Side 1/24

– 1 – AtlasSound.com

Specifications are subject to change without notice.

Owner’s Manual

AA200PHD-CE

200W Mixer Amplifier

1601 Jack McKay Blvd. • Ennis, Texas 75119 U.S.A.

Telephone: 800.876.3333 • Fax: 800.765.3435

AA200PHD-CE

200W Mixer Ampliﬁer

AtlasSound.com – 2 –

Specifications are subject to change without notice.

Owner’s Manual

AA200PHD-CE

200W Mixer Amplifier

1601 Jack McKay Blvd. • Ennis, Texas 75119 U.S.A.

Telephone: 800.876.3333 • Fax: 800.765.3435

Table of Contents

Important Safety Instructions .................................................................................................................. 3

Introduction ............................................................................................................................................ 5

Key Features ........................................................................................................................................... 5

Applications ............................................................................................................................................ 5

Front Panel Description ........................................................................................................................... 6

Rear Panel Description ............................................................................................................................ 7

PHD Diagnostic System Test ................................................................................................................. 12

Common Amplifier Failure Conditions................................................................................................... 12

Trouble Shooting the Fault LED ............................................................................................................. 13

How to Calculate Load Impedance ....................................................................................................... 13

Remote Level Control ............................................................................................................................ 15

Remote Input Select (RIS) ..................................................................................................................... 16

Wiring the AA200PHD-CE ......................................................................................................................17

Level Control Security Cover Options ...................................................................................................17

Block Diagram ....................................................................................................................................... 18

Specifications ........................................................................................................................................ 19

Warranty ................................................................................................................................................ 24

– 3 – AtlasSound.com

Specifications are subject to change without notice.

Owner’s Manual

AA200PHD-CE

200W Mixer Amplifier

1601 Jack McKay Blvd. • Ennis, Texas 75119 U.S.A.

Telephone: 800.876.3333 • Fax: 800.765.3435

Important Safety Instructions

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this device near water.

6. Clean only with dry cloth.

7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves, or other device (including amplifiers)

that produce heat.

9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the

other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your

safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they

exit from the device.

11. Only use attachments/accessories specified by the manufacturer.

12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the device. When a cart is used,

use caution when moving the cart/device combination to avoid injury from tip-over.

13. Unplug this device during lightning storms or when unused for long periods of time.

14. Refer all servicing to qualified service personnel. Servicing is required when the device has been damaged in any way, such as

power-supply cord or plug is damaged, liquid has been spilled, or objects have fallen into the device, the device has been exposed

to rain or moisture, does not operate normally, or has been dropped.

15. WARNING: To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture.

Avertissement: pour réduire le risque d’incendie ou de choc électrique, ne pas exposer cet appareil sous la pluie et l’humidité.

16. The apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such as vases, shall be placed on

apparatus.

L’appareil ne doit pas être exposé aux écoulements ou aux éclaboussures et aucun objet ne contenant de liquide, tel qu’un vase, ne

doit être placé sur l’objet.

17. The mains plug is used as a disconnect device. The mains plug of the apparatus should not be obstructed OR should be easily

accessed during intended use. To completely disconnect the power input, the mains plug of apparatus shall be disconnected from

the mains.

La prise du secteur est utilisé pour déconnecter le système. La prise du secteur ne doit pas être obstruée ou doit être facilement

accessible pendant son utilisation. Pour être complètement déconnecté de l’alimentation d’entrée, la prise doit être débranchée du

secteur.

18. This product shall be connected to a mains socket outlet with a protective earthing connection.

Cet appareil doit être connecté à une prise électrique dotée d’une mise à la terre.

The lightning flash with arrowhead symbol within an

equilateral triangle, is intended to alert the user to the

presence of uninsulated “dangerous voltage “ within the

product’s enclosure that may be of sufficient magnitude

to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is

intended to alert the user to the presence of important

operating and maintenance (servicing) instructions in the

literature accompanying the product.

Produkspesifikasjoner

Merke:	Atlas
Kategori:	Mottaker
Modell:	AA200PHD-CE
Bredde:	420 mm
Dybde:	422 mm
Høyde:	93 mm
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Strømkildetype:	AC
Volumkontroll:	Rotasjon
Impedans:	6 Ω
AC-inngangsspenning:	220 - 240 V
Diskantjustering:	Ja
Produktfarge:	Sort
inngangsimpedans:	4 Ω
Signal-til-støy-forhold (SNR):	- dB
Total Harmonic Distortion (THD):	5
Lyd-utgang kanaler:	6.0 kanaler
Formål:	Opptreden Scene
Frekvensrekkevidde:	50 - 15000 Hz
Bassjustering:	Ja
Peak effekt per kanal:	200 W
Gain-justering:	Rotasjon
