Installation Guide

• High-performance wireless for outdoor environments.

• NEMA 4X rated with an extended temperature range and a waterproof

chassis.

• Can be used outdoors in unprotected locations.

SmartPath Enterprise Wireless Access Point, Outdoor

L W N 6 0 2 W A

Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S. call 724-746-5500)

FREE technical support 24 hours a day, 7 days a week: Call 724-746-5500 or fax 724-746-0746

Mailing address: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018

Web site: www.blackbox.com • E-mail: info@blackbox.com

Customer

Support

Information

724-746-5500 | blackbox.com

Page 2

724-746-5500 | blackbox.com

SmartPath Enterprise Wireless Access Point, Outdoor Installation Guide

Table of Contents

1. Kit Contents ...........................................................................................................................................................................3

2. Safety Instructions and Site Hazard Warnings ........................................................................................................................3

3. Device, Power, and Environmental Specifications ...................................................................................................................4

3.1 Device and Enclosure Specifications ..............................................................................................................................4

3.2 Power Specifications ......................................................................................................................................................4

3.3 Environmental Specifications .........................................................................................................................................4

4. Mounting the LWN602WA ....................................................................................................................................................5

4.1 PoE Connections ...........................................................................................................................................................5

4.2 Vertical Pole Mount .......................................................................................................................................................5

4.3 Horizontal Pole Mount ..................................................................................................................................................6

4.4 Flat Surface Mount ........................................................................................................................................................8

5. Attaching External Antennas ...................................................................................................................................................9

6. Attaching the Ethernet Cable Waterproof Housing ..............................................................................................................10

7. Connecting to the Network ................................................................................................................................................. 11

7.1 Connecting to SmartPath EMS .................................................................................................................................... 11

7.2 Using the Virtual Access Console ................................................................................................................................ 13

8. Deployment and Configuration Tips .................................................................................................................................... 14

9. Ethernet Protector ................................................................................................................................................................16

10. Troubleshooting .................................................................................................................................................................. 17

10.1 Contacting Black Box................................................................................................................................................... 17

10.2 Shipping and Packaging .............................................................................................................................................. 17

Produkspesifikasjoner

Merke:	Black Box
Kategori:	Tilgangspunkt
Modell:	LWN602WA
Vekt:	2700 g
Bredde:	197 mm
Dybde:	244 mm
Høyde:	76 mm
Nettverksstandard:	IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af
Maksimal dataoverføringshastighet:	300 Mbit/s
2,4 GHz:	Ja
5 GHz:	Ja
Antennefunksjoner:	Avtakbar antenne
WAN-port:	Ethernet (RJ-45)
AC-inngangsspenning:	48 V
Antall ethernets-/bredbåndstilkoblinger (RJ-45):	1
Driftstemperatur (T-T):	-40 - 55 °C
Oppbevaringstemperaturomåde (Celsius):	-40 - 80 °C
DC-inngangskontakt:	Nei
Ethernet LAN dataoverføringshastigheter:	10,100,1000 Mbit/s
Intern:	Nei
Strøm over Ethernet (PoE):	Ja
Frekvensbånd og driftskanaler:	2.4, 5 GHz
Innput-strøm:	0.625 A
Antall antenner:	4
