Side 1/10
ENABLING BRIGHT OUTCOMES
Safety manual
SP4K-27BHC, SP4K-35B, SP4K-40B, SP4K-55B
SP4K-B
Barco NV
Beneluxpark 21, 8500 Kortrijk, Belgium
Registered office: Barco Visual (Beijing) Electronics Co., Ltd.
No. 16 Changsheng Road, Zhong Guan Cun Science Park, Chang Ping District, 102200 Beijing
注册办事处 巴可伟视（北京）电子有限公司:
北京市昌平区中关村科技园区昌平园昌盛路 号邮政编码：16 102200
3R5912127 /05 SP4K-B
1 Safety
1.1 General considerations ....... ....... ....... ....... ....... ....... ...... 3
1.2 Important safety instructions ....... ....... ....... ....... ....... ....... 3
1.3 Product safety labels..... ....... ....... ....... ....... ....... ....... .... 5
1.4 High Brightness precautions: Hazard Distance .......... ....... .... 6
1.5 HD for fully enclosed projection systems ....... ....... ....... ....... 7
1.6 HD in function of modifying optics ........ ....... ....... ....... ....... 7
1.7 HD calculation of multi-projector stacks. ...... ....... ......... ....... 7
1.8 Compliance .............................................................8
1.9 Download Product Manual . ....... ....... ...... ....... ....... ....... .. 8
About this document
Read this document attentively. It contains important information to
prevent personal injury while installing and using the SP4K-B projector.
Furthermore, it includes several cautions to prevent damage to the SP4K-
B projector. Ensure that you understand and follow all safety guidelines,
safety instructions and warnings mentioned in this chapter before
installing the SP4K-B projector.
Clarification of the term “SP4K-B” used in this
document
When referring in this document to the term “SP4K-B” means that the
content is applicable for following Barco products:
• SP4K-27BHC, SP4K-35B, SP4K-40B, SP4K-55B
Model certification name
• SP4K-B
Barco provides a guarantee relating to perfect manufacturing
as part of the legally stipulated terms of guarantee. Observing
the specification mentioned in this chapter is critical for
projector performance. Neglecting this can result in loss of
warranty.
1.1 General considerations
General safety instructions
• Before operating this equipment please read this manual thoroughly
and retain it for future reference.
• All warnings on the projector and in the documentation manuals must
be adhered to.
• Installation and preliminary adjustments must be performed by
qualified Barco personnel or by authorized Barco service dealers.
• This product contains no user serviceable parts. Attempts to modify/
replace mechanics or electronics inside the housing or compartments
will violate any warranties and may be hazardous.
• All instructions for operating and use of this equipment must be
followed precisely.
• All local installation codes must be adhered to.
Notice on safety
This equipment is built in accordance with the requirements of the
applicable international safety standards. These safety standards impose
important requirements on the use of safety critical components, materials
and insulation, in order to protect the user or operator against risk of
electric shock and energy hazard and having access to live parts. Safety
standards also impose limits to the internal and external temperature
rises, radiation levels, mechanical stability and strength, enclosure
construction and protection against the risk of fire. Simulated single fault
condition testing ensures the safety of the equipment to the user even
when the equipment's normal operation fails.
Notice on optical radiation
This projector embeds a light source incorporating high brightness lasers.
The laser light is processed through the projector's optical path. Native
laser light is not accessible by the end user in any use case. The light
exiting the projection lens has been diffused within the optical path,
representing a larger source and lower brightness than native laser light.
Nevertheless the projected light can represent a significant risk for the
human eye and skin when exposed directly within the beam. This risk is
not specifically related to the characteristics of laser light but solely to the
high thermal induced energy of the light source, which is equivalent with
lamp based systems. Thermal eye injury is possible when exposed within
the Hazard Distance (HD). The HD is defined from the projection lens
surface towards the position of the projected beam where the intensity
equals the maximum permissible exposure as described in the chapter
“Hazard Distance”.
This projector is classified as a laser product under IEC 60825-1: 2014,
EN 60825-1:2014 +A11:2021. The projector, in particular the projection
beam, is classified as a Risk Group (RG) under IEC EN 62471-5:2015.
WARNING: This projector has a built-in Class 4 laser module.
Never attempt to disassemble or modify the laser module.
Service only allowed by qualified service personnel.
WARNING: No direct exposure to the projection beam within
the hazard distance shall be permitted for RG3 (Risk Group
3) IEC EN 62471-5:2015. Do not stare into the beam for RG2
(Risk Group 2) IEC EN 62471-5:2015.
CAUTION: Use of controls or adjustments or performance of
procedures other than those specified herein may result in
hazardous radiation exposure.
Optical radiation safety precautions
This projector is classified as CLASS 1 LASER PRODUCT - RISK
GROUP 3.
Users definition
These projectors are intended “FOR PROFESSIONAL USE ONLY”, this
means installation can only be carried out by trained and authorized
persons.
Throughout this manual, the terms SERVICE PERSONNEL, INSTALLER
refers to persons having appropriate technical training and experience
necessary to be knowledgeable of potential hazards to which they are
exposed (including, but not limited to HIGH VOLTAGE ELECTRIC and
ELECTRONIC CIRCUITRY, HIGH TEMPERATURES and HIGH
BRIGHTNESS SOURCES) in performing a task, and of measures to
minimize the potential risks to themselves or other persons.
The term USER or OPERATOR of RG2 projectors refers to any other
person than SERVICE PERSONNEL or INSTALLER. The term USER or
OPERATOR of RG3 projectors refers to any person trained and
authorized to operate professional RG3 projectors. The USER or
OPERATOR may only perform the maintenance tasks set forth in the user
manual or the maintenance tasks for which they are trained and
authorized. All other maintenance tasks and service tasks must be
performed by qualified SERVICE PERSONNEL.
Intended use
This projector is intended for use in a cinema environment. Cinema
theaters are designed to establish unobstructed light projection towards
the screen, avoiding beam path intrusion by audience.
1.2 Important safety instructions
To prevent the risk of electrical shock
• This projector should be operated from an AC power source. Ensure
that the mains voltage and capacity matches the projector electrical
ratings. If you are unable to install the AC power requirements, contact
your electrician. Do not defeat the purpose of the grounding.
• Installation should be done according to the local electrical code and
regulations by qualified technical personnel only.
• This product is equipped with a 5-terminal barrier strip for the
connection of a power line. The projector can run on one of the
following configurations, depending on what power system is available:
- A 3W+N+PE power system (Y configuration).
- A 3W+PE power system (Δ configuration).
- A mono phase system with power line with a separate earth ground
PE.
If you are unable to install the AC power requirements, contact your
electrician. Do not defeat the purpose of the grounding.
• This product is equipped with a 2-terminal barrier strip for the
connection of a UPS power cord (2-pole, 3-wire grounding).
• The electronics of the projector (UPS INLET) must be powered from a
suitable UPS unit. The building has to be provided with a circuit
breaker of max 16A to protect the UPS.
• The building installation has to be provided with a circuit breaker of
max 40A to protect the complete unit.
Safety
