Side 1/2
ENG
K 1914
1
2
(H-34N)(GVOLT60)
ON
*1
OFF
LITHIUM-ION BATTERIES
Recharge the battery for first time use or after long period of
storage:
The voltage of the battery may drop due to self-discharge during
long period of storage. Always fully charge the battery before use.
Cautions for charging and usage:
• Please be sure that no dust or other foreign objects are
attached to the plug of the USB cable before charging.
• Do not subject the light to vibrations while charging.
• Once charging is completed, be sure to disconnect the USB
cable from the charging port.
•
Charging, discharging, and storing in high temperatures will
cause the rechargeable battery to deteriorate faster. Do not place
the light inside a vehicle or near a heater. Make sure to charge
only when the ambient temperature is between 5 and 40°C.
• If the illumination time is significantly reduced even after
proper charging, the rechargeable battery may be nearing the
end of its service life.
Cautions on storage:
• If the device will not be used for a long period of time, store it
in a location that is not too hot or too humid.
• Charge the battery for about 30 minutes every 6 months.
Cautions for dispose:
When disposing the light unit, please do so in accordance with
your local regulations.
Design Pat. Pending
Copyright© 2021 CATEYE Co., Ltd.
HLEL550GNRC-210421
1
1
WARNING!!!
(Risk of death; Prevention of accidents)
•
Do not look directly at the light source. In addition, when mounting
the light unit, ensure that the light will not dazzle other road users.
•
Please make sure the light is firmly mounted to the bracket and it
lights up properly before each ride. The light must not be obscured.
• Always attention to the remaining battery power by checking the
indicator periodically while using.
•
Do not disassemble or modify the light or any of the included items.
CAUTION!
(Prevention of injury, damage, or property damage)
• Operating the light while riding is dangerous. Always ride safely.
• Note that the light becomes hot while illuminated. Do not block
the lens or cover the light.
• Do not place it within children’s reach.
• In preparation for unexpected battery shutoff, we recommend
you carry a spare light.
• This device is rated IPX4 based on JIS C0920. Do not immerse
the device in water. Doing so may cause a malfunction. Wipe off
any moisture after using the device in rainy weather.
• Do not subject the light to strong vibrations, impacts, or
excessive force. Discontinue use if any abnormality occurs.
• Do not charge the battery in any way or at any voltage other than
that specified. Do not short-circuit the battery.
• Do not drop the light into a fire or heat the light.
• If the light unit or parts become dirty with mud, etc., clean with a
soft cloth which is moistened with mild soap. Never apply paint
thinner, benzine or alcohol; damage will result.
Approx.
6.5 h (0.5A)
HOW TO CHARGE
2
SWITCH OPERATION
Manual
HL-EL550GN RC
RECHARGEABLE HEADLIGHT
CAUTION!:
• Always charge the product before use.
• Once charging is completed, securely close the charging port cover.
* When your PC is in sleep state, the unit cannot be charged.
* We recommend using 500+ mAh USB battery charger.
* Charging and lighting times are approximate values, and will vary by environmental and user
conditions.
Standard charging time
Switch (indicator)
Charging status
Constant red light
Charging
Off
Charging is completed
Before using the light, read this manual
thoroughly and keep it for future reference.
Do not use the light in any way other than
as described in this manual.
Included Items
FlexTight™ bracketLight unit
USB cable
To PC or USB
battery charger
Charging port cover
Remaining battery capacity:
When the switch (indicator) is illuminated in red, the remaining battery power is 20% or less.
* Charge the product as soon as possible, as the brightness will no longer conform to German
Road Traffic Ordinance (StVZO) in this condition.
*1 When turning the light on, it lights up in
the mode that was used the last time.
(Mode memory function)
High
Low
(Eco)
Click
Press and hold
Switching the lighting mode
Switch (indicator)
Required Items
Please prepare a USB cable 2.0 (Micro B) or later that can be
used for charging (sold separately) before using this product.
Genuine CATEYE
optional accessory
5342730
USB cable
