Side 1/52

F5D7001

Connect your desktop computer to a

FASTER wireless network

User Manual

High-Speed Mode

Wireless G Desktop

Network Card

1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Benefits of a Home Network. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Advantages of a Wireless Network. . . . . . . . . . . . . . . . . . . . . . . . .

Placement of your Wireless Networking

Hardware for Optimal Performance . . . . . . . . . . . . . . . . . . . . . . . .

2 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Product Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Applications and Advantages . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Product Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3 Installing and Setting Up the Card . . . . . . . . . . . . . . . . . . . . . . . 10

Step 1: Install the Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Step 2: Insert the Card into your Computer . . . . . . . . . . . . . . . . . 11

Step 3: Let Windows Finish the Installation . . . . . . . . . . . . . . . . . 13

4 Using the Belkin Wireless LAN Utility . . . . . . . . . . . . . . . . . . . . 16

Setting Wireless Network Preferences . . . . . . . . . . . . . . . . . . . . . 16

Securing your Wi-Fi Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Monitoring the Status of your Network Connection. . . . . . . . . . . 32

Monitoring Data Transfer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Finding Available Networks in your Area . . . . . . . . . . . . . . . . . . . 35

Performing Diagnostic Tests on your Computer . . . . . . . . . . . . . 36

5 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

6 Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table of Contents

section

Introduction

Thank you for purchasing the Belkin High-Speed Mode Wireless

G Desktop Network Card (the Card). Now you can take advantage

of this great new technology and gain the freedom you need

around the home or office without using cables. The Card works

like a conventional network card, but without the wires. The easy

installation and setup will have you networking wirelessly in minutes.

Please be sure to read through this User Manual completely, and pay

special attention to the section entitled “Placement of your Wireless

Networking Hardware for Optimal Performance”. By following our

simple setup instructions your Belkin Home Network will allow you to:

• Share one high-speed Internet connection with all the computers

in your home

• Share resources, such as files, and hard drives among all the

connected computers in your home

• Share a single printer with the entire family

• Share documents, music, video, and digital pictures

• Store, retrieve, and copy files from one computer to another

• Simultaneously play games online, check Internet e-mail,

and chat

Here are some of the advantages of setting up a Belkin

Wireless Network:

• Mobility –you’ll no longer need a dedicated “computer room”—

now you can work on a networked laptop or desktop computer

anywhere within your wireless range

•

Easy installation – Belkin Easy Installation Wizards make

setup simple

•

Flexibility – set up and access printers, computers, and other

networking devices from anywhere in your home

•

Easy Expansion – the wide range of Belkin networking products

let you expand your network to include devices such as printers

and gaming consoles

•

No cabling required – you can spare the expense and hassle of

retrofitting Ethernet cabling throughout the home or office

•

Widespread industry acceptance – choose from a wide range

of interoperable networking products

Produkspesifikasjoner

Merke:	Belkin
Kategori:	Ruter
Modell:	F5D7001
LED-indikatorer:	Ja
Wi-Fi:	Ja
Wi-Fi-standarder:	802.11b, 802.11g
Tilkoblingsteknologi:	Trådløs
Nettverksstandard:	IEEE 802.11b, IEEE 802.11g
Vertsgrensesnitt:	PCI
Maksimal dataoverføringshastighet:	125 Mbit/s
Komponent for:	PC
Produktfarge:	Grønn
Beste Wi-Fi-standard:	802.11g
Videoopptaksgrensesnitt:	WLAN
Intern:	Ja
WLAN-støttede dataoverføringshastigheter:	54, 125 Mbit/s
Full tosidig:	Ja
