1
HS-200M HEALTH SCALE
The Health Scale HS-200M is designed to both weigh the body and measure the height
and meets the OIML International Recommendation R76. The scale has the advantage
of a large weighing range, accuracy and high sensitivity. It is ideal for school nurse’s
offices or for doctor’s screening rooms where height and patient weight measuring is
necessary. It is also can be used for other weighing needs.
Specification:
1. Maximum capacity: 160kg/350lb, 180kg/400lb, 200kg/450lb；
2. Graduation: 100g/0.25lb
3. Height Range: 60-210cm
4. Minimum value of height per division: 5mm
5. Platform size: 375 cm x 275 cm
6. Overall dimension (L x W x H) 530mm x 275mm x 1485mm
Installation Instruction:
Weighing Ruler
Height Rod
Pillar
Platform
Frame
Moving Wheel
2
Pillar Installation (Fig.2):
1. Insert the pillar upright to the bracket on frame
2. Use the screws and washer to fix the pillar in a vertical position
Main poise weight
Measuring rule
Zero balance weight
Zero adjusting screw
Force lever
Pole
Steelyard rod
Pillar head
Eye loop
Bolt
Pillar
Platform
Frame
Accessory poise weight
3
II. Connect the steelyard rod to long lever (Fig.3):
1. Lay the pillar on a table (Fig.3)
2. Disassemble the wires on the levers.
3. Insert the wrench into the small hole in front of the steelyard rod, and pull the
hook of the steelyard rod with the hook of wrench (Fig. 3.1)
4. Push the long lever forward, then hook the bearing of the steelyard rod on the
pivot of the long lever (Fig. 3-2)
5. Take away the wrench form the draft rod (Fig.3-3)
6. Put the scale on the ground gently
Zoom
Disassemble
the wires
Connect the steelyard to the long lever
Wrench
Steelyard rod hook
Fig 3.1
