Side 1/4
Owner’s Manual
Included Accessories
Welcome to Bluesound, Hi-Fi for the Wi-Fi generation.
Bluesound transforms your local digital music library by putting the music of your life right at your ngertips.
The clutter of CDs is relegated to a previous era! Your smartphone, desktop or tablet running the Bluesound App
now controls your music.
Your Bluesound music system is also a sophisticated Internet streaming device that allows you to listen to a
wide range of Internet music service providers. Bluesound also provides access to music subscription services
makes every radio station in the world a local station via the magic of the internet.
To take full advantage of all these Bluesound capabilities requires a robust wired or wireless home network
and a reliable high speed Internet connection, provided by a DSL or Cable modem. Internet access must be
contracted and installed by your local Internet Service Provider. For remote areas there are satellite options for
high speed internet access.
Before signing on to a music subscription or cloud service we suggest that you review your Internet service plan
and be sure you have enough internet speed and bandwidth to provide uninterrupted streaming. Most internet
service providers offer multiple plans and can help you make the best choice.
For detailed instructions on how to control your Bluesound player, visit our website at www.bluesound.com.
120V AC Power Cord
230V AC Power Cord
Mini Jack to Toslink Adaptor
Portable Wireless
Streaming Speaker
PORTABLE WIRELESS
STREAMING SPEAKER
STATUS INDICATOR:
Below is a table of the LED blink codes and their corresponding descriptions.
LED BLINK CODE DESCRIPTION
Short blue flash, then red Powering up, rebooting the unit
Solid green Hotspot Mode
Flashing green Connecting to Network shares
Solid red Cannot boot; drive error
Red pulse No Internet gateway
White pulse Software update available
Solid red Upgrade mode
Alternate flashing red and green Upgrading…
Flashing blue Mute mode
Solid white Indexing
Solid blue Connected to Network – ready to use with Bluesound App
Flashing red Factory reset in progress
Solid purple Hotspot timed out
1
3
10
10
12
13
11 7
8
9
6
4
5
1 2
PLAY/PAUSE BUTTON: This button has multiple functions – a visual indicator of network connectivity and a PLAY/
PAUSE button. For a full listing of LED Blink Codes, please see #1 – Blink Codes. For an ungrouped Player, press
the button to Play and Pause the stream. If listening to an Internet radio stream, the Pause function will work for 30
seconds. At this point, the buffer is full and the stream will Stop. When a Player is grouped, pressing the PLAY/PAUSE
button will Mute that Player while other Players continue the stream. The Player’s LED will flash blue when muted.
PREVIOUS TRACK/NEXT TRACK: These buttons can be used to go back to the previous track or skip to the ◄◄
next track in your current playlist. ►►
+, - (VOLUME): Toggle either button to vary volume level. Volume level will not change if you press and hold either
button.
(+): Increase volume level
(-): Decrease volume level
PRESETS: The PULSE FLEX 2i has 5 programmable preset buttons. These presets are configured using the presets
menu in the BluOS App.
LAN PORT: The LAN PORT connection can be used with the Ethernet cable provided. This is an optional connection
since the PULSE FLEX 2i can be connected to the network through a Wi-Fi connection to your router. To setup the
PULSE FLEX 2i using the LAN Port a Wired Ethernet connection is required. Using the Ethernet cable provided, connect
one end of the Ethernet cable to the LAN port of your wired Ethernet broadband router and the other end to the PULSE
FLEX 2i’s LAN port.
OPTICAL IN/ANALOG IN: Using a 3.5mm Stereo Audio Cable (not provided), connect one end to the Analog In of the
PULSE FLEX 2i and the other end to the corresponding analog output of other compatible devices. The source will show
as an Analog Input in the Navigation Drawer of the Bluesound app. Using an Optical to 3.5mm convertor (included
with the PULSE FLEX 2i), a digital optical source can also be added. This will appear as Optical Input in the Navigation
Drawer.
USB (TYPE A): Connect a USB mass storage device to the USB input. Typical USB mass storage devices compatible
with the PULSE FLEX 2i include portable flash memory devices and external hard drives (FAT32 formatted).
AC MAINS INPUT: The PULSE FLEX 2i comes supplied with two separate AC power cords. Select the AC power cord
appropriate for your region. Before connecting the plug to the wall outlet, connect firmly the other end of the AC power
cord to PULSE FLEX 2i’s AC Mains input socket. Never force the plug into a wall outlet. An adaptor may be necessary
in certain regions. Always disconnect the plug from the wall outlet first, before disconnecting the cable from the PULSE
FLEX 2i’s AC Mains input socket.
SERVICE: Use the SERVICE port in conjunction with USB (Type B Mini) to initially load firmware on the Player. This is
not for consumer use. Only Authorized Bluesound Service personnel can access this USB port and SERVICE control
button.
HEADPHONE JACK: A 3.5mm headphone jack is located on the back of the PULSE FLEX 2i.
MOUNTING THREAD: Use the built-in mounting mechanism with the Bluesound WM100 wall mount or for other
mounting options.
BATTERY PORT: The PULSE FLEX 2i can be used with a Bluesound BP100 Battery Pack to make it a truly portable
wireless speaker. Connect the BP100 to the PULSE FLEX 2i using this port.
2
3
4
5
7
6
8
9
10
11
12
13
