Side 1/8

5019 612 10243

Programme

Care

Labels

Max.

Load

Type of wash / Notes

- for temperature selection, respect the manufacturer's recommendations on the care label

Detergents and Additives Special options Max.

Spin

Speed

rpm

Pre-

wash

Main

Wash

Softener Rinse

hold

Pre-

wash

Rapid Variable

spin

Cotton

40 - 60 - 95 °C

40 - 60 - 95°C

5.0

Normally to heavily soiled bed linen, table linen and underwear, towels, shirts etc. made of

cotton and linen.

For washing heavily soiled laundry, the “Prewash” option can be selected.

Yes

i i i i

max.

Synthetics

30 - 40 - 60 °C

30 - 40 - 60°C

3.0

Normally soiled blouses, shirts, overalls etc. made of polyester (Diolen, Trevira), polyamide

(Perlon, Nylon).

Yes

i i i i i

max.

Delicates

30 - 40 °C

30 - 40°C

1.5 Curtains and delicate clothing, dresses, skirts, shirts and blouses.

Yes

i i i

–

max.

Daily load

40 °C

40°C

3.0 Slightly to normally soiled textiles made of cotton and/or synthetics. – Yes

i i

– –

max.

Quick wash 15´

30 °C

30°C

3.0

Refreshed briefly worn outer clothing made of cotton, artificial fibers and blends with cotton.

Use lowest recommended detergent amount.

– Yes

i i

– –

max.

Wool

Cold - 40 °C

- 40°C

1.0

Only woollens with a felt-free finish, labelled with the woolmark and identified as machine

washable.

– Yes

i i

– –

max.

Handwash

30 - 40 °C

30 - 40°C

1.0 Textiles made of linen, silk, wool and viscose marked as “handwashable”. – Yes

i i

– –

400

Rinse & Spin – 5.0 Same as the last rinse and the final spin in the “Cotton” programme. – –

i i

– –

max.

Spin – 5.0 In this programme spinning is intensive. Same as the spin cycle in the “Cotton” programme. – – – – – –

max.

Gentle Spin – 1.0 – – – – – –In this programme spinning is gentle. Same as the spin cycle in the “Wool” programme.

max.

Drain – – – – – – – – – –Drain only - no spinning. Alternative method of terminating programme after “Rinse Hold”.

A. Programme selector

B. Programme sequence indicator

C. “Variable spin” button

D. “Start/Pause” button

E. “Reset” button

F. “Door open” indication

This washing machine is equipped with

automatic safety functions which detect and

diagnose faults at an early stage and react

appropriately:

G. “Service” indication

H. “Water tap closed” indication

I. “Clean pump” indication

Do not use liquid detergent for main wash if you

have activated prewash option.

For improved garment care, spin speed is restricted

to 400 rpm in this programme.

Selectable for programmes Cotton 60 and 40°C only.

PROGRAMME CHART

N.B. This machine is controlled by sensors. Please avoid excessive detergent dosing.

i: optional / Yes : dosing required

5019 612 10243

Programme

Temperature

(°C)

Load

(kg)

Water

(l)

Energy

without “Rapid”

(kWh)

Approx. Programme Duration (hrs : min)

without “Rapid” with “Rapid”

Cotton 95 5.0 50* 1.70 2:05 –

Cotton** 60 5.0 47 0.89 2:45 2:10

Cotton** 60 2.5 32 0.68 2:10 ***

Cotton 40 5.0 47 0.65 2:00 1:45

Cotton** 40 2.5 32 0.52 1:45 ***

Synthetics 60 3.0 50* 0.90 2:05 1:14

Synthetics 40 3.0 40 0.50 1:50 0:59

Delicates 40 1.5 50 0.55 0:45 –

Daily load 40 3.0 40 0.45 1:00 –

Quick wash 15´ 30 3.0 30 0.15 0:15 –

Wool 40 1.0 55 0.55 0:45 –

Handwash 40 1.0 40 0.40 0:35 –

CONSUMPTION DATA

1. Load the machine, close the drum doors and check

that they are properly locked.

2. Add detergent and additives into the dispenser to

no more than the level mark, as follows:“MAX”

• Programme with pre and main wash

• Main wash programme without prewash

• Fabric softeners and conditioners

• Stain remover agents

• Anti-scale agents (if necessary)

3. Close the lid.

4. Turn the to the desiredprogramme selector

programme and temperature. The lamp next to the

“Start/Pause” button flashes. The indication lamp

of the predefined spin speed lights up.

PREPARATION OF THE WASH CYCLE

“DOOR OPEN” INDICATION

Before starting and after end of a programme, the lamp

lights to show the the lid can be opened. As long as a

wash programme is running, the lid remains locked and

must on no account be forced open. In case you have

an urgent need to open it during a running programme,

refer to “Cancel (Reset) a running programme before

the end”.

PROGRAMME START

Open the tap and press the “Start/Pause” button.

The indication lamp next to the “Start/Pause” button

lights up. The programme sequence indicator shows

the current programme phase, running from left to right

through Wash, Rinse, Spin/Drain. When the programme

phrase is finised, the corresponding indication goes out.

• Note: If there is a power interruption or if the

appliance is disconnected during the cycle, the

programme will run again from the point where it

was interrupted.

PROGRAMME END

• All the lights of the programme sequence indicator

are off, and the “Door open” indication lights up.

1. Turn the programme selector to the “Off/O”

position.

2. Close the water tap.

3. Open lid and drum and unload the machine.

4. Leave the lid open for some time to allow the

interior of the machine to dry.

CHANGE PROGRAMME AND/OR OPTIONS

AFTER PROGRAMME START

1. Press the “Start/Pause” button to pause the

programme. The light flashes.

2. Select the new programme, any options and another

spin speed if you want.

3. Press the “Start/Pause” button again. The new

programme continues at the same position where

the previous programme was interrupted. Do not

add detergent for this programme.

CANCEL (RESET) A RUNNING PROGRAMME

BEFORE THE END

The button cancels a programme before the “Reset”

end. Press the “Reset” button for at least 3 seconds.

Any existing water is drained out before the door can be

opened.

SELECT THE DESIRED OPTION(S)

Selecting or deselecting an option can be done at

any time during the programme. The option will be

applied as long as the corresponding programme

phase has not been executed yet.

“Rinse hold” button

• The laundry remains in the last rinse water without

progressing to the final spin cycle to avoid creasing

and prevent colours from changing.

• This option is particularly recommended for the

“Synthetics”, “Daily load” and “Delicates”

programmes.

• It is useful if you want to postpone spinning to a later

time, or if you want to drain out only.

• If you select “Rinse Hold”, do not leave items to

soak for too long.

• As soon as the appliance stops in the rinse hold, the

“Rinse hold” lamp of the sequence indicator lights up

and the lamp next to the “Start/Pause” button flashes.

Terminate the “Rinse hold” option:

• Press the “Start/Pause” button; the programme

will terminate automatically with the final spin cycle

for the present wash programme.

• If you do not wish to spin the clothes, turn the

programme selector knob to the “Drain”

programme and press the “Start/Pause” button.

“Prewash” button

• Only for heavily soiled loads (for example sand,

granular dirt). Increases the cycle time by

approximately 20 min.

“Rapid” button

• Enables quicker washing by shortening the

programme duration.

• Recommendable for small loads or only lightly soiled

laundry.

“Variable spin” button

• Every programme has a predefined spin speed.

• Press the button to set another spin speed.

• If spin speed “0” is selected, the final spinning is

cancelled but intermediate spin peaks remain during

the rinse. The water is drained out only.

Consumption values were measured in normalized conditions in compliance with standard IEC/EN 60 456. Consumption data in the home may vary with

respect to the values in the table in relation to the water supply pressure and temperature, the load and the type of wash.Water and energy consumption refer

to the default setting of the programmes; selecting special options or modifying spin speed or temperature will change the consumption data.

The programme duration may differ from the values indicated above as it depends on the operation conditions applicable at that time (see also

“Troubleshooting Guide” in your Instructions for Use).

* To reduce the water temperature, some cold water is added at the end of the main wash cycle, before the pump drains the water out.

** Reference Programmes for Energy Label.

*** Automatic adaption of programme duration after detection of wash load.

FAILURE INDICATIONS

In case of any failures or irregularities, consult the

“Troubleshooting Guide” in your Instructions for Use.

“Service”

Lighting up of the “Service” indication can be caused

by a fault in an electrical component. Refer to the

“Troubleshooting Guide” in your “Instructions for Use”;

if the fault persists, contact our After Sales Service.

“Water tap closed”

The appliance has no or insufficient water supply. Open

the water tap: if the indications still lights up, refer to the

“Troubleshooting Guide” in the Instructions for Use.

“Clean pump”

Waste water is not pumped out. Check whether the

drain hose is kinked or the filter must be cleaned: in the

latter case refer to the Instructions for Use (“Removing

the Filter”).

5019 612 10243

Programma

Simbolo

di lavaggio

Carico

max

Tipo di carico / Note

- nel selezionare le temperature, rispettare le raccomandazioni del fabbricante

sull’etichetta di lavaggio

Detersivi e additivi Opzioni selezionabili Velocità

max. di

centrifuga

giri/min

Pre-

lavaggio

Lavaggio

principale

Ammor-

bidente

Anti

piega

Pre-

lavaggio

Rapido Centrifuga

Cotone

40 - 60 - 95 °C

40 - 60 - 95°C

5.0

Biancheria da letto, tovaglie e biancheria intima, asciugamani, camicie, ecc. di cotone

e lino.

Se la biancheria è molto sporca, è possibile selezionare anche l’opzione “Prelavaggio”.

Sì

i i i i

Max.

Sintetici

30 - 40 - 60 °C

30 - 40 - 60°C

3.0

Bluse, camicie, grembiuli, ecc. di poliestere (diolen, trevira), poliammide (perlon,

nylon) poco o mediamente sporchi.

Sì

i i i i i

Max.

Delicati

30 - 40 °C

30 - 40°C

1.5 Tendaggi e abiti, gonne, camicie e bluse delicati.

Sì

i i i

–

Max.

Misti

40 °C

40°C

3.0 Capi di cotone e/o sintetici da poco a mediamente sporchi. – Sì

i i

– –

Max.

Rapido 15´

30 °C

30°C

3.0

Rinfresca indumenti esterni indossati per brevi periodi di tempo in cotone, fibre

artificiali e misto cotone. Usare il minimo quantitativo di detersivo consigliato.

– Sì

i i

– –

Max.

Lana

Freddo - 40 °C

- 40°C

1.0 Solo capi antinfeltrenti lavabili in lavatrice, provvisti di marchio Pura Lana Vergine. – Sì

i i

– –

Max.

Lavaggio a mano

30 - 40 °C

30 - 40°C

1.0 Capi di lino, seta, lana e viscosa per i quali è consigliato un lavaggio a mano. – Sì

i i

– –

400

Risciacquo & Centrifuga – 5.0 – –Corrisponde all’ultimo risciacquo ed alla centrifuga finale del programma “Cotone”.

i i

– –

Max.

Centrifuga – 5.0

Programma con cislo di centrifuga intensiva. Stesso ciclo di centrifuga del programma

“Cotone”.

– – – – – –

Max.

Centrifuga breve – 1.0

Programma con ciclo di centrifuga delicata. Con questo programma è possible eseguire

una centrifuga delicata, che corrisponde alla centrifuga del programma Lana.

– – – – – –

Max.

Scarico acqua – –

L’acqua viene solo, scaricata, senza centrifuga. Possibile alternativa per terminare i

programmi dopo “Anti Piega”.

– – – – – – – –

A. Manopola Programmatore

B. Indicatore delle fasi del programma

C. Manopola Selettore Centrifuga

D. Tasto “Avvio/Pausa”

E. Tasto “Annulla”

F. Spia “Apertura porta”

La lavatrice è dotata di fumzioni di sicurezza

automatiche in grado di riconoscere e

segnalare tempestivamente eventuali guasti,

reagendo in modo adeguato, ad es.:

G. Spia “Service”

H. Spia “Ingresso acqua”

I. Spia “Pulizia filtro”

Non utilizzare detersivi liquidi per il lavaggio

principale se è stata selezionata l‘opzione prelavaggio.

Per una miglior cura dei capi, in questo programma

l'effettiva velocità di centrifuga è limitata a 400 giri/min.

Selezionabile solo per i programmi Cotone 60 e 40°C.

SCHEDA PROGRAMMI

N.B. Questa mcchina è controllata da sensori. Evitare di utilizzare quantità eccessive di detersivo.

i = opzionale / Sì = dosaggio richiesto

Produkspesifikasjoner

Merke:	Bompani
Kategori:	Vaskemaskin
Modell:	BOCA080/E

Trenger du hjelp?

Hvis du trenger hjelp med Bompani BOCA080/E still et spørsmål nedenfor, og andre brukere vil svare deg

Ditt navn*

Din e-post*

Skriv spørsmålet ditt her

Vaskemaskin Bompani Manualer

Bompani BOCA106/E Bruksanvisning

25 Februar 2025

Bompani BOCA080/E Bruksanvisning

25 Februar 2025

Bompani BOCA060/E Bruksanvisning

25 Februar 2025

Bompani BO05283E Bruksanvisning

25 Februar 2025

Bompani BO05030/E Bruksanvisning

25 Februar 2025

Bompani BOWD114/E Bruksanvisning

25 Februar 2025

Bompani BOCA814/E Bruksanvisning

25 Februar 2025

Vaskemaskin Manualer

Nyeste Vaskemaskin Manualer

Hanseatic WA 1200-5 Bruksanvisning

10 April 2025

Hotpoint-Ariston artxd 149 Bruksanvisning

9 April 2025

Hotpoint-Ariston AQXF 145 Bruksanvisning

9 April 2025

Hotpoint-Ariston argd 169 eu Bruksanvisning

9 April 2025

Miele WSE383 WCS Bruksanvisning

9 April 2025

Zanussi-electrolux zf 1044 Bruksanvisning

8 April 2025

Hotpoint NDB 10748 WA Bruksanvisning

8 April 2025

Whirlpool FFB 7269 BV Bruksanvisning

8 April 2025

Whirlpool FFWDD 107448 WBS Bruksanvisning

8 April 2025

Whirlpool TDLR 6261BS Bruksanvisning

8 April 2025
