Side 1/16
Owner’s Manual
TSD-ML22VCA
2x2 Mic/Line Preamp & VCA
AtlasIED.com – 1 –
Specifications are subject to change without notice.
1601 Jack McKay Blvd. • Ennis, Texas 75119 U.S.A.
Telephone: 800.876.3333 • Fax: 800.765.3435
TSD-ML22VCA
2x2 Mic/Line Preamp & VCA
Owner’s Manual
TSD-ML22VCA
2x2 Mic/Line Preamp & VCA
AtlasIED.com – 2 –
Specifications are subject to change without notice.
1601 Jack McKay Blvd. • Ennis, Texas 75119 U.S.A.
Telephone: 800.876.3333 • Fax: 800.765.3435
Description
The AtlasIED TSD-ML22VCA is a 2 input, 2 output true VCA with enhanced features including a high
quality microphone pre amplier. VCA’s inserted prior to amplication provides a far more efcient
solution than transformer-based attenuators for volume adjustment in high power music applications.
The dual channel design can provide level control for two separate discrete zones or stereo sources
and is perfect for use in sports bars, restaurants, hotels or other installations.
The TSD-ML22VCA also provides two high quality, low noise mic pre-amps, which allows
simplication of designs that require remote microphone level adjustment. Switchable phantom
power is provided for powering condenser microphones and a 12dB/octave @ 125Hz high pass lter
is available on each mic input to minimize bass rumble and low frequency feedback in the system
ensuring focus and clarity for the voice spectrum.
The TSD-ML22VCA is part of a full line of AtlasIED Time Saving Devices. These compact
(1.5" x 4" x 2.75") units are designed to solve some of the common audio system problems in the
easiest and in the most efcient and cost-effective way. All models are made from high quality
components and include removable individual I/O connectors for quick and precise wiring, separate
ground terminals for all I/Os assuring secured connections, and removable level controls that can be
replaced with tamper-proof security covers. The TSDs are highly efcient and meet Energy Star™
standards as one 24V DC power supply (available separately) can power multiple AtlasIED Time
Saving Devices.
Features
• Two (2) Selectable Balanced Mic or Line
Inputs
• High Gain Mic Input 50dB
• 12dB/Oct @ 125Hz Low Cut Filter Per Input
• Phantom Power Per Input
• Two (2) Balanced Mic/Line Outputs
• Separate Channel VCAs for Remote Level
Control via Wall Plate or Programmable
External DC
• Input Peak Indicator Per Channel
• Input Signal Indicator Per Channel
• High Gain Output for Long Distance
Applications
• Cable Management System
• Multiple Mounting Congurations
• Separate Ground Connections
• Removable Phoenix Style I/O Connectors
• Security Covers Included for All Front
Panel Controls
• Meets Energy Star™ Standards
• Compact Chassis Design
Audio Applications
• Mic Preamp
• Line Preamp
• Line Drive
• Choirs
• Remote System Controller
Installation
• Churches
• Restaurants
• Sports Bars
• Schools
• Industrial Facilities
• House of Worship
