Side 1/3

Accessories: To purchase Bosch accessories, cleaners & parts please visit www.bosch-home.com/us/store or call 1-800-944-2904 (Mon to Fri 5 am to 6 pm PST, Sat 6 am to 3 pm PST).

Notes: All height, width and depth dimensions are shown in inches. BSH reserves the absolute and unrestricted right to change product materials and speciﬁcations, at any time, without

notice. Consult the product’s installation instructions for ﬁnal dimensional data and other details prior to making cutout.

Warranties: Please see Use & Care manual or Bosch website for statement of limited warranty.

For more information on our entire line of products, go to www.bosch-home.com/us or call 1-800-944-2904

SHP65DM2N

White

Also available in:

Stainless Steel SHP65DM5N

Black SHP65DM6N

Zone Wash creates an

intensive wash focus area,

allowing you to wash your

challenging dishes and

pots with conﬁdence

Features & Beneﬁts

The AutoAir

drying option

automatically releases

the door at the end of

the cycle to let moisture

escape and fresh air in for

drier dishes.

So quiet at 44 dBA,

InfoLight

shines on the

ﬂoor so you know the

dishwasher is running.

Enhance your cleaning

experience with Wi-Fi

enabled Home Connect®.

Access additional wash

cycles and options or

choose the right one for

your needs using Smart

Cycle.

The Favorite button allows

you to easily access your

preferred cycle/option

combination with 1 touch.

24" Pocket Handle Dishwasher

500 Series – White SHP65DM2N

Capacity

Number of place settings 16

Technical Details

Watts 1440 W

Current 12 Amps

Volts 120 V

Frequency 60 Hz

Power cord full length 67"

Power cord install length

from edge of unit when

facing the door

Left – 45"

Right – 56"

Minimum water pressure 14 lb/sin

Length outlet hose 78 3/4"

Dimensions & Weight

Overall appliance

dimensions (HxWxD)

33 7/8" x 23 9/16"

x 23 3/4"

Required cutout size

(HxWxD)

33 7/8" x 24" x 24"

Adjustable feet Yes

Net weight 85 lbs

Accessories—Optional

Junction Box SMZPCJB1UC

Junction Box + Supply

Hose Kit

SMZ3IN1UC

Bosch Dishwasher Water

Supply Hose

SMZSH1ABUC

Drain Hose Extension Kit SGZ1010UC

Edge Protector + Power

Cord Clip Install Kit

SMZEPCC1UC

General Properties

Wash cycles

(control panel)

5 (Deep Clean,

Auto, Normal,

Speed60 (1hr

Wash), Favorite)

Additional wash cycles

(in Home Connect

)

3 (Delicate, Rinse,

MachineCare)

Options

(control panel)

3 (Sanitize, Remote

Start, AutoAir®)

Additional options

(in Home Connect

)

3 (Half Load, Eco,

Zone Wash)

dBA 44

Wash system Zone Wash

Drying system AutoAir

Third rack Standard 3rd Rack

Rack adjustability Rackmatic

Tub material Stainless Steel

Concealed water

heating element

Yes

Leak protection system 24/7 AquaStop

Home Connect

(Wi-Fi enabled)

Yes

NSF

-certiﬁed** sanitize

option

Yes

Water softener No

Five-level wash Yes

Child Lock button

suspension

Anti-Fingerprint Finish N/A

Special features InfoLight

, AutoAir

Option, Zone Wash

Efﬁciency

Water usage per cycle 3.2 gal

ENERGY STAR

Certiﬁed Yes

Total annual energy

consumption

240 kWh

*Compared to a Bosch dishwasher with 2 racks.

**Certiﬁcation to NSF/ANSI Standard 184 for residential dishwashers.

Accessories: To purchase Bosch accessories, cleaners & parts please visit www.bosch-home.com/us/store or call 1-800-944-2904 (Mon to Fri 5 am to 6 pm PST, Sat 6 am to 3 pm PST).

Notes: All height, width and depth dimensions are shown in inches. BSH reserves the absolute and unrestricted right to change product materials and speciﬁcations, at any time, without

notice. Consult the product’s installation instructions for ﬁnal dimensional data and other details prior to making cutout.

Warranties: Please see Use & Care manual or Bosch website for statement of limited warranty.

For more information on our entire line of products, go to www.bosch-home.com/us or call 1-800-944-2904

Installation Details

5/25

24" Pocket Handle Dishwasher

500 Series – White SHP65DM2N

Ø 2

/ "2

(63.5 mm)

(178 mm)

Example of Hardwire Installation

Note: Cutout

required on left or right

cabinet wall, depending on

location of water inlet, drain

and electrical connection

/ "2

(63.5 mm)

Junction box accessory

available for purchase

SMZPCJB1UC

(not included)

Ø 2

/ "2

(63.5 mm)

(178 mm)

Example of an Electrical Receptacle Installation

Note: Cutout

required on left or right

cabinet wall, depending on

location of water inlet, drain

and electrical connection

/ "2

(63.5 mm)

3-prong

power cord

included

Pre-connected

drain hose

Toe-kick

Power cord

(3-prong plug)

Protective guard to

help protect cabinetry

Included:
