Side 1/16
Zone Zone Zone 120BT / 240BT / 360BT
Please read the manual before using the product
USER´S
MANUAL
15
Zone 120 BT
Zone 240 BT
Zone 360 BT
Playe
US Typ
OTG2.0 full-speed
controlle
Connecto
USB 2.0 Type-
SD/MMC Connecto
Non-self-locking so card
slo
Bluetoot
Versio
Bluetooth Ver20+EO
Max rang
10m (without
interference
Trans
Frequencie
2402-2480MH
Music format
MP3/WAW/WMA/FLAC
(8/16/24bit
File system
FAT16 or FAT3
FM Sectio
Tuning rang
87.5MHz to 107.9MH
Antenna inpu
75 unbalance Ω
Output
Low impedanc
4 Ω
Constant Voltage impedanc
167 -Zone 60B Ω
84 -Zone 120B Ω
42 -Zone 240B Ω
28 -Zone 360B Ω
Indicato
LED
Power/Zone/Outpu
LCO
Playe
Soun
Protec
Protectio
DC-Short Circu
Over Healin
Over Loa
Limite
Cooling system
Fan coole
Amplifier technolog
Class A/
Power suppl
Maste
AC230V-240V/50-60H
Standb
DC24
Zone Zone Zone 120BT / 240BT / 360BT USER´S
MANUAL
1 14
Index
Introduction..................................................................................................................2
System Black Diagram................................................................................................2
Precautions...................................................................................................................2
Safety requirements......................................................................................................2
Caution servicing..........................................................................................................3
EC Declaration of Conformity.....................................................................................3
Caution..........................................................................................................................4
Chapter 1: Pin connections and connectors............................................................4
Connection standards.................................................................................................4
Chapter 2: Front & rear panel.....................................................................................5
Front panel overview....................................................................................................5
Front panel description.................................................................................................5
Rear panel overview.....................................................................................................8
Rear panel description.................................................................................................8
Chapter 3: Setting up the system..............................................................................10
Connection the loudspeakers...................................................................................11
Connection the audio sources..................................................................................12
Phantom power..........................................................................................................13
To start playing music form MP3................................................................................13
To start playing music via Bluetooth .........................................................................13
Chapter 4: Additional information............................................................................14
Technical specifications.............................................................................................14
ATTENTION
• Do not operate the amplifier or disconnect power cable during firmwave
update Firmware update takes about10seconds
• No files other than firmware in USB storage device or SD card.
• Do not perform this procedure unless firmware update is necessary Also make
sure you read the information supplied with updates before updating the
firmware.
Chapter 4
Additional information
Technical specifications
Powe
Zone 120B
120 Wa
Zone 240B
240 Wa
Zone 360B
360 Wa
Frequency respons
20Hz-20KH
Signal to Noise Rati
>90d
THD+
<0.5%
Common Mode Rejectio
<0.5%
Crosstal
>70d
Input
MiC1-
Typ
2x Balanced mic / Un
Sensitivit
-50d
Connecto
2xXLR/6.3mmJack comb
Phantom powe
15VDO
Priorit
Ye
LINE 1/MIG
Typ
Balanced mic/lin
Sensitivit
-50d
Connecto
XLBi6.3mm Jack comb
Priorit
YE
LINE2-
Typ
2x Stereo lin
Sensitivit
-30d
Connecto
2x RC
Chime/Fire/TE
Typ
Priority mic input
Connecto
Euro terminal block-
5.08mm
Zone Zone Zone 120BT / 240BT / 360BT USER´S
MANUAL
13 2
Introduction
Public address amplifiers
The Zone series public address amplifier was developed as an easy to use,
flexible solution for multifunctional use
During the development of the Zone series amplifiers, our engineers wanted to
achieve four goals:
-Delivering a flexible audio solution to control multiple functions
- Easy to use
-Excellent sound quality
-Modern and advanced design
The Zone series amplifiers has 2 stereo unbalanced line level inputs, 1 mono
balanced line level inputs, 2 mono balanced line level inputs with phantom
power, 4 high impedance 100V mono output zones, 1 low impedance 4ohm
mono output zone a link output a telephone signal input, a chime and fire
signal input, an 100V emergency input with 24V control, a lossless music player
with screen, including FM tuner, the model with a "+BT" version also has
bluetooth.
The Zone series amplifiers can be used in commercial applications such as
restaurants, hotels, shops, warehouses, professional offices, public buildings.….
A simple example: when installed in a shop you could connect a tuner to play
your favorite radio station, microphone to make announcements, a telephone
pager. and off course the doorbell of the shop.
Precautions
READ FOLLOWINGINSTRUCTIONS FOR YOUR OWN SAFETY
ALWAYS KEEP THESE INSTRUCTIONS NEVER THROW THEM AWAY
ALWAYS HANDLE THIS UNIT WITH CARE
HEED ALL WARNINGS
FOLLOW ALLINSTRUCTIONS
NEVER EXPOSE THIS EQUIPMENT TO RAINMOISTUREANY DRIPPING ORSPLASHING
LIQUID.AND NEVER PLACE AN OBJECT FILLED WITH LIQUID ON TOP OF THIS
DEVICE
3)Phantom power
MlC input 1&2contain the possibility for supplying 15Volts phantom power for
powering condenser microphones. Enabling of the phantom power can be
done by the switches located between MIC 1&2 connections. Switch 2 will
enable phantom power to Mic input 1while switch 1 enables phantom power
to Mic input 2.
4)To start playing music form MP3
Insert a USB storage device or SD/MMC memory card to the slots on front of the
device. The MP3 player can play such as MP3WMAWAVFLAC. AAC audio
formats When the media is inserted the device will detect automatically and
will start playing You can select the playing tracks using the control buttons on
front of the device. For switching to settings of another media source, press the
M button on front (The variable audio output will switch automatically to this
media source)
5)To start playing music via Bluetooth
Adjust the bluetooth antenna to a vertical position then press the M button on
front to switch the operation mode to Bluetooth. Turn on the bluetooth on your
device(phone computer, Ipad, mace or other music playback devices with
bluetooth) and search for bluetooth device, you’ll find a device named
“ ”Bluetooth" in the list, select and connect it. Then you can
play music on your device. pressing the to control the music track previous,
next or pause.
6)Update the player's firmware
New firmware that provides additional features or product improvements will
be released as needed. You can download the type MVA of firmware from our
website.
Format the USB storage device or SD card for upgrade firs. Insert a USB storage
device or SD card with firmware on the front if the player detects firmware, it
will automatically extinguish the LCD screen and start to upgrade the firmware,
it will restart about 10 seconds later.
