. No detergent to be used with this
program.
SELF-CLEAN
Program to be used to perform maintenance of the dishwasher. It
cleans the interior of the appliance using hot water.
Notes:
Optimum performance levels when using the “Express”” program can
be achieved by observing the maximum amounts of specified place
settings.
To reduce consumption even further, only run the dishwasher
when it is full.
