Side 1/16
www.AvantcoEquipment.com 1
Gear Driven 60 Qt. Comm ial Mixererc
Mod s: el MX60
Please read and keep thes nstructe i ions. Indoor use only.
Shifting gears while this it isun
r ng w l v d warranty.unni il oi
02/2022
User Manual
User Manual
2 w.AvantcoEquipment.comww
Index
Stan rd Ada ccessor s .................................................... 3ie
Operation In ructions .................................................. 3st
Mixer Capacity C rt ..................................................... 4ha
Figure 1: Top Cover and Hand Cart ............................... 5
Figure 2: Center Axle ..................................................... 6
Figure 3: Gear Axle ........................................................ 7
Figure 4: Motor ............................................................... 8
Figure 5: Fork ................................................................. 9
Figure 6: Speed Block ................................................. 10
Figure 7: Bowl Lifter Unit ............................................. 11
Figure 8: Turning Plate and M ing Axle ..................... 12ix
Figure 9: Electro tion Type Bowl Lifter Unit ........... 13mo
Three P se Motor Diagram ........................................ 14ha
Troubl hooting ........................................................... 15es
User Manual
www.AvantcoEquipment.com 3
Standard Accessories
Item Description Qty
1 Flat Beater 1
2 1 Dough Hook
3 1 Wire Whip
4 1 Bowl
NOTES:
• Any agitator is easily installed by simply raising it onto the mixing axle, and the rotating it clockwise on the shaft
until it locks into place. To remove, raise the agitator on the shaft until it clears the lock and then rotate counter-
clockwise and lower.
• All of the accessories are precisely fitted to the bowl, have rounded corners, and are easily removed for cleaning.
Unpacking the Equipment
and Initial Setup
Carefully remove crating or packaging materials from the equipment. Models shipped on pallets are bolted to the pallet.
Bolts must be removed to safely separate the equipment from the pallet. Place the equipment on a flat surface with
sufficient space around the mixer to allow for safe cleaning and service.
This product must be hardwired; it does not plug into a standard wall outlet. Have a licensed electrician connect the
unit to the power supply.
INSTALLATION:
1. Read this manual in its entirety prior to installation and operation. DO NOT install if you do not understand everything
in this manual.
2. Select a location for the mixer keeping in mind that:
• Surface must be level
• Location should be accessible for maintenance and service
• Location should offer adequate clearance for installing and removing agitators, bowls or attachments
• Location offers sufficient space for adding ingredients to the mixer
• Make sure that the rear ventilation outlet of the mixer is not blocked
