Side 1/2

Compact and highly functional construction

Exchangeable top cover for silent or performance systems

Two preinstalled Pure Wings 2 140mm fans

Provides space for high-end graphics cards and coolers

Tidy interior thanks to cable management options

Side panel made of tempered glass

HIGHLIGHTSIDEAL APPLICATIONS

Gaming and multimedia systems

Regular and price-conscious configurations

Overclocked systems and water-cooled PCs

Outstanding price-performance ratio

be quiet! Pure Base 500 Window combines customizable and silence features with a compact and sophisticated design.

It is the perfect case for all who value compactness and highly functional features.

Highlights »

▪ Exchangeable top cover for silent or high-performance systems

▪ Two preinstalled Pure Wings 2 140mm fans ensure a silent airflow

▪ Insulation mats on the front, sides and the regular top cover

▪ Water cooling ready for radiators of up to 360mm

▪ Various options to install up to five SSDs in total

▪ Up to two SSDs can be installed prominently behind the window panel

▪ Double HDD cage with decoupled mountings

▪ Generous space for high-end graphics cards and large coolers

▪ PSU shroud and smart cable routing options provide a neat interior

▪ The power supply can be easily installed from the back of the case

▪ Side panel made of tempered glass

▪ Three-year manufacturer’s warranty

Version: 04/2022

We do not take responsibility for typographical errors. Similar image.

Airﬂow »

PSU exhaust circulation

PSU

bequiet.com

Version: 04/2022

We do not take responsibility for typographical errors. Similar image.

Logistics Data »

Pure Base 500 Window Art. no EAN code

Black BGW34 4260052187791

Metallic Gray BGW36 4260052187814

White BGW35 4260052187807

Red BGW41 4260052188439

Certiﬁcations »

Contact »

be quiet! headquarters

Listan GmbH

Wilhelm-Bergner-Straße 11c

21509 Glinde

Germany

Service hotline: +49 40 7367 686 44

E-Mail: service@bequiet.com

Visit the contact section on bequiet.com

for the right regional service information.

Optional installation of one

120mm or 140mm fan

Preinstalled

Pure Wings 2 | 140mm / 900rpm

Optional installation of up to two 120mm or 140mm fans

Preinstalled

Pure Wings 2 | 140mm / 900rpm

regular airﬂow

optional airﬂow

High-performance top cover

Technical Data »

Motherboard compatibility ATX, M-ATX, Mini-ITX

Case type Midi-Tower

PSU PS2 ATX (not included)

Dimensions (L x W x H in mm) 450 x 231 x 463

Material Steel (SGCC), ABS plastic, tempered glass

Weight (kg) 7.53 (net) / 8.49 (gross)

I/O port 2x USB 3.2 Gen. 1, HD audio (microphone + audio)

PCI slots 7

Drive bays

Up to 5x 2.5 (5 included)

Up to 2x 3.5 (2 included)

Preinstalled fans (mm) / (rpm)

Front: 1x Pure Wings 2 140 / 900

Rear: 1x Pure Wings 2 140 / 900

Optional fans (mm)

Front: 1x 140 / 3x 120

Top: 2x 140 / 120

Optional radiators (mm)

Front: 120 / 140 / 240 / 280 / 360

Top: 120 / 240

Rear: 120 / 140

Maximum dimensions (mm)

CPU cooler: 190mm

PSU: 258 / 225 (depending on position of the HDD cage)

GPU: 369

Noise cancellation

Sound insulation mats (front / top (regular top cover) / sides)

Produkspesifikasjoner

Merke:	Be Quiet!
Kategori:	dataeske
Modell:	Pure Base 500
Vekt:	7530 g
Bredde:	231 mm
Dybde:	450 mm
Høyde:	463 mm
Lydutgang:	Ja
Materiale:	ABS, Steel, Tempered glass
Støttede HDD-størrelser:	- "
Antall utvidelsesspor:	7
Produktfarge:	Black, Red
Formfaktor:	Midi Tower
Modell/Type:	PC
Støttet systemdisk formfaktorer:	ATX, Micro ATX, Mini-ITX
Antall USB 3.2 Gen 1 (3.1 Gen 1)Type-A-porter:	2
Lydkontakter:	Ja
Strømforsyning medfølger:	Nei
Antall 3.5" bays:	2
Antall 2.5" bays:	5
Siderute:	Ja
Av/på-knapp:	Ja
Maksimal høyde CPU-kjøler:	190 mm
Maksimal lengde PSU:	258 mm
Frontvifte installert:	1x 140 mm
Maksimale frontvifter:	3
Frontviftediameter som støttes:	120,140 mm
Antall toppvifter som støttes (maks.):	2
Toppviftediametere som støttes:	120,140 mm
Støttede radiatorstørrelser foran:	120,140,240,280,360 mm
Støttede radiatorstørrelser bak:	120,140 mm
Støttede radiatorstørrelser øverst:	120,240 mm
Bakre vifter installert:	1x 140 mm
