OWNER’S MANUAL
AD508
AudioSource®
13970 SW 72nd Ave
Portland, OR 97223
503.914.4688
www.audiosource.net
AD508 Owner’s Manual 30117
Congra ula ion on our purcha he udio ource D508t t s y se of t A S ® A .
Please take a few moments to read this entire manual, and be sure to
retain this document for future reference. Please read and observe all
safety instructions detailed on page 2.
NOTE: If any par hit of t s produc ist damaged or mi ing ss , please call ou y r
dealer or udio ource dire ly 877 715 5439 or 503 914 468 A S ® ct a 1.t . . . . 8.
P se t tonlea read your warran andty re ain your receip andt original car
for possible future use.
F f t S ce k andor more in orma ion about Audio our ® ctele ronics, spea ers
accessories please visit www.audiosource.net
FEATURES:
SPECIFICATIONS
Stereo (8 ohm): 8 x 65 per channel 2% HDW , <0. T +N
Stereo (4 ohm): 8 x 100 per channel 2% HDW , <0. T +N
Bridged Mono (8 ohm): 200W, 1kHz, <0.2% THD+N
Frequency Response: 20Hz ~ 20kHz, +/-0dB
Signal to Noise Ratio:
100dB below 65W output into 8 ohms
w/20kHz lowpass filter/A-Wgt
Channel Separation: 65dB @ 1kHz, referred to 65W output
into 8 ohms
Input Sensitivity: Variable, 430mV for full output with
Input Level control at maximum
AC Power Consumption: 1000W maximum
Net Weight: 32.4lbs / 14.7kgs
Gross Weight: 37.4lbs / 17kgs
Digital Multi-Zone Power Amplifier
AD508
8 Channels (4 stereo zones)
8 Rear mounted level controls
8 Independent inputs, 2 Bus inputs, 1 optical input
Bus 1 and Bus 2 master level controls
Multi-function IR remote control
Normal, signal sensing, and trigger power modes
Rear mounted treble and bass controls for bus 1 & 2
Phoenix-style speaker connectors
LED status indicator lights
Bridgeable channel outputs
Rack mountable (rack mount included)
4.0”
(102mm)
16.63” (423mm)
14.75”
(375mm)
MULTI-ZONE POWER AMPLIFIER
AD5012
Input:
120/230V~, 60/50Hz, 800W
