Side 1/60
USER’S
MANUAL
rev. 2.0a
Valid for any of the below software versions
or above:
• Control Firmware 2.0
• Media Firmware 2.0
• Android APP. 2.0
• IOS APP 2.0
2
USER’S MANUAL
bit Play HD /
Index
1. bit Play HD - bit Play HD SSD DESCRIPTION ......................................................................................................................3
1.1 SAFETY CONSIDERATIONS ................................................................................................................................................3
1.2 PACKAGING CONTENT ........................................................................................................................................................4
1.3 DIMENSIONS AND FASTENING .........................................................................................................................................5
2. DESCRIPTION OF THE CONNECTION PANELS ..................................................................................................................6
3. REMOTE DESCRIPTION ............................................................................................................................................................9
3.1 ARC (Advance Remote Control) REMOTE ........................................................................................................................9
3.2 USR (User Remote Control) REMOTE ............................................................................................................................ 10
3.3 DRC MP Remote control (optional) ................................................................................................................................11
3.3.1 NAVI COMMAND ...................................................................................................................................................... 11
3.3.2 BIT PLAY HD SETTINGS ......................................................................................................................................... 11
4 CONNECTIONS ......................................................................................................................................................................... 12
4.1 POWER SUPPLY AND REMOTE CONTROL ................................................................................................................... 12
4.2 AUDIO OUTPUT SIGNALS ................................................................................................................................................ 13
4.2.1 ANALOG OUTPUT SIGNALS ................................................................................................................................... 13
4.2.2 S/PDIF DIGITAL OUTPUT SIGNALS ..................................................................................................................... 14
4.2.3 S/PDIF DIGITAL OUTPUT SIGNALS WITH HI-DEFINITION VOLUME CONTROL ........................................ 15
4.2.4 HOW TO CONNECT THE bit Play HD TO THE AUDISON bit DMI .................................................................... 16
4.3 VIDEO OUTPUT SIGNALS ................................................................................................................................................. 17
4.3.1 COMPOSITE VIDEO SIGNAL ................................................................................................................................... 17
4.3.2 HDMI VIDEO SIGNAL .............................................................................................................................................. 17
4.4 AUX/OPTICAL INPUT AUTO SWITCH ........................................................................................................................... 18
4.5 STORAGE DEVICES/EXTERNAL FILE READING ......................................................................................................... 20
4.6 INFRARED RECEIVER ........................................................................................................................................................ 21
4.7 Wi-Fi AND MOBILE DEVICES .......................................................................................................................................... 21
5 HOW TO USE THE bit Play HD WITH AN EXTERNAL MONITOR ................................................................................. 22
6 HOW TO USE THE bit Play HD ON MOBILE DEVICES .................................................................................................... 24
6.1 ANDROID DEVICES ............................................................................................................................................................24
6.1.1 DOWNLOAD THE AUDISON bit Play HD APP from PLAY STORE ................................................................... 24
6.1.2 ANDROID DEVICES SETUP ..................................................................................................................................... 25
6.1.3 AUDISON APP FOR ANDROID ................................................................................................................................ 33
6.2 APPLE IOS DEVICES .......................................................................................................................................................... 38
6.2.1 DOWNLOAD THE AUDISON bit Play HD APP from APP STORE ..................................................................... 38
6.2.2 Apple DEVICES SETUP ............................................................................................................................................ 38
6.2.3 AUDISON APP FOR IOS ........................................................................................................................................... 42
6.2.4 AIRPLAY ..................................................................................................................................................................... 47
7 MAIN SYSTEM SETTINGS ..................................................................................................................................................... 48
7.1 INTERNAL HDD INSTALLATION...................................................................................................................................... 48
7.1.1 INTERNAL HDD FORMAT ....................................................................................................................................... 49
7.2 EXTERNAL MONITOR GRAPHIC RESOLUTION ........................................................................................................... 50
7.3 SELECT SYSTEM LANGUAGE .......................................................................................................................................... 51
7.4 SELECT AUDIO/VIDEO LANGUAGE ................................................................................................................................ 51
7.5 RESTORING FACTORY SETTINGS .................................................................................................................................. 52
8 TROUBLESHOOTING .............................................................................................................................................................. 53
8.1 MEDIA FIRMWARE UPGRADE ......................................................................................................................................... 53
8.2 CONTROL FIRMWARE UPGRADE ................................................................................................................................... 53
8.3 FAQ ...................................................................................................................................................................................... 55
9 TECHNICAL SPECIFICATIONS ............................................................................................................................................. 59
3
1. BIT PLAY HD - BIT PLAY HD SSD DESCRIPTION
1. For the safety of the driver and third parties, the driver should not watch any video and/or operate the controls of
the device while driving. While driving, we also recommend to adjust the volume to a level that allows you to hear
sounds from outside the vehicle. The law prohibits the display and use of video while driving. For this reason, the
unit is equipped with a function that inhibits the viewing of such content, unless the car is parked and the parking
brake is engaged (see sections 2.1 and 4.3). We accept no responsibility if you choose to ignore this warning and
do not install the product correctly to inhibit video content while in motion.
2. Operate the bit Play HD only when the internal temperature is between 0°C (32°F) and 55°C (131°F). The bit Play HD
must be a minimum of 3 cm (1.5”) from other structures and there must be good air circulation around the chassis.
3. Make sure your car has a 12VDC negative ground.
4. Make sure the location you choose for the product and its accessories does not affect the vehicle’s other mechanical
and electrical devices.
5. Make sure the power cable does not short circuit during installation and connection.
6. Use extreme caution when cutting or drilling the car chassis, checking that there is no electrical wiring or structural
elements underneath.
7. Use rubber grommets to protect wires running through holes in metal and use proper materials if close to
heat-generating devices.
8. Make sure all the cables are properly secured along their entire length. Also, make sure their outer protective jacket
is flame resistant and self-extinguishing. Secure the wiring near the terminals.
SAFE SOUND
Use common sense while listening; long exposure to excessive sound levels may damage your hearing. Safety while
driving must always come rst.
1.1 SAFETY CONSIDERATIONS
USER’S MANUAL
bit Play HD /
1
