Side 1/2
Café
™
30" Slide-In Front Control Induction
and Convection Range with Warming Drawer
CCHS900P4MW2 / CCHS900P3MD1 / CCHS900P2MS1
ALSO
AVAILABLE IN
CCHS900P2MS1
Stainless Steel with
Brushed Stainless
handles and knobs
CCHS900P4MW2
Matte White with
Brushed Bronze
handles and knobs
FEATURES
FEATURES & BENEFITS
Gourmet results without any guesswork - Take culinary skills to the next level
with Gourmet Guided Cooking, which combines video-guided recipes from
chefs with a system that automatically adjusts the time, temperature and
cooking pace for perfect results
Enjoy total control in the kitchen and beyond - Control your oven with your
smart device or simply your voice using WiFi Connect
An attractive appearance at all times - Every detail of your kitchen is designed
to delight, thanks to a sleek backlit glass touch control panel that visually
disappears when not in use and wakes up when prompted
The perfect combination of power & precision - Stun guests by showing off
your 11" 3,700-watt induction element, which uses chef-preferred induction
cooktop technology to deliver precise heat to cookware only. That means you
can do everything from boiling a quart of water in 101 seconds to melting butter
at exact temperatures with amazing efficiency
Precise control for flawless results - Delight guests with the precision of sous
vide cooking or perfectly prepared fondues and delicate sauces using a
precision cooking probe that is sold separately.
Ensure consistent temperatures across a large area - Evenly heat large
griddles or enamel cookware across two 8" synchronized elements
Create a look that matches your personal style - Select any combination of
premium finishes and hardware options to create a stunning look customized
to any owner’s taste
Allow your appliances to interact with one another - Create a chef-like
experience with Chef Connect, which can synchronize your appliance clocks
and surface lights and vent when a range burner is in use, and even your
microwave and range clocks
ACCESSORIES
Trim Kit
Optional; JXFILLR1BB
Cooktop Cleaning
Included; Cream; Sponge
Probe Accessory
Optional; JXPROBE1
WEIGHTS & DIMENSIONS
APPEARANCE
Installation
Flush Appearance; Free-standing cut-out
Oven Door Features
Big View Oven Window; Full-Wrapped Metal Frame
Handle
Professional Style; Customizable; Consumer Removable
CAPACITY
Total Capacity (cubic feet)
5.7 cu ft
ADA
COMPLIANT
Configuration
Range with Warming Drawer
Cooking System
True European Convection with Precise Air
Cooking Technology
Convection
Oven Cleaning Type
Self-Clean with Steam Clean Option
Cooktop Burner Type
Induction
Cooktop Surface
Edge-to-Edge; Black Ceramic Glass
Control Location
Front controls
Control Type
White Backlit; Glass Touch
Oven Control Features
Audible Preheat Signal; Auto Oven Shut-Off with
Override; Auto Recipe Conversion; Auto Self Clean;
C° or F° Programmable; Certified Sabbath Mode;
Chef Connect; Control Lock Capability; Delay Bake
Option (Time Bake); Delay Clean Option; Electronic
Clock & Kitchen Timer; Fast Preheat; Hi / Low Broil;
Oven "ON" Light; Self-Clean Cool Down Time Display;
Steam Clean; Temperature Probe
Oven Cooking Modes
Baked Goods (No Preheat); Convection Bake;
Convection Roast; Frozen Pizza Multi Rack (No
Preheat); Frozen Pizza Single Rack (No Preheat);
Frozen Snacks Multi Rack (No Preheat); Frozen
Snacks Single Rack (No Preheat); Proof; Warming
Oven Features
8-Pass Broil Element; Hidden Bake
Self-Clean Oven Door Lock
Automatic
Oven Rack Features
1
Self-Clean Heavy-Duty Roller Rack; 2 Self-Clean
Heavy-Duty Oven Racks; 6 Rack Positions
Oven Interior
Black; 1 Incandescent
Connected Capabilities
Amazon Alexa; The Google Assistant; Hestan Cue;
IFTTT; Nest; Drop; Innit; DiGiorno
WiFi Connect
Built-In
Element - Left Front
8" 2500W Sync Element
Element - Left Rear
8" 2500W Sync Element
Element - Right Front
11" 3700W Power Boil
Element - Right Rear
6" 1800W
Element - Center
6" 100W Warming Zone
Hot Surface Indicator Lights
1
Heating Element "ON"
Indicator Light
5
Warming Drawer Features
(3) levels
Depth with Door Open
47-1/2 in
Approximate Shipping Weight
256 lb
Net Weight
236 lb
Height to Top of Rear Vent Trim
37-3/8 in
Overall Height
37-3/8 in
Height to Cooking Surface (in.)
36-1/4 +/- 1/4
Overall Width
29-7/8 in
Cabinet Width
30 in
Overall Depth
29-1/2 in
Depth Without Handle
26-7/8 in
Oven Interior Dimensions
(W x H x D) (in.)
24 x 19-7/8 x 20-5/8
Café
™
30" Slide-In Front Control Induction
and Convection Range with Warming Drawer
CCHS900P4MW2 / CCHS900P3MD1 / CCHS900P2MS1
29-7/8"
1-1/8"
36-1/4"
+_
1/4"
*26-7/8"
47-1/2"
DIMENSIONS
Receptacle Locations:
Locally
approved flexible service cord or
conduit must be used because
terminals are not accessible
after range installation. See
shaded area in drawing for
location of electrical outlet box.
Recommended outlet locations
allow range to be installed directly
against rear wall.
Note:
This appliance has been
30"
30" min
See note A
Side Wall
approved for 0" spacing to
adjacent surfaces above the
cooktop. However, a 6" minimum
spacing to surfaces less than 15"
above the cooktop and adjacent
cabinet is recommended to
reduce exposure to steam,
grease splatter and heat.
Installation Information:
Before
installing, consult installation
Recommended
Wall-Mounted
6-1/2" single ovens
7-1/2" double ovens
7-1/2"
2-1/2"
4" single ovens
0"
minimum
to cabinets
below
cooktop
24"
2-1/2"
30"
36"
0"
permitted
recommend
6"
space to
each side wall
instructions for current
dimensional data and
additional requirements.
*Depth including door handle is approximately 29 1/2".
3" double ovens
Note A: 30" Minimum to bare cabinet, see
installation instructions heights less than 30"
ADDITIONAL ACCESSORIES
CXFCHHKPMBZ
Brushed Bronze
2 handles; 6 knobs
CXFCHHKPMSS
Brushed Stainless
2 handles; 6 knobs
CXFCHHKPMBT
Brushed Black
2 handles; 6 knobs
CXFCHHKPMCU
Brushed Copper
2 handles; 6 knobs
JXPROBE1
Probe Accessory
For answers to your Café™ product questions, visit our website at cafeappliances.ca.
© 2019 GE Appliances PC93682 11/19
WARRANTY
Parts warranty
Limited 1-year entire appliance
Labor warranty
Limited 1-year entire appliance
POWER / RATINGS
Amp Rating at 208V
40
Amp Rating at 240V
40
Convection Wattage
2500W
Bake Wattage
2850W
Broiler Wattage
4000W
KW Rating at 208V
11.3
KW Rating at 240V
13.6
