Side 1/12

– 1 – AtlasIED.com

Specifications are subject to change without notice.

Owner’s Manual

AL2450

AtlasIED Amplifier/Receiver

1601 Jack McKay Blvd. • Ennis, Texas 75119 U.S.A.

Telephone: 800.876.3333 • Fax: 800.765.3435

AL2450

Ampliﬁer/Receiver

AtlasIED.com – 2 –

Owner’s Manual

AL2450

AtlasIED Amplifier/Receiver

1601 Jack McKay Blvd. • Ennis, Texas 75119 U.S.A.

Telephone: 800.876.3333 • Fax: 800.765.3435

Table of Contents

Important Safety Instructions .................................................................................................................. 3

Introduction ............................................................................................................................................ 5

Key Features ........................................................................................................................................... 5

Applications ............................................................................................................................................ 5

Front Panel Description ........................................................................................................................... 6

Rear Panel Description ............................................................................................................................ 7

Installation ............................................................................................................................................... 8

Wiring ...................................................................................................................................................... 8

AL2450 Block Diagram ............................................................................................................................ 9

Specifications ........................................................................................................................................10

Warranty ................................................................................................................................................ 12

– 3 – AtlasIED.com

Specifications are subject to change without notice.

Owner’s Manual

AL2450

AtlasIED Amplifier/Receiver

1601 Jack McKay Blvd. • Ennis, Texas 75119 U.S.A.

Telephone: 800.876.3333 • Fax: 800.765.3435

Important Safety Instructions

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this device near water.

6. Clean only with dry cloth.

7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves, or other device that produce heat.

9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the

other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your

safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they

exit from the device.

11. Only use attachments/accessories specified by the manufacturer.

12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the device. When a cart is used,

use caution when moving the cart / device combination to avoid injury from tip-over.

13. Unplug this device during lightning storms or when unused for long periods of time.

14. Refer all servicing to qualified service personnel. Servicing is required when the device has been damaged in any way, such as

power-supply cord or plug is damaged, liquid has been spilled, or objects have fallen into the device, the device has been exposed

to rain or moisture, does not operate normally, or has been dropped.

15. This product is equipped with a three-wire grounding-type plug, a plug having a third (grounding) pin. This plug will only fit into a

grounding-type power outlet. This is a safety feature. If you are unable to insert the plug into the outlet, contact your electrician to

replace your obsolete outlet. Do not defeat the safety purpose of the grounding-type plug.

16. WARNING: To reduce the risk of fire or electric shock, this device should not be exposed to rain or moisture and objects filled with

liquids, such as a vase, should not be placed on this device.

17. To completely disconnect this equipment from the mains, disconnect the power supply cord plug from the receptacle.

18. The mains plug of the power supply cord shall remain readily operable.

19. Protective earthing terminal. The apparatus should be connected to a mains socket with a protective earthing connection.

The lightning flash with arrowhead symbol within an equilateral triangle,

is intended to alert the user to the presence of uninsulated “dangerous

voltage “ within the product’s enclosure that may be of sufficient

magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to

alert the user to the presence of important operating and maintenance

(servicing) instructions in the literature accompanying the product.

WARNING: SHOCK HAZARD - DO NOT OPEN

AVIS: RISQUE DE CHOC ELÉCTRIQUE - NE PAS OUVRIR

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK

DO NOT EXPOSE THIS EQUIPMENT TO RAIN OR MOISTURE

AVIS: NE PAS EXPOSER CE MATÉRIEL À LA PLUIE OU L’HUMIDITE

AFIN DE REDUIRE LE RISQUE D’INFLAMMATION OU DE CHOC ELÉCTRIQUE

Produkspesifikasjoner

Merke:	Atlas
Kategori:	Mottaker
Modell:	AL2450
Vekt:	3180 g
Bredde:	216 mm
Dybde:	343 mm
Høyde:	45 mm
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
Strømkildetype:	AC
Pakkevekt:	4100 g
Impedans:	8 Ω
Antall kanaler:	6 kanaler
AC-inngangsspenning:	100 - 240 V
Utgangsimpedans:	8 Ω
Produktfarge:	Sort
Pakkedybde:	353 mm
Pakkehøyde:	145 mm
Pakkebredde:	275 mm
Mikrofon, linje-inn-støpsel:	Ja
Signal-til-støy-forhold (SNR):	- dB
Av/på-bryter:	Ja
Total Harmonic Distortion (THD):	0.033
Lyd-utgang kanaler:	6.0 kanaler
Formål:	Opptreden Scene
DC inngående spenning:	24 V
Frekvensrekkevidde:	20 - 20000 Hz
Tilkoblingstype høyttalere:	RCA
Forsterker, klasse:	D
Peak effekt per kanal:	50 W
