Side 1/2
Art. 38-735
1
© 2017-11-16 Biltema Nordic Services AB
SIKKERHETSINSTRUKSJONER
• Se aldri rett inn i lykten.
• Produktet må ikke modi seres.
• Produktet må ikke senkes ned i vann.
INSTALLASJON
1. Kontroller at alle deler følger med ved levering.
2. Kontroller at tilkoblingskablene er lange nok.
3. Velg ut et passende sted for installasjon.
4. Koble strømkablene til batteriet, rød til BAT+ og
sort til BAT-.
5. Kontroller sikringen dersom lykten ikke lyser når
tenningen er på.
Stående montering Hengende montering
LED Working Light Operating Instruction Manual
38743（SW12210）
Led working light 15W Flood
Ⅰ. Read the complete instructions carefully before you use the product, and keeping properly
Ⅱ. Primary structure and range of application
Back cover: Die-cast aluminum;
Lamp-chimney: Optical PMMA plastic;
Surface: Anti-static coating processing;
The entire product seal treatment: Pouring sealant.
Main application: Vehicle、Building、Agriculture、Mining、Forestry and Fishery etc..
Ⅲ. Main parameter
1.input voltage：DC10~30V
2.Power：15W
3.IP： IP68
Ⅳ. Installation requirement and product maintenance
1. Three kinds of installations for choice:
Stent installation Back stent installation Magnetic base installation
2. Before the installation must cut off power supply;
3. Ensure product firm installed in fixation;
4. Current lead: White guide line should connect to positive pole, Black guide line
should connect to negative pole. Reverse connection will cause damage to the product;
5. Magnetic base need to purchase extra.
Ⅴ. Announcements:
1. Refuse to use the light when its chimney and the body cover damaged;
2. Clean the dust and debris on light surface every other 2~3months, Keeping good heat
dissipation to ensure the lifetime of the light.
3. Can not use alcohol or other solvents when washing the light.
JUSTER VINKELEN PÅ LYKTEN
1. Løsne justeringsskruen.
2. Juster vinkelen på lykten.
3. Fest justeringsskruen.
SÄKERHETSINSTRUKTIONER
• Titta aldrig rakt in i lampan.
• Produkten får inte modi eras.
• Produkten får inte nedsänkas i vatten.
INSTALLATION
1. Kontrollera att alla delar är med vid leverans.
2. Kontroller att anslutningskablarna är tillräckligt
långa.
3. Se ut en passande plats för installationen.
4. Anslut spänningskablarna till batteriet, röd till
BAT+ och svart till BAT-.
5. Kontrollera säkringen om lampan inte lyser då
tändningen är till.
Stående montering Hängande montering
LED Working Light Operating Instruction Manual
38743（SW12210）
Led working light 15W Flood
Ⅰ. Read the complete instructions carefully before you use the product, and keeping properly
Ⅱ. Primary structure and range of application
Back cover: Die-cast aluminum;
Lamp-chimney: Optical PMMA plastic;
Surface: Anti-static coating processing;
The entire product seal treatment: Pouring sealant.
Main application: Vehicle、Building、Agriculture、Mining、Forestry and Fishery etc..
Ⅲ. Main parameter
1.input voltage：DC10~30V
2.Power：15W
3.IP： IP68
Ⅳ. Installation requirement and product maintenance
1. Three kinds of installations for choice:
Stent installation Back stent installation Magnetic base installation
2. Before the installation must cut off power supply;
3. Ensure product firm installed in fixation;
4. Current lead: White guide line should connect to positive pole, Black guide line
should connect to negative pole. Reverse connection will cause damage to the product;
5. Magnetic base need to purchase extra.
Ⅴ. Announcements:
1. Refuse to use the light when its chimney and the body cover damaged;
2. Clean the dust and debris on light surface every other 2~3months, Keeping good heat
dissipation to ensure the lifetime of the light.
3. Can not use alcohol or other solvents when washing the light.
JUSTERA VINKELN PÅ LAMPAN
1. Lossa justeringsskruven.
2. Justera vinkeln på lampan.
3. Fäst justeringsskruven.
ARBETSBELYSNING
SE NO
ARBEIDSBELYSNING
Tillverkat för Biltema, Garnisonsgatan 26, 2nd FL, SE-254 66 Helsingborg. www.biltema.com
Art. 38-735
2
© 2017-11-16 Biltema Nordic Services AB
SIKKERHEDSINSTRUKTIONER
• Se aldrig direkte ind i pæren.
• Man må ikke ændre på produktet.
• Produktet må ikke nedsænkes i vand.
INSTALLATION
1. Kontroller, at alle dele er med ved leveringen.
2. Kontroller, at tilslutningskablerne er tilstrækkeligt
lange.
3. Vælg et egnet sted til installationen.
4. Slut spændingskablerne til batteriet, rød til BAT+
og sort til BAT-.
5. Kontroller sikringen, hvis lampen ikke lyser, når
tændingen er sat til.
Stående montering Hængende montering
LED Working Light Operating Instruction Manual
38743（SW12210）
Led working light 15W Flood
Ⅰ. Read the complete instructions carefully before you use the product, and keeping properly
Ⅱ. Primary structure and range of application
Back cover: Die-cast aluminum;
Lamp-chimney: Optical PMMA plastic;
Surface: Anti-static coating processing;
The entire product seal treatment: Pouring sealant.
Main application: Vehicle、Building、Agriculture、Mining、Forestry and Fishery etc..
Ⅲ. Main parameter
1.input voltage：DC10~30V
2.Power：15W
3.IP： IP68
Ⅳ. Installation requirement and product maintenance
1. Three kinds of installations for choice:
Stent installation Back stent installation Magnetic base installation
2. Before the installation must cut off power supply;
3. Ensure product firm installed in fixation;
4. Current lead: White guide line should connect to positive pole, Black guide line
should connect to negative pole. Reverse connection will cause damage to the product;
5. Magnetic base need to purchase extra.
Ⅴ. Announcements:
1. Refuse to use the light when its chimney and the body cover damaged;
2. Clean the dust and debris on light surface every other 2~3months, Keeping good heat
dissipation to ensure the lifetime of the light.
3. Can not use alcohol or other solvents when washing the light.
JUSTER LAMPENS VINKEL
1. Skru justeringsskruen løs.
2. Juster lampens vinkel.
3. Skru justeringsskruen fast.
TURVAOHJEET
• Älä koskaan katso suoraan valaisimeen.
• Muutoksia ei saa tehdä.
• Älä upota laitetta veteen.
ASENTAMINEN
1. Varmista, että toimitus sisältää kaikki osat.
2. Varmista, että liitäntäjohdot ovat riittävän pitkät.
3. Valitse sopiva asennuspaikka.
4. Yhdistä johdot akkuun: punainen plusnapaan
(BAT+) ja musta miinusnapaa (BAT-).
5. Jos valaisimeen ei syty valoa, kun se sytytetään,
tarkista sulake.
Pystyyn asentaminen Riippumaan asentaminen
LED Working Light Operating Instruction Manual
38743（SW12210）
Led working light 15W Flood
Ⅰ. Read the complete instructions carefully before you use the product, and keeping properly
Ⅱ. Primary structure and range of application
Back cover: Die-cast aluminum;
Lamp-chimney: Optical PMMA plastic;
Surface: Anti-static coating processing;
The entire product seal treatment: Pouring sealant.
Main application: Vehicle、Building、Agriculture、Mining、Forestry and Fishery etc..
Ⅲ. Main parameter
1.input voltage：DC10~30V
2.Power：15W
3.IP： IP68
Ⅳ. Installation requirement and product maintenance
1. Three kinds of installations for choice:
Stent installation Back stent installation Magnetic base installation
2. Before the installation must cut off power supply;
3. Ensure product firm installed in fixation;
4. Current lead: White guide line should connect to positive pole, Black guide line
should connect to negative pole. Reverse connection will cause damage to the product;
5. Magnetic base need to purchase extra.
Ⅴ. Announcements:
1. Refuse to use the light when its chimney and the body cover damaged;
2. Clean the dust and debris on light surface every other 2~3months, Keeping good heat
dissipation to ensure the lifetime of the light.
3. Can not use alcohol or other solvents when washing the light.
VALAISIMEN KULMAN SÄÄTÄMINEN
1. Irrota säätöruuvi.
2. Säädä valaisimen kulma.
3. Kiinnitä säätöruuvi.
FI DK
TYÖVALAISTUS ARBEJDSBELYSNING
