Side 1/3

MicroFlip

™

100x–250x Zoom Pocket

Microscope

i  e

Adapter clip

Eyepiece

LED switch

Focusing ring

UV light

ownward

Facing LED

Front Facing LED

Objective lens

UV light switch

Zooming dial

Battery door

Base plate

Install the battery



Slide open the battery door (Fig.1).

 Install 1 (one) AA alkaline battery with the correct polarity (Fig.2).

 Attach the battery door (Fig.3).

Fig.1 Fig.2 Fig.3

2

Using the microscope to view objects directly

 ae sre the base plate sits behind the batter door in the pright position (Fig.).

 Press the LED switch to turn on the LED (Fig.). lease note that when base plate is in pright position

onl front facing E will illminate.

 Place the viewing object directly below the objective lens (Fig.6).

Fig.4 Fig.5

Fig.6

Using the microscope to view specimen slides

1. Flip the base plate down so that it sits on the base of the microscope (Fig.).

2. ress the E switch to trn on the E (Fig.). lease note that when base plate is down onl downward

facing E will illminate.

. nsert the specimen slide into the slot between the obective lens and the base plate (Fig.).

Fig.

Fig. Fig.

Adjusting zoom & focus

 Adjust the zooming dial to the desired level

of magnification (Fig.10).

 Rotate the focusing ring until the image is

sharp and clear (Fig.11).

UV light

Press and hold the UV light switch to activate the

UV light (Fig.12).

NOTE: The UV light is deactivated when the base

plate is flipped down to the base of the microscope.

Fig.10 Fig.11

Fig.12

WARNING:

Do not look directly

at the UV light.

Produkspesifikasjoner

Merke:	Carson
Kategori:	Mikroskop
Modell:	MICROFLIP MP-250
Vekt:	74 g
Bredde:	32 mm
Dybde:	61 mm
Høyde:	109 mm
Strømkilde:	Batteri
Pakkevekt:	111 g
Innebygd kamera:	Nei
Minimum forstørrelse:	100 x
Produktfarge:	Black, Stainless steel
Pakkedybde:	36 mm
Pakkehøyde:	135 mm
Pakkebredde:	66 mm
Belysning:	Ja
Mikroskoptype:	Digitalt
Maksimal forstørring:	250 x
