High-Power 300-Watt, 3-Way, 8 Ω Loudspeaker System with 15" Low-Frequency,

6" Mid-Frequency and 1.35" High-Frequency Transducers

CL3596/CL3596-WH

Features

• Professionalsoundreinforcementloudspeakersystem

designedforavarietyofxedinstallationapplications

• Exceptionalsoundqualitywithwidefrequency

bandwidthanduniformdispersion

• 250-Watt15"low-frequencyand75-Watt6"

mid-frequencytransducersprovidedeepbassand

precisemid-rangeformediumtolargesizedrooms

• Constantdirectivity90°Hx60°Vrotatablewaveguide

with1.35"high-frequencytransducer

• Passivecrossoverwithoverloadcircuitryensures

optimaldriverprotection

• Dualprofessionalspeakerconnectors(compatiblewith

NeutrikSpeakonconnectors)and4-position

terminalstrip

• Internallybracedandacousticallyinert15°trapezoidal

birchplywoodenclosureidealforclusterapplications

• Multiplethreadedinsertsforexibleinstallation

includingOmnimount™boltpattern

• Powdercoatedsteelgrillewrappedwithacoustically

transparentfabricandfoammatchingcabinetcolor

• High-qualitycomponentsandexceptionallyrugged

constructionensurelonglife

High-Power 300-Watt, 3-Way, 8 Ω Loudspeaker System with 15" Low-Frequency,

6" Mid-Frequency and 1.35" High-Frequency Transducers

CL3596/CL3596-WH

Product Overview Technical Specications

• Frequencyrange(-10dB) 33Hz-20kHz

• Frequencyresponse(±3dB) 37Hz-18kHz

• Nominaldispersion 90ºHx60ºV

• Directivityfactor(Q) 8.7

• Directivityindex(DI) 9.4dB

• Sensitivity 97dB

(1W@1mpassive)

(halfspace)

• Crossovermodes Bypassable

• Crossoverfrequency 600Hz,3.8kHz

• Powerhandling 300WRMS@49V

(longterm,IECpassive)

Transducers:

• Nominalimpedance 8Ω

• Lowfrequencydriver 15"@300W

• Midfrequencydriver 6"@75W

• Highfrequencydriver 1.35"@30W

• Maximumcontinuous 122dB

SPL(passive)

• Maximumpeak 128dB

SPL(passive)

• Overloadprotection Fullrangepowerlimitingtoprotectdrivers

andcrossovers

• Enclosure Trapezoidal15°sideangle,

laminatedbirchplywood

• Grille Steel

• Hornwaveguide 90ºHx60ºVMF/HF,rotatable

• Riggingpoints 23xM10threadedpoints;4xM8threaded

insertsforOmniMount™60series.

• Termination DualNL4and4-positionterminal

stripconnection

• Dimensions(HxWxD) 35.0x18.5x16.5"/890x470x418mm

• Weight 75.7lbs/34.4kg

• Optionalaccessories

Wall/CeilingBracket(Black): CL3500YB

Wall/CeilingBracket(White): CL3500YB-WH

Array/FlyKitfor

Suspensionof(2)Identical

CLSeries(Black): CLFK

Array/FlyKitfor

Suspensionof(2)Identical

CLSeries(White): CLFK-WH

TheEUROCOMCL3596isaprofessionalhigh-performance

two-wayloudspeakersystemthatisidealforawide

varietyofxedinstallationapplications.Featuringclean

linesandauniquefabric-nishedwrap-aroundgrille,

theCL3596isfullyathomeineventhemostelegant

settings,includingtheatersandauditoria,housesof

worship,themedentertainment,andsportingvenues.

Perfectformainsinmediumtolargevenues,theCL3596

alsoexcelsforllanddelaysystemsinlargerooms.

Builtofhigh-qualitylaminatedBalticbirchplywood,

theCL3596'slightweightcabinetcombinesnaturalrigidity

andacousticinertnesswiththeadditionalstrengthof

internalsteelbracing.Threadedmounting-pointinserts

intheinternalbracketsprovidearatedloadfactorofat

least10timesoverallcabinetweight,makingtheCL3596

exceptionallysafeforowninstallation,eithersinglyor

inarrays.

TheCL3596achievesfully-professionalperformance

andreliabilitywithnewly-designedcomponentswhose

frequencyresponse,sensitivity,andpowerhandling

areallcustom-tailoredforCLSeriesloudspeakers.

BEHRINGERmaintainscompletecontroloverquality

andsoniccharacterbymanufacturingallCLSeries

components—startingwiththepulpusedforcone

fabrication—inourownfactories.

A15"wooferprovidingfull,richlowsismatchedto

a6"mid-rangeconedriveranda1.35"compression

driverviainternalpassivecrossoversat600Hzand

3.8kHztodeliverclear,smoothsoundacrosstheentire

audiblespectrum.Arotatablewaveguideallowsoptimal

applicationofthe90°x60°coveragepatternregardless

ofspeakerorientation,whichmaybeeitherverticalor

horizontal.Easybypassofthecrossoveroerstheadded

exibilityofoperatingtheloudspeakerinabi-amped

conguration.

EveryaspectoftheCL3596hasbeenthoughtthroughto

maximizevalueandconvenienceforboththeinstaller

andtheenduser.Theresultisanattractive,durable,

installation-readyloudspeakersystemthatwilldeliver

top-notchsoundday-after-dayforyearstocome.

High-Power 300-Watt, 3-Way, 8 Ω Loudspeaker System with 15" Low-Frequency,

6" Mid-Frequency and 1.35" High-Frequency Transducers

CL3596/CL3596-WH

Summary description:Theloudspeakershallbeaprofessional3-wayxed-installationloudspeakersysteminasteel-braced

plywoodenclosureusingabypassableinternalcrossovernetworkwitha15"/380mmlow-frequencyconetransducerand

waveguide-mounted6"/150mmmid-frequencyconedriverand1.35"/34mmhigh-frequencycompressiondriver.

Drivers:Theloudspeakersystemshallusethreetransducers:

• Low-frequencydrivershallbea15"/380mmdirect-radiatingconetransducer

• Mid-frequencydrivershallbea6"/150mmconedrivermountedintandemwiththehigh-frequencydriveronarotatable

90ºx60ºwaveguideconstructedofpolypropylene

• High-frequencydrivershallbea1.35"/34mmdiaphragmcompressiondrivermountedintandemwiththe

mid-frequencydriveronarotatable90ºx60ºwaveguideconstructedofpolypropylene

Enclosure:Theloudspeakersystemshallbehousedinanenclosureconstructedoflaminatedbirchplywoodthatisinternally

bracedwithsteel.Theenclosureshallbenishedwithdurable,scu-freeblackorwhitepaint.Thefrontoftheenclosureshall

beprotectedwithaperforatedgrilleofpowder-coatedstructuralsteelbehindfabric-wrappedacousticallytransparentfoam.

Thebackoftheenclosureshallhavearecessedsteelinputplateforconnectors.

Rigging and mounting:Theexterioroftheenclosureshallbettedwith23M10threadedriggingpoints.Therearofthe

enclosureshallhave4M8threadedinsertsforOmniMount™60bolts.Theenclosureshallprovideattachmentpointsforan

optionalyokebracket.

I/O and connectors:Theloudspeakersystemshallhavethefollowingconnectors:

• TwoNL4connectors,wiredinparallelasfull-rangeinputstothepassivecrossover

• One4-positionterminalstripwithcaptivewireclampsandremovableplasticcover,withINterminalswiredinparallelto

OUTterminalsandtotheNL4connectors

• CrossoverbypassasadetachableconnectoronthecrossoverPCB,allowingdirectconnectiontoeachdriver

Performance criteria:Theloudspeakersystemshallmeetthefollowingperformancecriteria:

• Nominalimpedanceshallbe8Ω

• Sensitivity(1W/1mpassive)shallbe97dB

• Usablefrequencyrange(-10dB)shallbe33Hz-20kHz

• Frequencyresponse(±3dB)shallbe37Hz-18kHz

• PowerHandling(IEC268-5,passive)shallbe300WRMS@40V

• Nominaldispersionshallbe90ºx60º(axisdependentonhornorientation)

• MaximumSPL(1m,passive)shallbe122dBcontinuousand128dBpeak

Dimensions and weight:Theloudspeakersystemshallhavethefollowingphysicalcharacteristics:

• Heightshallbe35.0"/890mm

• Widthshallbe18.5"/470mm

• Depthshallbe16.5"/418mm

• NetWeightshallbenomorethan75.7lbs/34.4kg

Model:TheloudspeakershallbetheBEHRINGEREUROCOMCL3596/CL3596-WH.
