INSTRUCTION MANUAL | MS-040
Standard Included Accessories: 10x Wide Field Eyepiece
Eyepiece
360°
Rotatable
Draw Tube
Objective Lens
Reective Light Source
Stage Clips
Focus Knob
Stage
Filter Wheel
Transmitted
Light Source
Power
Intensity Knob
for Reective
Light Source
Intensity Knob for
Transmitted Light Source
(on opposite side)
Base
Turret
Quick-Start Guide:
1. Place microscope on a secure surface. You may rotate the draw tube to the front facing position or any preferred
360° position.
2. Insert the round end of the power cord into the microscope’s power port on the rear bottom side of the micro-
scope, and plug the opposite end of the power cord into any standard 110V outlet.
3. Gently place the narrow end of the eyepiece into the draw tube.
4.
Rotate the objective lens turret so that the rst objective lens (4x labeled by a red line) is perpendicular to the stage.
5. Position your desired specimen on the stage, with your area of interest located in the center of the stage.
6. Use the stage clips to securely hold down your slide or specimen.
Quick-Start Guide:
1. Place microscope on a secure surface. You may rotate the draw tube to the front facing position or any preferred
360° position.
2. Insert the round end of the power cord into the microscope’s power port on the rear bottom side of the microscope,
and plug the opposite end of the power cord into any standard 110V outlet.
3. Gently place the narrow end of the eyepiece into the draw tube.
4.
Rotate the objective lens turret so that the rst objective lens (4x labeled by a red line) is perpendicular to the stage.
5. Position your desired specimen on the stage, with your area of interest located in the center of the stage.
6. Use the stage clips to securely hold down your slide or specimen.
7. Turn on appropriate light source(s).
i. For transparent specimens such as biological slides, rotate the intensity knob for the transmitted light source to
turn on the light and to change light intensity.
ii.
Foropaque orreflective specimens,rotate the intensityknob for thereflectivelightsourcetoturnonthelight
and to change light intensity.
iii. For mixed transparent and opaque specimens, you may turn on both the reective and transmitted light
sources.
8. Focusing:
i.
Lookintotheeyepiece and youshouldsee a whitefieldimage.
ii. Gently adjust the focus knob until the image of the specimen comes into a crisp focus.
iii. Adjust light intensity on light sources to achieve best image.
CAUTION: Always take care when focusing, so that the objective lens does not collide down on the specimen, as
you may cause damage to objective lens and/or specimen.
Objective
Eyepiece
Total
Lens
Magnication
10x 4x
40x
10x
10x 100x
10x
40x
400x
9. Magnication:
i. To change magnication, rotate the objective lens turret so that the desired objective lens is perpendicular to
the stage. Refocus as needed.
10. Color lters may be used to enhance contrast, especially if using stained slides. To use color lters, rotate lter wheel
until the wheel clicks into the desired color lter.
Care & Maintenance:
• Please take care when using our microscope. Try to avoid bringing your microscope into contact with any dirt,
debris, dust or moisture.
• Cleaning:
— For microscope body, unplug power and use a soft slightly damp cloth to clean dust or dirt.
— For optical surfaces, such as the eyepiece lens or objective lens, use a slightly damp microber cloth or
Carson’s Lens Cleaners to gently remove dust or debris.
• When not in use, it is best to store your microscope in original container.
• When moving the microscope, hold by the metal neck or base of the microscope body.
Do not hold by the eyepiece lens, draw tube, or objective turret.
2
