Side 1/24

VE228 Series

LCD Monitor

User Guide

Contents

 

 

 

  

  

  

1.3.1 Frontview....................................................................... 1-2

1.3.2 Backview........................................................................ 1-3

  

  

  

  

  

  

3.1.1 Howtorecongure.......................................................... 3-1

3.1.2 OSDFunctionIntroduction.............................................. 3-1

  

  

  

iii

Notices

Federal Communications Commission Statement

This device complies with Part 15 of the FCC Rules. Operation is subject to the

following two conditions:

• This device may not cause harmful interference, and

• This device must accept any interference received including interference that

may cause undesired operation.

This equipment has been tested and found to comply with the limits for a Class

B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed

to provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may

cause harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation. If this

equipment does cause harmful interference to radio or television reception, which

can be determined by turning the equipment off and on, the user is encouraged to

try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which

the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

The use of shielded cables for connection of the monitor to the graphics card is

required to assure compliance with FCC regulations. Changes or modications

to this unit not expressly approved by the party responsible for compliance

could void the user’s authority to operate this equipment.

Canadian Department of Communications Statement

This digital apparatus does not exceed the Class B limits for radio noise emissions

from digital apparatus set out in the Radio Interference Regulations of the

Canadian Department of Communications.

This class B digital apparatus complies with Canadian ICES-003.

Produkspesifikasjoner

Merke:	Asus
Kategori:	skjerm
Modell:	VE228DR
LED-indikatorer:	Kraft indikator
Berøringsskjerm:	Nei
Synsvinkel, horisontal:	170 °
Pakkevekt:	6100 g
Innebygde høyttalere:	Nei
Sertifisering:	CEL, UL/cUL, CB, CE, ErP, FCC, CCC, BSMI, Gost-R, C-Tick, VCCI, PSB, J-MOSS, RoHS, WEEE, Windows Vista, Windows 7 WHQL
HDCP:	Nei
3D:	Nei
Digital horisontal frekvens:	30 - 83 kHz
Digital vertikal frekvens:	50 - 76 Hz
Kontrastforhold (dynamisk):	80000000:1
Innebygd kamera:	Nei
Tynn klient installert:	Nei
AC-inngangsspenning:	100 - 240 V
AC-inngangsfrekvens:	50 - 60 Hz
Skjermoppløsning:	1920 x 1080 piksler
Strømforbruk (standby):	- W
Høydejustering:	Nei
Produktfarge:	Sort
HD-type:	Full HD
Vippevinkelområde:	20 - -5 °
Bredde (uten stativ):	512.84 mm
Høyde (uten stativ):	385.96 mm
Vekt (uten stativ):	4100 g
Bredde (med stativ):	512.84 mm
Dybde (med stativ):	56.9 mm
Høyde (med stativ):	305.51 mm
Pakkedybde:	148 mm
Pakkehøyde:	468 mm
Pakkebredde:	576 mm
Skjermdiagonal:	21.5 "
Naturlig sideforhold:	16:9
Støttede grafikkoppløsninger:	1920 x 1080 (HD 1080)
Strømforbruk (vanlig bruk):	35 W
Antall VGA (D-Sub)-porter:	1
Bærekraftsertifikater:	ENERGY STAR
VESA-montering:	Ja
Dybde (uten stativ):	201.82 mm
Synsvinkel, vertikal:	160 °
Oppdateringsresponstid:	5 ms
Pikselbredde:	0.248 x 0.248 mm
Panelmonterbart grensesnitt:	100 x 100 mm
Skjermlysstyrke (typisk):	250 cd/m²
Display antall farger:	16.78 million farger
Størrelseforhold:	16:9
Display:	LCD
Innebygd TV-mottaker:	Nei
Kabellåsport:	Ja
Kabellåstype:	Kensington
Strømforbruk, av:	0.5 W
Strømforbruk, strømsparing:	0.5 W
Plugg inn og spill:	Ja
