USER’S
MANUAL
rev. 1.5 e
Update for:
• bit One.1
• Pc Software 1.5
• bit One Firmware 1.5.0.0
• DRC Firmware 1.50
• Accessories: SFC / DRC cable extension Kit
• Instruction for Windows XP, Vista, 7, 8, 8.1, 10 installation
2
USER’S MANUAL
bit One /
Index
1. PRODUCT DESCRIPTION .............................................................................................................................................3
2. PACKAGING CONTENTS ..............................................................................................................................................3
3. BIT ONE and DRC INSTALLATION .............................................................................................................................4
4. CONNECTION PANELS - DESCRIPTION ...................................................................................................................5
4.1 Input Signals ..........................................................................................................................................................5
4.2 Output Signal .........................................................................................................................................................6
4.3 Inputs - remote control outputs and power supply ....................................................................................... 6
5. CONNECTIONS ...............................................................................................................................................................7
5.1 Power supply and remote turn on ..................................................................................................................... 7
5.2 How to turn on/off the bit One ...........................................................................................................................7
5.3 Personal computer and Digital Remote Control (DRC) .................................................................................7
5.4 Low Level and Digital input signals ...................................................................................................................8
5.5 High Level input signals ......................................................................................................................................9
5.6 Output Signals .....................................................................................................................................................10
6. BIT ONE SOFTWARE AND DRIVERS - INSTALLATION GUIDE ..........................................................................11
6.1 Software installation guide ...............................................................................................................................11
6.2 Ac-Link drivers installation on Windows XP, Vista, 7 ..................................................................................13
6.3 Ac-Link drivers installation on Windows 8, 8.1, 10 ......................................................................................17
6.4 Troubleshooting section for software installation .......................................................................................24
7. BIT ONE SOFTWARE AND DRIVERS UNINSTALLATION GUIDE........................................................................25
7.1 bit One software uninstall .................................................................................................................................25
7.2 How to uninstall the Ac-Link drivers with Windows XP ..............................................................................25
7.3 How to uninstall the Ac-Link drivers with Windows Vista .......................................................................... 26
7.4 How to uninstall the Ac-Link drivers with Windows 7 ................................................................................. 27
7.5 How to uninstall the Ac-Link drivers with Windows 8, 8.1, 10 ................................................................... 28
8. HOW TO CONNECT THE BIT ONE TO THE PC .......................................................................................................29
8.1 OFFLINE mode ....................................................................................................................................................29
8.2 Starting up the bit One software in TARGET mode - warnings ................................................................. 30
8.3 TARGET mode .....................................................................................................................................................30
8.4 Selecting the MASTER mode Low Level inputs ........................................................................................... 31
8.5 Selecting the MASTER mode High Level inputs ...........................................................................................35
9. HOW TO SETUP THE BIT ONE WITH THE PC ........................................................................................................38
9.1 Features ................................................................................................................................................................38
9.2 Main menu File ....................................................................................................................................................39
9.3 Main menu Config ..............................................................................................................................................40
9.4 Channel Map ........................................................................................................................................................41
9.5 Select a Channel .................................................................................................................................................42
9.6 Filter Settings .......................................................................................................................................................43
9.7 Display and Settings ..........................................................................................................................................45
9.8 Selected Input .....................................................................................................................................................45
9.9 Ext. Source EQ .....................................................................................................................................................46
9.10 Set Distance and Delay ...................................................................................................................................... 48
9.11 Output Level .........................................................................................................................................................50
9.12 Grafic Equalizer ...................................................................................................................................................51
9.13 Dynamic Equalization Wizard ........................................................................................................................... 52
9.14 Memory .................................................................................................................................................................54
10. TROUBLESHOOTING ...................................................................................................................................................55
10.1 Synchronization with the PC ............................................................................................................................55
10.2 Background noise ...............................................................................................................................................55
10.3 Firmware upgrade - Rescue Mode ..................................................................................................................55
11. STARTING UP THE BIT ONE SOFTWARE IN TARGET MODE IN FINALIZED BIT ONES ................................ 59
12. DRC - DIGITAL REMOTE CONTROL .........................................................................................................................60
12.1 Phone Call ............................................................................................................................................................61
12.2 SEL button - function .........................................................................................................................................61
12.3 Bypassing the DRC .............................................................................................................................................62
12.4 Upgrade Firmware DRC ..................................................................................................................................... 62
13. ACCESSORIES ..............................................................................................................................................................65
13.1 SFC.........................................................................................................................................................................65
13.2 DRC cable extension kit ..................................................................................................................................... 66
14. TECHNICAL SPECIFICATIONS ..................................................................................................................................67
3
USER’S MANUAL
bit One /
- bit One - Signal Interface Processor
- DRC (Digital Remote Control) Control Panel
- Printed Quick Start Guide
- 5.0 m / 196,85” AC Link (RJ-12) cable
- 5.0 m / 196,85” AD Link (LAN class 5S - RJ45) cable
- 3.0 m / 118,11” USB cable
-N.44.2x38mmself-tapping,crossheadxingscrews
- 4.5 m / 177,16” DRC / ACLink cable
-N.2xingbracketswith2.9x6.5mm
self-tapping, cross head screws
- CD ROM with:
bit One Software
USB-ACNet drivers
This Advanced Manual (.pdf format)
Test tracks
- DVD comprising:
Test tracks encoded with Dolby Digital 5.1
1. PRODUCT DESCRIPTION
bit One is a signal digital processor essential to maximize the acoustic performance of your Car Audio system.
It consists of a 32 bit DSP processor and 24 bit AD and DA converters.
It can be interfaced with any factory system, even in vehicles featuring an integrated audio processor, since, thanks
to the de-equalization function, the bit One will send back a linearized signal.
The bit One features 21 signal inputs; 8 Hi-Level, 1 Phone, 6 Low-Level, 4 Aux, 1 Optical Digital, 1 Coax Digital.
It provides 8 PRE OUT analog or digital outputs.
Each output channel has a 32 band equalizer available. It also features a 66 frequency steps electronic crossover
aswellasBUTTERWORTHorLINKWITZlterswith6-48dBslopes;adigitaltimedelaylinealongwithanequalizer
on each auxiliary input are also available. The user can select adjustments that will allow him to interract with the
bit One trough the remote controll device called DRC.
WARNING: a PC provided with Windows XP, Vista, 7, 8, 8.1 or 10 operating system, 1.5 GHz minimum processor
