Side 1/16

COM104/108

User Manual

www.audac.eu

ADDITIONAL INFORMATION

This manual is put together with much care, and is as complete as could be on the

publication date. However, updates on the specifications or functionality may have occurred

since publication. To obtain the latest instruction manual or obtain additional product

information, please visit the product page on www.audac.eu.

Index

Introduction 5

Precautions 6

Safety requirements 6

Caution servicing 7

EC Declaration of Conformity 7

Waste of Electrical and Electronic Equipment (WEEE) 7

Caution 7

Chapter 1: Pin connections and connectors 8

Connection standards 8

Chapter 2: Front & rear panel 9

Front panel overview 9

Front panel description 9

Rear panel overview 10

Rear panel description 10

Chapter 3: Setting up the system 11

Chapter 4: Additional information 14

Technical specifications 14

Notes 15

Produkspesifikasjoner

Merke:	Audac
Kategori:	Mottaker
Modell:	COM108
Vekt:	3000 g
Bredde:	217.5 mm
Dybde:	300 mm
Høyde:	43.7 mm
Tilkoblingsteknologi:	Koblet med ledninger (ikke trådløs)
AC-inngangsspenning:	100 - 240 V
AC-inngangsfrekvens:	50 - 60 Hz
Utgangsimpedans:	4 Ω
Produktfarge:	Sort
Driftstemperatur (T-T):	0 - 40 °C
Signal-til-støy-forhold (SNR):	90 dB
Total Harmonic Distortion (THD):	0.5
Relativ luftfuktighet under drift (H-H):	0 - 95
Lyd-utgang kanaler:	- kanaler
Frekvensrekkevidde:	20 - 20000 Hz
Forsterker, klasse:	D
Peak effekt per kanal:	80 W
Crosstalk/krysstale (1kHz):	70 dB
