Side 1/2
OK
NO!
Indicator
(Constant red light)
Remaining battery capacity:
When the switch (battery indicator) is illuminated in red, there is little
remaining battery power. Replace the battery as soon as possible.
ENG
Design Pat. Pending
Copyright© 2019 CATEYE Co., Ltd.
HLEL370G-191010
1
1
WARNING!!!
• Be sure to direct the light beam downward so
approaching car or pedestrian are not dazzled.
• Before your trip, please make sure the light is
firmly mounted to the bracket and it lights up.
• Always pay attention to the remaining battery power
by checking the battery indicator periodically while
using the light.
CAUTION!
• Keep the light away from children.
• Mounting the light unit too close to a wireless
computer may adversely affect the reading of the
computer.
• This product is water-resistant under normal daily
use and can be used in the rain. However, do not
intentionally submerge it in water.
• If the light unit or parts become dirty with mud,
etc., clean with a soft cloth which is moistened with
mild soap. Never apply paint thinner, benzine or
alcohol; damage will result.
HOW TO REPLACE BATTERY
2
HOW TO MOUNT TO A BICYCLE
Light unit FlexTight™ bracket
(
H-34N
)
Before using the light, read this manual
thoroughly and keep it for future reference.
5338827N
FlexTight™ bracket
(
H-34N
)
5341831N
Helmet mount
SPARE/OPTIONAL PARTS
SPECIFICATIONS
1
4
5 6
3
3
1. Slide the cover backward while pressing
on the dot section (Fig.1 , ).
2. Insert the batteries on top of the belt
according to the orientation marked on
the unit ( ).
3. Reattach the cover by following the
procedure in reverse.
CAUTION!
• Do not use rechargeable batteries.
• Do not combine old and new batteries or batteries of
different types.
• Ensure correct polarity when installing the batteries.
• Remove the batteries if the light will not be used for a long
time. Failure to do so may result in malfunction due to
battery fluid leakage.
Manual
BATTERY HEADLIGHT
HL-EL370G
K 1682
Dot section
Cover
Belt
Pull
Belt
Alkaline AAA
batteries
× 3
1 2
Removing the battery
*1
*3
*2
Mounting height : 400 – 1200 mm
Bracket
Rubber pad
Strap
Dial
Release button
Screw
1. Mount the bracket to the handlebar. (Fig.2 – )
2. Insert the light unit into the bracket until it clicks, and
adjust the beam angle. ( ) (*1)
3. To remove the light unit, pull it forward while pressing
down on the release button ( , ).
* To readjust the beam angle, loosen the dial and/or the
screw enough to move the bracket, and firmly tighten them
after adjustment. (*2)
CAUTION!
• Be sure to tighten the dial by hand.
If tightened too hard with a tool, the screw thread may be stripped.
• Check the dial and screw (*2) on the bracket periodically, to monitor for any loosening.
• If cutting the strap, be careful of injury from where the strap is cut. (*3)
1
4
5
6
4
2
3
1
2
3
3
ONOFF
*4
When turning the light on, it lights up in the mode that was used
last time. (Mode memory function)
*4:
Switch
(Battery indicator)
Switch : Press and hold
3
SWITCH OPERATION
Click
High Low
Light source High-intensity LED x 1
Battery Alkaline AAA batteries 1.5 V x 3
Operating time High : Approx. 3 hours
Low : Approx. 10 hours
* Average runtime at 68˚F (20˚C).
Temperature range 14˚F – 104˚F (-10˚C – 40˚C)
Dimensions/weight 1-11/32” x 1-1/2” x 3-23/64”
(34 x 38 x 85.5 mm) / 2.33 oz (66 g)
* The specifications and design are subject to change without
notice.
