Specifications are subject to change without notice
AtlasSound.com
1601 JACK MCKAY BOULEVARD ENNIS, TEXAS 75119 U.S.A. • TELEPHONE: (800) 876-3332 • FAX: (800) 765-3435
©2004 ATLAS SOUND LP Printed in U.S.A. 000604 ATS001741 RevB 6/04 487010
INSTALLATION INSTRUCTIONS
ATLAS SOUND PD-30(T)(-16),
PD-5V(H)(T),PD60A(T)
GENERAL DESCRIPTION
• High efficiency compression drivers with various power levels available
• Environment resistant construction for indoor/outdoor use
• Various horn types available for different coverage patterns and SPL’s
• Field replaceable diaphragms
PD-30(T)(-16)
Field connections are made to the 2 screw terminals located under the clear cover plate. Terminal 2 is positive with respect
to terminal 1. For the transformer equipped models, a screwdriver adjustable tap selector is also located beneath the
cover plate. Set the tap to the desired power level by lining up the screwdriver slot with the correct tap position. Do
not use
positions 6 or 7 (PD-30T) for a 70.7V line. It is recommended that the proper high pass filter be installed to limit low
frequency reproduction and to prolong diaphragm life. Low frequency cut off is a parameter of the horn attached
to this driver. Check with Atlas Sound for recommendations. See Capacitor Selection Chart for the proper value on
this document.
PD5VH(T)
Field connections for the
non transformer version are located on the outside of the sound chamber and are marked “1”
and “2”. Pin 2 is positive with respect to pin 1.
For the transformer equipped version, field connections are made to the screw terminals located on the rear of the driver
assembly, beneath the clear protective cover. On this model, connect the common of your speaker line to the terminal
labeled “C”, the positive of your speaker line to the appropriate tap terminal.
It is recommended that the proper high pass filter be installed to limit low frequency reproduction and to prolong
diaphragm life. Low frequency cut off is a parameter of the horn attached to this driver. Check with Atlas Sound
for recommendations. See Capacitor Selection Chart for the proper value on this document
.
SPECIFICATIONS
MODEL POWER
RATING
PLANE WAVE
FREQ. RESPONSE
LOW FREQ. LIMIT
@ FULL POWER
SOUND
LEVEL˚
IMPEDANCE POWER
TAPS
VOICE
COIL
DIMENSIONS WEIGHT
PD-5VH
40W 110 - 4,100 Hz
(±5DB)
250Hz 110.7 (AVG)
110 - 4,200 Hz (±5db)
16 (Nom.) – 2”
(5CM)
5 1/8” H x 6
3/8” W (17.5cm
x 16.2cm)
4.10 lbs.
(1.9Kgs.)
PD-5VT 40W 190 - 4,200 Hz
(±5db)
300 Hz 111.2 (avg)
190 - 4,200 Hz (±5dB)
2K, 1K, 500,
250, 125, 16
70.7V
@ -
2.5, 5, 10,
20, 40
6 7/8” H x
6 3/8” W
7 lbs.
(3.2Kgs)
SPECIFICATIONS
MODEL
POWER
RATING
PLANE WAVE
FREQ. RESPONSE
LOW FREQ. LIMIT
@ FULL POWER
SOUND
LEVEL˚
IMPEDANCE POWER
TAPS
VOICE
COIL
DIMENSIONS WEIGHT
PD-30
30W
300 - 3,900 Hz
(±5dB)
500Hz
113.6 (avg) 300 -
3,900 Hz (±5dB)
8 (Nom.) –
1.5”
(3.2cm)
4.5” H x 4.5”
Dia. (11.4cm x
11.4cm)
3 lbs.
(1.45Kgs.)
PD-30-16
16 (Nom.)
_
4.75 lbs.
(2.1Kgs)
PD-30T 45, 89, 167,
333, 666,
1300, 2500
70.7V@ -
1.8, 3.7,
7.5, 15, 30
