THANK YOU FOR BUYING A BAUKNECHT PRODUCT.
In order to receive a more complete assistance,
pleaseregister your product on
www.register10.eu
Policies, standard documentation, ordering of spare parts and additional product information can be found by:
• Using QR code in your appliance
• Visiting our website docs.bauknecht.eu and parts-selfservice.europeanappliances.com
• Alternatively, contact our After-sales Service (See phone number in the warranty booklet). When contacting our After-sales
Service, please state the codes provided on your product's identi cation plate.
You can nd more information about your model online at https://eprel.ec.europa.eu/ which is the o cial EU EPREL product database.
After selecting the Product Category, enter the Model Identi er of the product. The Model Identi er is made up of letters and numbers
and can be found on the identi cation plate, as Mod. (see image on the right).
Policies, standard documentation, ordering of spare parts and additional product information can be found by:
• Using QR code in your appliance
• Visiting our website docs.emeaappliance-docs.eu
• Alternatively, contact our After-sales Service (Using QR code in your appliance). When contacting our After-sales Service, please
state the codes provided on your product's identi cation plate.
EN
Before using the appliance carefully
read the Safety Instruction.
PLEASE SCAN THE QR CODE ON YOUR APPLIANCE IN ORDER TO REACH MORE INFORMATION.
Quick guide
Before using the appliance carefully
read the Safety Instruction.
DAILY USE
Doing this will keep your machine working at its BEST:
- remember to empty your water tank after each drying
cycle.
- remember to clean your lters after each drying cycle.
Refer to the Care & Maintenance section.
1. Plug the dryer into the power supply socket.
2. Open the door and load garments; always refer to instructions on
clothing labels and the max loads indicated in the programme
section. Empty pockets. Make sure garments do not get caught
between the door and/or the door lter. Do not load items that
are dripping wet. Do not tumble dry large, very bulky items. For
optimal drying result, garments should be loaded one by one.
3. Close the door.
4. Press the "On/O" button.
5. Select the most suitable programme
for the type of fabric in
that load.
6. Select the options, if necessary.
7. Press the "
Start/Pause"
button to begin drying.
8. At the end of the drying cycle, a buzzer will beep. An indicator on
the control panel signals the end of the cycle. Turn the machine
o by pressing the "On/O" button, open the door and pull the
clothing immediately out to prevent the formation of creases on
laundry.
If the machine is not switched o manually, after about a quarter
of an hour from the end of the cycle , the appliance turns o
automatically to save energy.
Note that some programme/option accords with "Crease Care"
system. This means that for some hours, after the end of the
drying cycle, the drum rotates at regular intervals to prevent the
formation of creases.
Note that some models perform a nal cool tumble phase, for this
reason the fabrics may not feel hot.
CARE LABEL
Always check the care labels, especially when placing garments in
the tumble dryer for the rst time. Below are the most commonly
used symbols:
May be tumble dried.
Do not tumble dry.
Tumble dry – high heat.
Tumble dry – low heat.
In case of power failure, it is necessary to press the "Start/Pause" button
to restart the cycle.
Opening the door during the cycle
The tumble dryer door can be opened at any time during the cycle
to check progress and remove any garments already dry.
However, since opening the door can extend the drying time, the
recommendation is to keep the door closed throughout the cycle
process to save time and energy.
After closing the door, press the "Start/Pause" button within 15
minutes to resume the machine operation.
FIRST TIME USE
Make sure that the water tank is correctly inserted. Make sure
that the drain hose on the back of the dryer is xed correctly,
either to the dryer’s water tank, or to your domestic drainage
system. The dryer must be installed in a room with a
temperature ranging between 5°C and 35°C to ensure proper
operation. Before using the dryer make sure it has been in an
upright position for at least 6 hours.
Should you wish to change the opening side of the door,
please contact our After-sales Service. (See phone number in
the warranty booklet).
3 “
“
3 “
“
END
END
1
3
2
4
10
8
9
5 67
D
D
E
E
M
M
O
O
h
h
h
CONTROL PANEL
1 ON/OFF Button (hold for Reset)
2 Programme Selection Knob
3 Start/Pause
Options Buttons*
4 Crease Care
5 Dryness Level
6 Start Delay
7 Timed Drying
8 Cycle End
9 Gentle (hold for Key Lock)
10 Rapid (hold for Mute)
*Note: some models may have the wording in full instead of the icons.
INDICATORS
Dryness Level: Iron Dry - Hanger Dry - Cupboard Dry - Extra Dry
Cycle Phase: Drying - Cool Down - END End of Cycle
Empty water tank - Clean door lter - Clean bottom lter
Refer to troubleshooting section: Failure: Call after sales service
*MAX LOAD 8 Kg (Dry load)
OPTIONS
These buttons allow you to personalise the selected programme
according to personal requirements.
Not all options are available for all programmes. Some options
may be incompatible with ones you have previously set; if so,
you will be alerted by the buzzer and/or blinking indicators.
If the option is available, the option indicator will stay on. The
programme may retain some options selected in previous drying
cycles.
Dryness Level
Press the relevant button several times to obtain a dierent
level of residual moisture on your laundry. An indicator signals the
level being selected.
Iron Dry: very delicate drying. Items will be more easily
ironed immediately after the cycle.
Hanger Dry: a level intended for delicate garments ready to
be hanged.
Cupboard Dry: the laundry is ready to be folded and put
away.
Extra Dry: for laundry intended to be worn at the end of the
cycle.
h
Start Delay
This option is for delaying the start of the cycle. Press the
corresponding button several times to nd the required delay.
Once the max time is reached, the option is reset by pressing
the button again. An indicator on the control panel signals the
time being selected. After pressing the "Start/Pause" button, the
machine signals the time remaining to the start of the cycle. If the
door is opened, press the "Start/Pause" button once the door has
been closed.
Timed Drying
This option is to manually set the drying time. Press the
corresponding button to set the required time for drying. An
indicator on the control panel signals the time being selected.
Cycle End
This option activates a prolonged buzzer at the end of the
cycle. Enable it if you do not think you will hear the normal sound
at the end of the cycle. This option remains in memory, if selected
in previous drying.
Gentle
Enables a more gentle treatment of the laundry by reducing the
drying temperature.
Key Lock
This option makes all machine controls inaccesible, except the
"On/O" button. When the machine is on:
• to activate the option, keep the button pressed until the
machines signals that the option has been enabled.
• to disable the option, keep the button pressed until the machine
signals that the option has been disabled.
This option remains in memory if selected in previous drying.
Crease Care
This option add a crease treatment at the end of the cycle by
means of a periodic rotation of the drum (duration up to 10 hours).
It is particularly suitable when it is not possible to remove the
laundry as soon as the drying ends. If this option is used together
with the Start Delay, the crease treatment is added also in the Start
Delay phase. This option remains in memory if selected in the
previous drying.
Mute
This option turns o all sounds of control panel. Only
warnings remain active. When the machine is on:
• to activate the option, keep the button pressed until the machine
signals that the option has been enabled.
• to disable the option, keep the button pressed until the machine
signals that the option has been disabled.
Rapid
Enables quicker drying.
PROGRAMS
The duration of these programs will depend on the size of the
load, types of textiles, the spin speed used in your washer and
any extra options selected. In machines equipped with display,
the duration of the cycles is shown on the control panel. The
remaining time is constantly checked and adjusted during the
drying cycle to show the best possible estimate.
Option to use - If all your loads on Automatic Cycles are
consistently less dry or more dry than you would like, you may
increase or decrease the dryness level using the specic option.
Mixed kg 4
This programme is ideal for drying cotton and synthetic fabrics
together.
Eco kg Max*
This is the most ecient programme in terms of energy
consumption and is suitable for drying normal wet cotton
laundry. The values on the Energy Label are based on this
programme.
NOTE: For optimal energy eciency this cycle by default is set up to
"Cupboard Dry" level. For a higher dryness level we suggest using
the Cotton cycle.
Cotton kg Max*
Cycle suitable for drying all types of cotton, ready to be placed
in the cupboard.
Synthetics kg 4
For drying synthetic fabrics.
Wool kg 1
Programme for drying wool clothes. It is advisable to turn the
items inside out before drying. If heavy edges remain damp, leave
them to dry naturally.
Silk kg 0.5
Gentle drying of silk garments.
Anti Allergy kg Max*
This cycle has the “Allergy UK” approval of “The British Allergy
Foundation” attesting the eective reduction and elimination of
allergens. It can be used both with damp load (drying and
treatment) and dry load (half load only).
Cuddly Toys kg 2.5
This cycle preserves the appearance of cuddly toys, keeping them
at their best. Remove all accessories before proceeding with
drying. Each single piece must not exceed 600 gr.
Pre-Iron
This cycle relaxes bres, thus making ironing and folding
easier. Suitable for small load of damp or dry cotton and cotton
blend fabrics. Not for wet items.
Refresh
A short programme suitable for refreshing bres and garments
through the emission of fresh air. Do not use on wet items. It can
be used on with any load size but is more eective with small
loads. It lasts about 20 minutes.
Duvet
Programme intended to dry bulky items, such as a single duvet.
Bed & Bath kg Max*
This programme is intended for drying cotton towels and
sheets.
Baby kg 2
A programme intended to dry garments and linen of new-born
babies (cotton and chenille), as well as delicate garments.
Do not dry garments having plastic covering.
Jeans kg 3
For drying sturdy cotton including denim trousers and jackets.
Shirts kg 3
This is a programme for cotton or cotton blend/synthetics shirts.
THANK YOU FOR BUYING A HOTPOINT ARISTON PRODUCT.
In order to receive a more complete assistance,
please register your product on
www.register10.eu
Policies, standard documentation, ordering of spare parts and additional product information can be found by:
• Using QR code in your appliance
• Visiting our website docs.hotpoint.eu and parts-selfservice.europeanappliances.com
• Alternatively, contact our After-sales Service (See phone number in the warranty booklet). When contacting our After-sales
Service, please state the codes provided on your product's identi cation plate.
You can nd more information about your model online at https://eprel.ec.europa.eu/ which is the o cial EU EPREL product database.
After selecting the Product Category, enter the Model Identi er of the product. The Model Identi er is made up of letters and numbers
and can be found on the identi cation plate, as Mod. (see image on the right).
Policies, standard documentation, ordering of spare parts and additional product information can be found by:
• Using QR code in your appliance
• Visiting our website docs.emeaappliance-docs.eu
• Alternatively, contact our After-sales Service (Using QR code in your appliance). When contacting our After-sales Service, please
state the codes provided on your product's identi cation plate.
EN
Before using the appliance carefully
read the Safety Instruction.
PLEASE SCAN THE QR CODE ON YOUR APPLIANCE IN ORDER TO REACH MORE INFORMATION.
Quick guide
Before using the appliance carefully
read the Safety Instruction.
Power consumption
o-mode (Po) - Watts 0.42
left-on mode (Pl) - Watts 2.00
Programs kg kWh Minutes
Eco*
8 1.95 194
Eco
4 1.06 135
Synthetics 4 0.73 95
*The ECO is the most ecient programme in terms of energy
consumption for drying wet cotton laundry, and is used to assess
compliance with Regulation (EU) 932/2012.
Cleaning the tumble dryer
• The external metal, plastic and rubber parts can be cleaned
with a damp cloth.
• Clean the front air intake grille regularly (every 6 months) with
a vacuum cleaner to remove any lint, u or dust deposits.
Furthermore, remove any lint deposits from the lters area,
using a vacuum cleaner every so often.
• Do not use solvents or abrasives.
AB
1
4
2
3
C
C1 C2 C3
C4
C5
C6
CLEANING AND MAINTENANCE
WARNING: unplug the dryer during the cleaning and
maintenance procedures.
Emptying the water tank after each cycle (see Fig. A).
Pull the container out of the dryer and empty it into a sink or
other suitable drain, then place it back properly. Do not use the
dryer without having inserted the container back in place.
Cleaning the lters
Take out the lters and clean them by removing the lint from their
surfaces with your hand or a cloth or using a vacuum cleaner, then
put them back in place. The lint should be thrown in the garbage
bin and not washed through the drain in order to avoid spreading
microplastics in the used water system.
Do not use the dryer without having reinserted the lter in place.
Cleaning the door lter after each cycle (see Fig. B).
Remove the door lter as described below:
1. Open the door and pull the lter upwards.
2. Open the lter and remove the lint from all its parts.
Make sure to also remove any foreign objects inside the lter and
the drum.
Replace the lter correctly making sure it is fully seated.
Cleaning the bottom lter when the relevant indicator
turns on (see Fig. C).
NOTE: however, it is advisable to clean this lter after each cycle
to optimise drying performance.
Remove the bottom lter as described below:
C1. Open the bottom cover; take the handle and pull the lter out.
C2. Open the rear side of the lter and remove the lint from the
inner surface of the mesh.
C3/C4. Check the bottom lter chamber every month. If you
see residual lint accumulated on the metal ns, clean it with a
vacuum cleaner, using a nozzle with a brush.
It's crucial to do vertical movements, you may destroy the
component if you try to clean it in horizontal direction. Avoid the
direct contact of the hand with the ns - risk of cut.
C5. Close the rear side of the lter and place it back by checking it
is perfectly integrated into its seat, then lower the lter handle.
C6. Close the bottom cover.
Make sure the air intake is free.
The lters are essential parts for drying. They are intended
to collect the lint formed during the drying process. In case
of clogged lters, the air ow inside the dryer would be
seriously aected: the drying times would be longer, the
energy consumption would increase and the dryer could be
damaged. If these procedures are not carried out properly,
the dryer may not start.
TRANSPORT AND HANDLING
Never lift the dryer by holding it at the worktop.
1. Unplug the dryer.
2. Remove the water from the water tank completely.
3. Make sure that door and water tank are properly closed.
4. If the drain hose is connected to your drainage system,
re-connect it to the back of the dryer (see "Installation" section
in the Safety Instruction guide).
PRODUCT DESCRIPTION
1. Water Tank
2. Air Intake
3. Bottom lter
4. Door lter
NOTE: After cleaning the lters the relevant indicator remains on;
this is normal, it will disappear when you start a new drying cycle.
Produkspesifikasjoner
| Merke: | Bauknecht |
| Kategori: | tørkemaskin |
| Modell: | T Pure M11 82 |
Trenger du hjelp?
Hvis du trenger hjelp med Bauknecht T Pure M11 82 still et spørsmål nedenfor, og andre brukere vil svare deg
tørkemaskin Bauknecht Manualer
18 September 2025
tørkemaskin Manualer
- tørkemaskin Teka
- tørkemaskin Maytag
- tørkemaskin Miele
- tørkemaskin Whirlpool
- tørkemaskin LG
- tørkemaskin Bosch
- tørkemaskin BEKO
- tørkemaskin Exquisit
- tørkemaskin Grundig
- tørkemaskin Electrolux
- tørkemaskin Siemens
- tørkemaskin Danby
- tørkemaskin Smeg
- tørkemaskin Hoover
- tørkemaskin TCL
- tørkemaskin Hotpoint
- tørkemaskin AEG
- tørkemaskin Cecotec
- tørkemaskin Samsung
- tørkemaskin Kogan
- tørkemaskin SereneLife
- tørkemaskin Xiaomi
- tørkemaskin Candy
- tørkemaskin Gorenje
- tørkemaskin Gram
- tørkemaskin Vox
- tørkemaskin Euromaid
- tørkemaskin Omega
- tørkemaskin Fisher Paykel
- tørkemaskin Nevir
- tørkemaskin Indesit
- tørkemaskin Asko
- tørkemaskin Lamona
- tørkemaskin Cylinda
- tørkemaskin V-Zug
- tørkemaskin Avanti
- tørkemaskin Thor
- tørkemaskin Kenmore
- tørkemaskin Fagor
- tørkemaskin Corberó
- tørkemaskin Biltema
- tørkemaskin Sonnenkonig
- tørkemaskin Blomberg
- tørkemaskin Hanseatic
- tørkemaskin Equator
- tørkemaskin Aurora
- tørkemaskin Vestfrost
- tørkemaskin Essentiel B
- tørkemaskin InAlto
- tørkemaskin Veripart
- tørkemaskin Wascomat
Nyeste tørkemaskin Manualer
18 September 2025
18 September 2025
17 September 2025
17 September 2025
16 September 2025
16 September 2025
16 September 2025
16 September 2025
16 September 2025
16 September 2025
