Aruba IAP-130 Series Instant Access Point
Installation Guide
0511013-02 | November 2011 1
The Aruba IAP-134 and IAP-135 Instant access points support the IEEE 802.11n standard for high-
performance WLAN. These access points use MIMO (Multiple-in, Multiple-out) technology and support
existing 802.11a/b/g/n wireless services.
The Aruba IAP-130 Series access points provide the following capabilities:
Wireless transceiver
Protocol-independent networking functionality
IEEE 802.11a/b/g/n operation as a wireless access point
IEEE 802.11a/b/g/n operation as a wireless air monitor
Compatibility with IEEE 802.3at PoE
Minimum Software Requirements
The IAP-130 Series access point requires Aruba Instant 2.0 or later.
Package Contents
IAP-134 or IAP-135 access point
Installation guide (this document)
Aruba Instant Quick Start Guide
9/16” Ceiling Rail Adapter
15/16” Ceiling Rail Adapter
NOTE
Inform your supplier if there are any incorrect, missing, or damaged parts. If possible, retain the carton, including
the original packing materials. Use these materials to repack and return the unit to the supplier if needed.
NOTE
Additional mounting kits for use with the IAP-130 Series access points are sold separately. Contact your Aruba
sales representative for details.
2 Aruba IAP-130 Series Instant Access Point | Installation Guide
Device Overview
Figure 1 IAP-130 Series Access Points (IAP-134 Shown)
LEDs
The IAP-130 Series access point is equipped with five LEDs that indicate the status of various components
of the device.
PWR: Indicates the whether or not the IAP-130 is powered on and its status.
ENET 0: Indicates the status and activity of Ethernet port 0
ENET 1: Indicates the status and activity of Ethernet port 1
11b/g/n: Indicates the status of the 2.4 GHz radio
11a/n: Indicates the status of the 5.0 GHz radio
For more information about the LEDs and their behavior, see Table 3 on page 9.
External Antenna Connectors
The IAP-134 is designed for use with external antennas. The IAP-135 is equipped with internal antennas. For
more information about antenna types and configurations, visit
www.arubanetworks.com.
AP-134_003
134
Antenna Connectors (IAP-134 Only)
LED Status Indicators
