Driver Complement:
L
ow Frequency: Dual Apogee 8"(204mm) permanent magnet cone-
type drivers are treated with a waterproofing compound, providing
resistance to moisture, and enabling long-term stability of cone
resonance and cone mass parameters
High F
requency: Dual Apogee 1"(25mm) horn-loaded compression
drivers
Input Connectors:
Neutrik
™
NL
4
MP Speakon
™
connectors standard; Cannon EP series
and gas-tight barrier strips optional
Compatible Processors:
DLC24 Digital Controller
Grille:
Powder-coated, diamond-punched steel with acoustic foam covering
Trim:
Optional protective steel trim on ends; powder-coated for durability
Rigging Hardware:
Two 12-gauge steel nutplates, mounted one on either end, recessed,
nominally flush; accepts 3/8"-16 thread, (10mm nutplate optional);
nutplates are backed with 12-gauge steel internal brackets
Finish:
Textured high-strength black epoxy paint; other colors optional
Enclosure Type:
Compound angular trapezoidal, optimally-vented bass
Cabinet Construction:
Multi-ply birch with stainless steel fasteners
Wide-Angle
Loudspeaker System
Engineering Data:
Description:
Format:
Single-amped/Two-way/Electronically-coupled
Dispersion:
H: 165
°
x V: 45
°
Frequency Response (1m on axis):
63 Hz to 19 kHz ± 3 dB
Max. SPL (@1m):
114 dB cont./120 dB peak
PTML (peak transient mechanical limit):
131 dB
Sensitivity (1W @ 1m):
97.4 dB/200 Hz to
4
kHz
Nominal Impedance:
16 ohms
Max Power Handling:
120W cont./480W peak
Dimensions:
front: 32"(813mm) W x 9.9"(252mm) H
rear: 32"(813mm) W x 8.5"(216mm) H
depth: 10"(254mm)
Weight:
38 lb. (17.3 kg)
The AE-2s2 is a wide-angle, two-way,
single-amped system designed for
extended horizontal dispersion and
high fidelity response. The unique
shape of the enclosure produces the
wide coverage angle (165°) while
minimizing sight-line obstructions.
AE-2s2
