Reflection Filter
with Gooseneck
RF-GN-10
Owner’s Manual
This AURAY product is warranted to the original purchaser to be free
from defects in materials and workmanship under normal consumer use
for a period of one (1) year from the original purchase date or thirty (30)
days after replacement, whichever occurs later. The warranty provider’s
responsibility with respect to this limited warranty shall be limited solely to
repair or replacement, at the provider’s discretion, of any product that fails
during normal use of this product in its intended manner and in its intended
environment. Inoperability of the product or part(s) shall be determined by
the warranty provider. If the product has been discontinued, the warranty
provider reserves the right to replace it with a model of equivalent quality
and function.
This warranty does not cover damage or defect caused by misuse, neglect,
accident, alteration, abuse, improper installation or maintenance. EXCEPT
AS PROVIDED HEREIN, THE WARRANTY PROVIDER MAKES NEITHER ANY
EXPRESS WARRANTIES NOR ANY IMPLIED WARRANTIES, INCLUDING
BUT NOT LIMITED TO ANY IMPLIED WARRANTY OF MERCHANTABILITY
OR FITNESS FOR A PARTICULAR PURPOSE. This warranty provides you
with specific legal rights, and you may also have additional rights that vary
from state to state.
To obtain warranty coverage, contact the Auray Customer Service
Department to obtain a return merchandise authorization (“RMA”) number,
and return the defective product to Auray along with the RMA number and
proof of purchase. Shipment of the defective product is at the purchaser’s
own risk and expense.
For more information or to arrange service, visit www.aurayaudio.com or
call Customer Service at 212-594-2353.
Product warranty provided by the Gradus Group.
www.gradusgroup.com
AURAY is a registered trademark of the Gradus Group. © 2014 Gradus Group LLC. All Rights Reserved.
One-Year Limited Warranty
GG1
65 RF-GN-10RF-GN-10 Owner’s ManualOwner’s Manual
• Pleasereadandfollowtheseinstructions,andkeepthis
manual in a safe place.
• Makesurethatthisproductisintactandthatthereare
no missing parts.
• Donotattempttodisassembleorrepairthe
equipment—doing so will void the warranty, and Auray
will not be responsible for any damage.
• Handletheunitwithcare.
• Makesureeverythingissecurebeforeproceeding.
• Allphotosareforillustrativepurposesonly.
!
Warnings
Introduction
Thank you for choosing Auray.
Congratulations on your purchase of the Auray RF-GN-10
Reflection Filter with Gooseneck.
Designed for use in studios, acoustically untreated rooms, and
desktop recording, the RF-GN-10 absorbs and diuses external
noise and acoustic reflections to improve the quality of both
vocal and instrumental tracks. It attaches directly onto a mic
stand and, set behind the microphone, provides isolation when
recording vocals, drums, pianos, or practically any acoustic
instrument.
The RF-GN-10’s ten-inch profile allows it to fit into tight spaces
where large reflection filters are impractical. The filter features
high-density acoustic foam for attenuating room ambience
and a perforated aluminum shield that prevents sound from
reflecting back into the microphone. The heavy-duty, 1/2”
gooseneck provides precise positioning of the filter to achieve
optimum results, further ensuring a dry and close sound that
provides cleaner tracks. A high-quality metal alloy design
makes the RF-GN-10 a sturdy, lightweight, and portable asset in
any studio.
Filter
1
Threaded socket
2
Threaded mount
3
Lock nut
4
Gooseneck
5
Clamp
6
Tightening screw
7
Overview
1
5
6
2
3
4
7
Instructions
Setting up the RF-GN-10
1. First, set up your microphone by
placing it into the shock mount
or mic clip and adjusting the
mic stand to the desired height.
1
2. Attach the gooseneck to
the filter by screwing the
gooseneck’s threaded post into
the threaded socket of the filter
until it is tight.
2
3. Loosen the tightening screw
on the gooseneck, and fit the
clamp onto the shaft of the mic
stand, or the boom arm of the
mic stand. Tighten the screw
until the RF-GN-10 is securely in
place.
3
4. Position the shield so that it is
directly behind the microphone.
Adjust the distance between
the filter and microphone for
optimum results.
4
3
4
1
2
432 RF-GN-10RF-GN-10RF-GN-10 Owner’s ManualOwner’s ManualOwner’s Manual
Specifications
Shield Dimensions (H × W × D): 12" × 10.39" × 2.95" (30.5 × 26.4 × 7.5 cm)
Weight: 2.15 lb. (0.97 kg)
