LVL255A05
10/22
Tel: (613) 342-5424, Fax: (800) 263-4598
Fixture
Phillips
Screwdriver
Wire Cutters
Pliers Wrench
Wiring supplies
as required by
local electrical
code
INSTALLATION:
SAFETY PRECAUTIONS:
TOOLS AND MATERIALS REQUIRED:
1. TURN OFF ELECTRICAL POWER BEFORE STARTING INSTALLATION OF LIGHT FIXTURE.
2. THIS PRODUCT MUST BE INSTALLED IN ACCORDANCE WITH THE APPLICABLE INSTALLATION CODE
BY A PERSON FAMILIAR WITH THE CONSTRUCTION AND OPERATION OF THE PRODUCT AND THE
HAZARDS INVOLVED.
3. CONNECT THE GROUND WIRES (BARE COPPER OR GREEN) FROM YOUR FIXTURE TO THE GROUND
WIRE (BARE COPPER OR GREEN) OR GROUND SCREW IN THE ELECTRICAL BOX.
4. TO CLEAN THE FIXTURE, TURN OFF THE POWER, WAIT FOR IT TO COOL, AND WIPE THE FIXTURE WITH
A CLEAN, SOFT CLOTH. NO SERVICE PART IS REQUIRED INSIDE THE FIXTURE.
NOTE: Product may not look exactly as shown in figures.
1. Mount the mounting
bracket to electrica
l box using
electrica
l box screws (not
included).
2. Connect the ground
wires (bare copper or green)
from your fixture to the
ground wire (bare copper or
green) or ground screw in the
electrical box. Attach the
black wire from the light
fixture to the black wire in the
electrical box. Attach the
white wire from the light
fixture to the white wire in the
electrical box.
NOTE: Do not disconnect
any pre-wired connections.
3. Once connections of
wires are completed, carefully
tuck wires and wire nuts into
the electrical box making sure
no bare wire (on the black and
white) is visible at the wire
nuts.
4. Attach fixture to
mounting bracket by
tightening the 2 screws.
Screw
Electrical
Box
Electrical Box Screws
(not included)
Mounting
Bracket
White
Black
House
supply
Ground
wire
Fixture
Ground wire
LED VANITY
dimmable
This LED light is compatible with the dimmers:
LEVITON# 66EV-742-P0W, 742-6672-HLW, 722-6674-PDW MAX 150 W,
Lutron # SCL-153PH-WH MAX 150 W.
The MAX rated wattage of this model is 20 W
