Side 1/12

Your music + our passion

651T

azur

ENGLISH

User’s manual

Thank you for purchasing your Azur 651T. We are confident that you will

enjoy many years of listening pleasure from it. Like all Cambridge Audio

products, the Azur 651T adheres to our three core principles – stunning

performance, ease of use and incredible value.

The 651T supports both the digital DAB and analogue FM/AM radio

systems. For FM/AM the 651T features true analogue domain decoding of

FM/AM for best sound quality with this format.

For DAB broadcasts the built in digital radio tuner is compatible with both

the DAB and DAB+ (AAC+ format) standards and features a very high

quality WM8740 Digital to Analogue converter from Wolfson

Microelectronics.

An Azur Navigator remote is provided, giving full remote control of the

tuner functions and those of our amplifiers in an attractive and easy to

use handset.

The 651T can only be as good as the system it’s is connected to. Please

do not compromise on your amplifier, speakers or cabling. Naturally we

particularly recommend models from the Cambridge Audio Azur range

which have been designed to the same exacting standards as this tuner.

Your dealer can also supply excellent quality Cambridge Audio

interconnects to ensure your system realises its full potential.

The use of an external aerial is strongly recommended to get the best from

your 651T.

Thank you for taking the time to read this manual; we recommend you

keep it for future reference.

Matthew Bramble

Cambridge Audio Technical Director

and the 651T design team

Contents Introduction

Introduction .................................................................................................2

Important safety instructions .....................................................................3

Limited warranty..........................................................................................4

Rear panel connections..............................................................................5

Front panel controls ....................................................................................6

Remote control............................................................................................7

AM loop aerial .............................................................................................8

FM aerial......................................................................................................8

DAB aerial ....................................................................................................8

Aerials ..........................................................................................................8

Operating instructions ................................................................................8

General operation (all modes) ...................................................................9

Connecting the Control Bus .....................................................................10

Custom installation (C.I.) use...................................................................10

Technical specifications ...........................................................................11

Troubleshooting.........................................................................................11

Make sure you register your purchase.

Visit: www.cambridge-audio.com/sts

By registering, you’ll be the first to know about:

Future product releases

Software upgrades

News, events and exclusive offers plus

competitions!

This guide is designed to make installing and using this product as easy

as possible. Information in this document has been carefully checked

for accuracy at the time of printing; however, Cambridge Audio's policy

is one of continuous improvement, therefore design and specifications

are subject to change without prior notice.

This document contains proprietary information protected by copyright.

All rights are reserved. No part of this manual may be reproduced by any

mechanical, electronic or other means, in any form, without prior written

permission of the manufacturer. All trademarks and registered

trademarks are the property of their respective owners.

Produkspesifikasjoner

Merke:	Cambridge
Kategori:	lydstiller
Modell:	Azur 651T
Vekt:	4100 g
Bredde:	430 mm
Dybde:	305 mm
Høyde:	70 mm
FM-bånd:	87.5 - 108 MHz
Strømforbruk (standby):	1 W
Selektivitet:	25 dB
Produktfarge:	Sølv
Strømforbruk (vanlig bruk):	15 W
Fjernkontroll medfølger:	Ja
Signal-til-støy-forhold (SNR):	105 dB
Total Harmonic Distortion (THD):	0.005
Formål:	Hjem
Støttede radiobånd:	AM, DAB, DAB+, FM
RDS-mottaker inkludert:	Ja
AM båndbredde:	531 - 1620 kHz
Lyd D/A-konverterer (DAC):	Wolfson WM8740 24-bit
Frekvens (MHz):	20Hz - 20kHz
DAB-tuner:	Ja
DAB III båndområde:	175 - 240 MHz
DAB L båndområde:	1491 MHz
