Side 1/2
ENG
K 2032
(GVOLT45)
1
2
(H-34N)
ON
*1
OFF
LITHIUM-ION BATTERIES
Recharge the battery for first time use or after long period of
storage:
The voltage of the battery may drop due to self-discharge during
long period of storage. Always fully charge the battery before use.
Cautions for charging and usage:
• Please be sure that no dust or other foreign objects are
attached to the plug of the USB cable before charging.
• Do not subject the light to vibrations while charging.
• Once charging is completed, be sure to disconnect the USB
cable from the charging port.
• Charging, discharging, and storing in high temperatures will
cause the rechargeable battery to deteriorate faster. Do not
place the light inside a vehicle or near a heater. Make sure to
charge only when the ambient temperature is between 41˚F
and 104˚F (5˚C and 40˚C).
• If the illumination time is significantly reduced even after
proper charging, the rechargeable battery may be nearing the
end of its service life.
Cautions on storage:
• If the device will not be used for a long period of time, store it
in a location that is not too hot or too humid.
• Charge the battery for about 30 minutes every 6 months.
Cautions for dispose:
When disposing the light unit, please do so in accordance with
your local regulations.
Design Pat. Pending
Copyright© 2022 CATEYE Co., Ltd.
HLEL550GVRC-220131
1
1
WARNING!!!
(Risk of death; Prevention of accidents)
•
Do not look directly at the light source. In addition, when mounting
the light unit, ensure that the light will not dazzle other road users.
•
Please make sure the light is firmly mounted to the bracket and it
lights up properly before each ride. The light must not be obscured.
• Always attention to the remaining battery power by checking the
indicator periodically while using.
•
Do not disassemble or modify the light or any of the included items.
CAUTION!
(Prevention of injury, damage, or property damage)
• Operating the light while riding is dangerous. Always ride safely.
• Note that the light becomes hot while illuminated. Do not block
the lens or cover the light.
• Due to the variability of LEDs, the color and brightness may differ
even between devices with the same model number.
• Do not place it within children’s reach.
• Carrying a spare headlight is recommended in case the battery
runs out.
• When used with a cyclocomputer, attach the headlight as far
away from the cyclocomputer as possible, as it may affect
measurement.
• This device is rated IPX4 based on JIS C0920. Do not immerse
the device in water. Doing so may cause a malfunction. Wipe off
any moisture after using the device in rainy weather.
• Do not subject the light to strong vibrations, impacts, or
excessive force. Discontinue use if any abnormality occurs.
• Do not charge or use the battery at any voltage or polarity other
than that specified. Do not short-circuit the battery.
• Do not drop the light into a fire or heat the light.
• If the light unit or parts become dirty with mud, etc., clean with a
soft cloth which is moistened with mild soap. Never apply paint
thinner, benzine or alcohol; damage will result.
Approx.
6.5 h (0.5A)
HOW TO CHARGE
2
SWITCH OPERATION
Manual
RECHARGEABLE HEADLIGHT
CAUTION!:
• Always charge the product before use.
• Attach the charging port cover securely to ensure waterproofness.
* When your PC is in sleep state, the unit cannot be charged.
* Using a PC or USB battery charger with an output current of 0.5 A or more is recommended for
charging.
* Charging and lighting times are approximate values, and will vary by environmental and user
conditions.
Standard charging time
Switch (indicator)
Charging status
Constant red light
Charging
Off
Charging is completed
Before using the light, read this manual
thoroughly and keep it for future reference.
Do not use the light in any way other than
as described in this manual.
Included Items
FlexTight™ bracketLight unit
USB cable
To PC or USB
battery charger
Charging port cover
Remaining battery capacity:
When the switch (indicator) is illuminated in red, the remaining battery power is 20% or less.
* Charge the product as soon as possible, as the brightness will no longer conform to German
Road Traffic Ordinance (StVZO) in this condition.
*1 When turning the light on, it lights up in
the mode that was used the last time.
(Mode memory function)
High
Low
(Eco)
Click
Press and hold
Switching the lighting mode
Switch (indicator)
Required Items
Please prepare a USB cable 2.0 (Micro B) or later that can be
used for charging (sold separately) before using this product.
Genuine CATEYE
optional accessory
5342730
USB cable
HL-EL550GV RC
2
3
4
5
1
*3
*2
OK
NO!
(H-37)
(MICRO USB)
(H-34N)
1. Mount the bracket to the handlebar. (Fig 3 – )
2. Insert the light unit into the bracket until it clicks, and adjust the beam angle.
( ) *3, *4
3. To remove the light unit, pull out it forward while pressing down on the release
button ( ).
CAUTION!
• Be sure to tighten the dial by hand. When you tighten it too hard with a tool,
the screw thread may be stripped.
• Round off the cut edge of the bracket strap to prevent injury. *2
• Check the dial and screw (*3) on the bracket periodically, and use them
without any loosening.
3
HOW TO MOUNT TO A BICYCLE
Standard accessories
Optional accessories
LIMITED WARRANTY
Light source High-intensity LED x 1
Battery type Li-ion 3.6 v - 2600 mAh
Charge terminal Micro B USB
Operating time High : Approx. 6.5 hours
Low (Eco) : Approx. 25 hours
* Average runtime at 68˚F (20˚C).
Standard charging time Approx. 6.5 hours (0.5 A)
Charge voltage 5 v
Temperature range Charging : 41˚F – 104˚F (5˚C – 40˚C)
Operating : 14˚F – 104˚F (-10˚C – 40˚C)
Recharge/discharge number of times About 300 times (until the rated capacity drops to 70%)
Waterproof IPX4
Dimensions/Weight 1-27/64” x 4-11/64” x 1-47/64” (36 x 106 x 44 mm) /
3.23 oz (91.5 g) (Light unit only)
* The specifications and design are subject to change without notice.
SPECIFICATIONS
2-year Warranty: Light unit only (excludes battery deterioration)
CatEye products are warranted to be free of defects from materials and workmanship for a
period of 2 years from original purchase. If the product fails to work during normal use, CatEye
will repair or replace the defect at no charge. Service must be performed by CatEye or an
authorized retailer. To return the product, pack it carefully and enclose the warranty certificate
(proof of purchase) with instruction for repair. Please write or type your name and address
clearly on the warranty certificate. Insurance, handling and transportation charges to CatEye
shall be borne by person desiring service.
2-8-25, KUWAZU, HIGASHI SUMIYOSHI-KU, OSAKA, JAPAN 546-0041
For inquiries, please visit https://cateye.com/intl/contact/
CO
.,LTD.
Bracket Dial
Strap
Release button
Slide out the light while pressing
the release button.
Rubber pad
Click
Removing
Mounting
Screw
(Horizontal adjustment)
Dial
(Vertical adjustment)
Mounting height:
400 – 1200 mm
Ø
22 –
Ø
35 mm
1
4
5
3
*4
Adjusting the lighting angle
When mounting the light unit, ensure that the light will not dazzle other
road users.
To adjust the angle, loosen the dial or the screw (*3) to the point that the
bracket moves slightly, make the adjustment, and then tighten the screw
to fix the light unit in place.
5342730
USB cable
5338827N
FlexTight™ bracket
5340920
Bracket spacer
